- Page 1 Owner’s Manual CASSETTE MULTIZONE HEAT PUMP INVERTER 12 000 to 24 000 BTU/hr Models: CCD12KCHVS-I CCD18KCHVS-I CCD24KCHVS-I Please read this owner’s manual carefully before operating the unit and keep it for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Operation notices .................................3 Explanation of symbols ................................3 User notices....................................4 Precautions....................................4 Working temperature range ...............................6 Parts name ....................................7 Remote control ..................................8 User notices....................................8 Buttons on remote control ..............................9 Icon identification on remote control display ......................9 Operation of remote control ............................ -
Page 3: Operation Notices
OPERATION NOTICES EXPLANATION OF SYMBOLS Indicates a hazardous situation that, if not avoided, DANGER will result in serious injury or death. Indicates a hazardous situation that, if not avoided, WARNING could result in serious injury or death. Indicates a hazardous situation that, if not avoided, CAUTION may result in minor or moderate injury. -
Page 4: User Notices
USER NOTICES • The total capacity of the indoor units running at the same time cannot exceed 150% of the outdoor unit capacity. Otherwise, the cooling or heating effect of each indoor unit will be poor. • To ensure a successful startup, switch the main power on 8 hours before powering on the unit. •... - Page 5 • Do not repair the appliance by yourself. It may cause electric shock or damage. Please contact a qualified person when you need to repair it. • Do not extend fingers or objects into air inlet or air outlet. It may cause personal injury or damage. •...
-
Page 6: Working Temperature Range
• The appliance shall be installed in accordance with national wiring regulations. • Installation must be performed in accordance with the requirement of NEC and CEC by a qualified person only. • The heat pump is a first class electric appliance. It must be properly grounded with specialized groun- ding device by a qualified person. -
Page 7: Parts Name
PARTS NAME Actual product may be different from below graphics, please refer to actual product NOTICE for reference purposes. Indoor unit Drainage equipment (inside type) Discharge condensate water from indoor unit when cooling Drainage hose Guide louvre (placed in air outlet vent) Air outlet vent Connecting pipe Air filter, purifier... -
Page 8: Remote Control
REMOTE CONTROL USER NOTICES CAUTION • The distance between the remote control and receiving window should not be more than 26.25 ft. (8 m) and there should be no obstacle between them • The remote control should be placed 3.3 ft. (1 m) away from TV or Audio sets. •... -
Page 9: Buttons On Remote Control
BUTTONS ON REMOTE CONTROL No. Bouton Fonction ON/OFF Turn on or off the unit Set temperature and time Set fan speed MODE Set operation mode I FEEL Use of the remote control as ambient sensor Not available on models presented in this HEALTH manual Not available on models presented in this... -
Page 10: Operation Of Remote Control
OPERATION OF REMOTE CONTROL 1. ON/OFF button Pushing this button allows to turn on or off the device. When turning off the unit, the SLEEP function will be canceled but the pre-set time remains. 2. +/- button Push " + " or " - " button to decrease or increase temperature by one degree at a time. Temperature range is from 16 °C to 30 °C (61 °F to 86 °F). - Page 11 FAN mode: When you select FAN mode, only the fan is operating. There is no heating, nor cooling in this mode. HEAT mode: When you select HEAT mode, device is working on heating mode. Press the " + " or " - " button to adjust temperature.
- Page 12 • When selecting " ", device blows at fixed position. Horizontal louvre will be at fixed angle. • Hold the SWING button for 2 seconds to define required oscillating angle. When reached, release the button. NOTE: " " may not be available. When device receives this signal, it will function as per following position "...
-
Page 13: Special Functions
13. TURBO button When TURBO function is on, the unit operates at super high speed to achieve quick cooling or heating. This function is available only in COOL (cooling) or HEAT (heating) mode. When you press this button, icon " "... -
Page 14: Replacement Of Batteries In Remote Control
REPLACING BATTERIES IN REMOTE CONTROL 1. Lightly press the " " and slide in the direction the arrow is pointing to remove the back cover of the remote control (as illustrated). 2. Remove the old batteries (as illustrated). 3. Insert two new " AAA " (1.5 V) dry batteries and make sure the position of + and –... -
Page 15: Preparation Before Installation
PREPARATION BEFORE INSTALLATIONN REQUIRED INSTALLATION CLEARANCE DISTANCES DIAGRAM Ceiling Wall Wall surface ≥59” surface (1500 mm) ≥59” (1500 mm) Ground surface SELECTION OF INSTALLATION LOCATION Basic requirements Installing the unit in the following places may cause malfunction. If it is unavoidable, please consult a qualified person: •... -
Page 16: Requirements For Electrical Connection
• The power cords and connection lines of the indoor and outdoor units must be at least 3.3 ft. (1 m) away from the TV set or radio to avoid image interference and noise (even if the clearance distance is kept, noise may be produced due to strong electromagnetic wave). Indoor unit •... -
Page 17: Installation
(refrigerant pipe, drain pipe) and wiring (wires of the wired controller, wires between the indoor and outdoor unit) to make the further installation steps much easier. DIMENSION OF CEILING OPENING AND LOCATION OF HOISTING SCREW M10 CCD12KCHVS-I & CCD18KCHVS-I 650 mm 570 mm 400 mm... - Page 18 CCD24KCHVS-I Refrigerant pipe Hoisting screw (X4) 680 mm (Gaps between hoisting screw rods) 840 mm ( Indoor unit) 890 mm (Ceiling opening) 950 mm (Decorated surface boards) *This dimension could be as large as 910 mm as long as the overlapping section of the ceiling and the decorated surface boards is no less than 20 mm.
- Page 19 Step 2: Install installation template Bolt of one of the angle of outlet pipe is fixed on the angle of the drainage slot Center of • Refer to the installation template provided the ceiling Installation template with the unit for dimension of ceiling ope- opening ning.
-
Page 20: Installation Of Drain Pipe
INSTALLATION OF DRAIN PIPE • The diameter of the drain pipe should be larger than or equal to that of the refrigerant pipe. (PVC pipe, outer diameter: 1 in. (25 mm), wall thickness ≥ 1/16 in. (1.5 mm)). 3.3-4.9' (1-1.5 m) •... -
Page 21: Test Of Drainaige System
• If multiple drain pipes converge, follow the installation steps below. ≥4" T-tie in join drain hose (100 mm) The specification of the drain pipe joint should be suitable to the running capacity of the unit. TEST OF DRAINAGE SYSTEM •... -
Page 22: Insulation Of Refrigerant Pipe
open-end wrench Tightening torque Hex nut diameter (N-m) union nut 15~20 Φ 6 30~40 Φ 9.52 pipe torque wrench 45~55 Φ 12 60~65 Φ 16 70~75 Φ 19 indoor pipe • Wrap the indoor pipe and joint of connection pipe with insulating pipe, and then wrap it with tape. -
Page 23: Electrical Connection
ELECTRICAL CONNECTION NOTE: All indoor units must be connected to the outdoor unit. • Open the electric box cover (1), drag the communication wire from rubber plug A and fix them indivi- dually with wire clamps. • Prior to the wiring, please check the voltage marked on the nameplate and then carry out the wiring following the wiring diagram. -
Page 24: Installation Of The Front Panel
INSTALLATION OF THE FRONT PANEL 1. Adjust the panel to the housing of the indoor unit by matching the position of the swing flap motor of the panel to the piping position of the housing. See image below. 2. Install the panel on the housing temporarily. When installing, hang the latches on the hooks located on the opposite side of the panel swing flap motor (2 positions). - Page 25 NOTE: Improper screwing of the screws may cause the troubles shown below. Air leak Air leak from ceiling Water condensation, water drop • If there is still a gap between the ceiling and the decorative panel after tightening the screws, readjust the height of the indoor unit, as show below.
-
Page 26: Malfunction
MALFUNCTION MALFUNCTION ANALYSIS Please check below items before asking for servicing. If the malfunction still cannot be eliminated, please contact a qualified person. Phenomenon Items to check Solution Ask a qualified person to replace circuit Circuit break trips off? break. Is there a power failure? Wait until power resumes. -
Page 27: Maintenance
MAINTENANCE CLEANING AND MAINTENANCE WARNING • Turn off the unit and disconnect the power before cleaning to avoid electric shock. • Do not wash the unit with water to avoid electric shock. • Do not use volatile liquid or mineral oils to clean the unit. •... - Page 28 Step 1: Open air inlet grille • Loosen 2 screws on the air inlet grille with a screw- driver. • Pull the 2 handles on the air inlet grille simultaneously in the direction indicated by the arrows. Step 2: Disassemble the air filter •...
-
Page 29: Cleaning Air Inlet Grille
CLEANING AIR INLET GRILLE • Open air inlet grille (See step 1 of CLEANING THE FILTER section) • Remove the air filter (See step 2 of CLEANING THE FILTER section) • Take out the air inlet grille. Open air inlet grille at a 45°... - Page 30 NOTES _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________...
