Summary of Contents for AIPTEK PocketCam PocketCam Classic

  • Page 1 My digital eye! English Digital Camera Installation Guide...
  • Page 2: Table Of Contents

    English Contents Contents Checklist System Requirements Specifications Operating Environment How to Use Your Digital Camera Switching the camera on Taking a picture Additional features Self Timer Continuous mode Clearing the stored images Changing the picture resolution How to Upload Photo & Video to PC Start Digital Camera Mode Selecting...
  • Page 3: Contents Checklist

    Contents Checklist 1.Digital Camera 3.Install Quick Guide 4.USB Cable NOTE: If you are missing any of these contents please inform your dealer or your nearest support office so that the contents can be replaced. 2.Application / Driver CD Driver & Application ..
  • Page 4: System Requirements

    English System Requirements Microsoft Windows 98 / ME / 2000 Pentinum 200 MHz (or equivalent) processor or higher 32 MB of RAM (64 MB recommended) Video card with 2 MB of RAM for minimum 16 bit (High Color) display 4X speed CD-ROM An available USB port Specifications Sensor type...
  • Page 5: How To Use Your Digital Camera

    How to Use Your Digital Camera Introduction The camera is capable of taking and storing VGA(640x480 Pixels) images or QVGA (320x240 Pixels) Images. These images may be uploaded to a PC via the USB port. User Interface The camera has two switches on it. SW1 is the shutter switch.
  • Page 6: Switching The Camera On

    English Pressing the SW2 when the LCD is blank will power on the camera. The camera will automatically power off after 30 seconds of inactivity. The LCD indicates the camera mode either "Lr" for low resolution (QVGA images) or "Hr" for high resolution(VGA images). The LCD then displays the number of pictures you have remaining.
  • Page 7: Self Timer

    Pressing the mode button until "St" appears in the LCD then pressing the shutter button will start a 10 second self-timer. The camera will issue a short beep every second and then a longer beep. The next beep indicates that the picture has been taken.
  • Page 8: Clearing The Stored Images

    English Clearing the stored images Press the mode button until CL appears on the LCD. Pressing the shutter button once will cause the camera to beep and the CL will start flashing . Pressing the shutter button again within 5 seconds will clear the camera and reset the picture counter.
  • Page 9: How To Upload Photo & Video To Pc

    How to Upload Photo & Video to PC Thank you for purchasing the through the steps of how to install the system. Digital Camera Place the CD into your CD-ROM and click on the Icon to begin the installation. If the CD does not automatically display, simply go to "Start"...
  • Page 10: Start Digital Camera Manager

    English Start Digital Camera Stored pictures may be uploaded to a PC at any time whether or not the camera is full. Plugging the USB connector into the camera will cause it to reset. A double beep will sound, but all stored pictures will remain. When the USB connector is unplugged the camera will switch off.
  • Page 11: Mode Selecting

    Mode Selecting Press the "Live View" button to switch the camera to PC Camera mode. Press the "DSC Function" button to switch the camera to DSC & Camcorder mode. In this mode, it is easy to attach the camera to your system, to use as a stand PC camera.
  • Page 12: Dsc Mode

    English Uploading Photos: This allows you to upload photos captured by the camera. Press the "Link" button to link up the camera and upload photo icons. < Press the "Folder" button to open the album folder window. > Press the "Transfer all" or "Transfer selected" button to transfer photos to the album folder.
  • Page 13: Editing Photos

    Editing Photos: It is easy to edit any photo you want in the album folder. Double click the photo icon to execute your default image application (such as Imaging, Paint...etc.) to edit your image file. Uploading Video: This takes advantage of the continuous mode. It is recommended that this be displayed in QVGA(low resolution mode).
  • Page 14: Avi Creator

    English AVI Creator: < Select Images you want to process into a video clip. Press "Setting" button to adjust fram rate. > Press "Fram Rate" button to create a AVI file saved in album folder. Playing Video: You can play any video clip file (AVI format) you want in album folder by double clicking the AVI file icon to execute your default media application.
  • Page 15: Image Processing

    Image processing: Click the "Image Process" button to select the image processing function you want. After pressing "OK" the selected image will be processed using the checked function. Image Process Mail Function: Click the "Mail" button to attach seleted image files automatically to a new email document.
  • Page 16: Troubleshooting

    English Troubleshooting Install step missed - Most of the problems associated with using the camera have to do with the fact that the end-user accidentally skips a step during installation. Solution: Uninstall the camera, and reinstall it, making sure to follow each step of the Quick Install Guide. USB ports not enabled in the BIOS - Even after following the Quick Install Guide completely, the camera still does not work.
