- Page 1 MegaCam MegaCam Manager Manager E-Manual...
-
Page 2: Chapter 1: How To Use Your Digital Camera
Chapter 1: How to Use Your Digital Camera Introduction The built-in memory of your camera is 16MB (128Mbits) memory. It supports two kinds of quality - high quality(1248x960) pictures and normal quality (640x480) pictures. It also supports AVI Movie mode( 624x480) and (304x240) for high quality and normal quality. -
Page 3: Your Camera
Your camera Flash View Finder Flash Dial USB port Lens Power Battery Cover Mode Switch LCD Display Shutter Switch... -
Page 4: The Lcd Display
The LCD display Press the power button to turn on/off the camera. Press the mode button, the LCD indicates still image, AVI movie, Self-timer, erase last, erase all, quality and good battery icons in order. To use the function of the icons, press the shutter button. LCD Display Self Timer Flash Strobe... - Page 5 Icon Functions Still Image mode AVI Movie mode Self Timer Erase Last Erase All Plug in USB Cable AUTO Flash Strobe High quality Normal quality Digit Counter Good battery Low battery Description - takes still pictures - takes AVI Movie pictures - starts 10 second self-timer to take a picture - erases the last picture - erases all of the pictures in the memory...
-
Page 6: Turning On / Off Your Camera
Turning on / off your camera Press the power button to turn on/off the camera. Your camera turns off automatically when idle over 60 econds. Chapter 2: Taking Pictures Press the shutter switch to take a picture. A high pitched beep indicates that a picture is taken successfully and the counter increases as well. -
Page 7: Self Timer
AVI Movie Mode Press the mode button. The LCD shows the AVI Movie Mode icon. Keep pressing the shutter button to take AVI Movie. Also, AVI Movie can be made with a click on the shutter. Release the shutter button to stop AVI Movie Mode. Self Timer Press the mode button. -
Page 8: Erase All
Erase All Press the mode button. The LCD shows the Erase All icon. Press the shutter button. The Erase All icon starts to blink. Press the shutter button again and all the stored picture and AVI Movie are cleared. Digit Counter It shows the total taken images and AVI Movies. - Page 9 Quality Good You should use high quality when you need very good image quality. Normal You should use low quality when you need standard image quality. Choosing the Quality Press the mode button until a star icon with H or L is shown. To change "H"...
-
Page 10: Chapter3: How To Transfer Photo And Video To Pc
Chapter3: How to Transfer Photo and Video to PC Hardware Installation Plug the larger end of the USB cable to the USB port of your PC. Connect the smaller end of the USB cable to the USB port of your camera. -
Page 11: Software Installation
Software Installation MegaCam Manager Installation Place the CD into your CD-ROM and click on the MegaCam Manager Icon to begin the installation. If the CD does not automatically display, simply go to "Start" then "Run" and select the path "D:\Setup.exe". You may need to replace "D"... -
Page 12: Mode Selecting
Start MegaCam Manager The digital pictures can be transferred at all times, even if you take only one image. To connect your camera with your PC, you need a USB cable and USB port. Your camera double beeps when successfully connected with your PC. -
Page 13: Live View Mode
Live View Mode This mode allows you to view the camera in a Live View as a PC Camera, to record Video and take snapshots. The current view is displayed in the "preview" window. Live View Mode Record Snapshot Video Format Video Source Live preview = Press "Video Source"... -
Page 14: Dsc Mode
DSC Mode DSC Function (DSC Mode) Transfer images to the work area Transfer images to the album Create AVI file Send Mail Select All Delete Press the button to connect the camera and transfer photos. Press the button to transfer photos to the album. Press the button to create AVI file Open or close album Image... - Page 15 Transferring images to the work area Upload Update Transferring images to the Album Click a JPG/ BMP image or an AVI image . Then click " Transfer images to the album" button. Images are transferred from the work area to the album. To delete an image, select it and click "Delete".
- Page 16 Making AVI file Select JPG/BMP images and click " Make AVI file" icon to make an AVI file. It fails to make an AVI file while you select AVI images. Playing picture You can play any picture file you want by double clicking the picture icon to execute Slide window.
- Page 17 Slide Show Timer Playing Video You can play any video clip file (AVI format) you want by double clicking the AVI file icon to execute your default media application. Editing Photos Pictures can be edited in image editing software, such as PhotoShop, Imaging, CorelDraw, etc.
- Page 18 Album Delete Click the button. All the files you select in the album window are cleared forever. Therefore, you should be very careful with the delete button. Select All Click the button. You select all the files in the album window. Making Your Album Folders Click the button and key in your file name.
- Page 19 TWAIN Manager To start using the TWAIN Manager, simply click on the "Start" menu and go up to "Programs" Then go to the folder named "Imaging" and select it. How to enter TWAIN Manager Go to "File" and choose "select device" Choose "...
- Page 20 Mode Selecting DSC Mode Live View Live View Mode Press "Snapshot" button to capture an image Press "Snapshot" button to capture an image Press "Video Source" button to adjust advanced settings. Snapshot Transfer Transfer All Save AVI Setting...
- Page 21 DSC Mode Select an image and transfer it to the work area Select images and transfer it to the work area Select an AVI file and click "Save AVI" Press "Snapshot" button to capture an image 82-092-90060 V1.0...
