Summary of Contents for AIPTEK Qt CAM FLASH
- Page 1 C o m p a n y English Qt CAM FLASH Installation Guide...
-
Page 2: Installing Batteries
English How to Use Your Camera Introduction The built-in memory of your camera is 64 Mbit memory. It supports two kinds of resolution- high resolution ( 640x480 VGA) for 26 pictures and low resolution ( 320x240 QVGA ) for 107 pictures. Besides, your camera offers several functions on the LCD, showing the remaining number of pictures as well. -
Page 3: Camera Front
Camera Front Flash Strobe View Finder Strap Lens USB Port Camera Back Flash Dial View Finder Shutter Switch( Mode Switch( LCD Display Battery Cover .. 2 .. -
Page 4: Switching The Camera On / Off
English Switching the camera on / off Keep pressing SW2 until the LCD is activated, and the camera turns off after 30 seconds of inactivity. The LCD indicates "Lr" for low resolution (QVGA images) and "Hr" for high resolution(VGA images). The LCD then displays the number of the remaining pictures. -
Page 5: Continuous Mode
High resolution ( 26 images at most ) Picture remaining number Continuous snapshot 10-second self-timer Clear all images Low resolution ( 107 images at most ) Press SW1 to select mode Features are displayed Press SW2 to change features Continuous mode Press the mode switch until "Ct"... -
Page 6: Self-Timer
English Self timer Press the mode switch until "St" appears on the LCD. Then press the shutter switch and a 10 second self-timer starts. Every 10 second the camera issues a short beep. When completing the self-timer, a longer beep sounds, which indicates that a picture is taken. -
Page 7: Changing The Picture Resolution
Changing the picture resolution Picture resolution may only be changed when the camera memory is empty. If there are any pictures stored in your camera, the memory must be cleared first. To change resolution, press the mode switch until the resolution icon is displayed. - Page 8 English How to Download Photo and Video to PC Thank you for purchasing the digital camera. This guide will help you install your camera onto your computer system. Digital Camera Manager Installation Place the CD into your CD-ROM and click on the Digital Camera Manager Icon to begin the intallation.If the CD does not automatically display, simply go to "Start"...
- Page 9 After the welcome screen appears, click "Next". The CD begins installing the driver to the proper location. The dialog box that appears asks if you would like to restart your computer now or later. Press "OK" to complete installation. .. 8 ..
-
Page 10: Start Digital Camera Manager
English Start Digital Camera Manager The digital pictures can be transferred at all times, even if you take only one picture. To connect your camera with your PC, you need a USB cable and USB port. Your camera double beeps when successfully connected with your PC. -
Page 11: Mode Selecting
To start using the Digital Camera Manager, simply click on the "Start" menu and go up to "Programs" Then go to the folder named "Digital Camerar" and select it. This is the program where you can begin to use your camera. Mode Selecting Press the "Live View"... -
Page 12: Pc Camera Mode
English PC Camera Mode It is easy to attach your camera to your system. In this mode, y our camera is used as a standard PC camera. The current view is displayed in the "preview" window. Live preview PC Camera Mode Press "Video Source"... -
Page 13: Dsc Mode
DSC Mode Transferring Photos: This allows you to transfer photos in your camera. Press the "Link" button to connect the camera and transfer photos. < Press the "Album" button to open the album window. > Press the "Transfer all" or "Transfer selected" button to transfer photos to the album window. -
Page 14: Editing Photos
English Enhanced Resolution Mode: . The Largest Resolution : XGA( 800K pixels ) . Optical Resolution: VGA ( 300K pixels) Your camera has particular enhanced image skills, which make images sharper by enhancing the original VGA image to XGA image. How to operate: Click the setting button. - Page 15 Transferring Video: After transferring images to the preview window, click AVI Creator and all images are combined in one AVI file. This AVI file is saved in your album folder. Note: Pictures in AVI files can be placed forward or backward. AVI Creator (Reverse) AVI Creator...
- Page 16 English Playing Video: You can play any video clip file (AVI format) you want in album window by double clicking the AVI file icon to execute your default media application. Image processing: Click the" Image Process" button to choose image settings. Image Process ..
- Page 17 Mail Function: Click the "Mail" button to attach selected image to a new email document. It is easy to send images to your family and friends! Mail Album window: Delete Click the button. All the files you select in the album window are cleared forever.
