Owner’s Manual CONSOLE MULTIZONE HEAT PUMP INVERTER 9 000 to 12 000 BTU/hr Models: CMD09KCHVS-I CMD12KCHVS-I Please read this owner’s manual carefully before operating the unit and keep it for future reference.
TABLE DES MATIÈRES Operation notices .................................3 Explanation of symbols ................................3 User notices....................................4 Precautions....................................4 Parts name ....................................7 Indoor unit screen display ..............................8 Remote control ..................................9 Buttons on remote control ..............................9 Icon identification on remote control display ......................9 Operation of remote control ............................
OPERATION NOTICES EXPLANATION OF SYMBOLS Indicates a hazardous situation that, if not avoided, DANGER will result in serious injury or death. Indicates a hazardous situation that, if not avoided, WARNING could result in serious injury or death. Indicates a hazardous situation that, if not avoided, CAUTION may result in minor or moderate injury.
USER NOTICES • The total capacity of the indoor units running at the same time cannot exceed 150% of the outdoor unit capacity. Otherwise, the cooling or heating effect of each indoor unit will be poor. • To ensure a successful startup, switch the main power on 8 hours before powering on the unit. •...
Page 5
• Do not repair the appliance by yourself. It may cause electric shock or damage. Please contact a qualified person when you need to repair it. • Do not extend fingers or objects into air inlet or air outlet. It may cause personal injury or damage. •...
Page 6
• The appliance shall be installed in accordance with national wiring regulations. • Installation must be performed in accordance with the requirement of NEC and CEC by a qualified person only. • The heat pump is a first class electric appliance. It must be properly grounded with specialized groun- ding device by a qualified person.
PARTS NAME Actual product may be different from below graphics, please refer to actual product NOTICE for reference purposes. Indoor unit Titanium apatite photocatalytic air-purifying filter Air outlet Flap (horizontal blade) Air filter Front panel Air outlet Louvres (vertical blades - Air inlet inside the air outlet) Remote Control...
INDOOR UNIT SCREEN DISPLAY Actual product may be different from below graphics, please refer to actual product NOTICE for reference purposes. LED display COOL mode LED indicator DRY mode LED indicator HEAT mode LED indicator Power LED indicator Indoor unit Receiving ON/OFF button window...
REMOTE CONTROL BUTTONS ON REMOTE CONTROL Button Function ON/OFF Turn on or off the unit - / + Set temperature and time MODE Set operation mode Set fan speed SWING Set fan oscillating angle I FEEL Use of the remote control as ambient sensor Not available on models presented in this manual Lowering or raising the temperature gradual-...
OPERATION OF REMOTE CONTROL NOTES: • This is a general remote control that could be used for multifunction appliances. If you push a button which is not featured on the model, the unit will continue to work as is. • After powering it, the device will beep. Working indicator " "...
Page 11
DRY mode: When you select DRY mode, the appliance is in dehumidifying mode and works at its lowest speed. In this mode, the fan speed can’t be changed.. FAN mode: When you select FAN mode, only the fan is operating. There is no heating, nor cooling in this mode. HEAT mode: When you select HEAT mode, device is working on heating mode.
Page 12
6. I FEEL button Press this button to activate I FEEL function and the icon " " will appear on remote control. Once this function is settled, remote control sends the information about room temperature to the control panel and will adjust automatically. Press again this button to cancel I FEEL function and the icon disappears. Please put remote control near the user when this function is chosen.
Page 13
Initial temperature setting between 21 °C to 27 °C (69 °F to 81 °F): Temperature setting will be decreased of 1 °C (1 °F or 2 °F) every hour up to 2 °C (3 °F or 4 °F) and will be maintained for the duration of the SLEEP mode.
Page 14
11. CLOCK button Press this button to set time. Icon " " on remote control will blink. Within the next 5 seconds, press button " + " or " - " to set time. With every push on the button " + " or " - ", time increases or decreases by one minute.
SPECIAL FUNCTIONS Child lock function This function eliminates unwanted temperature adjustments and the use of different modes on the device. Before activating it, make sure to have set the temperature as you like. Press simultaneously " + " and " - " buttons to activate or deactivate the child lock function. When that function is activated, icon "...
Page 16
REPLACING BATTERIES IN REMOTE CONTROL 1. Lightly press the " " and slide in the direction the arrow is pointing to remove the back cover of the remote control (as illustrated). 2. Remove the old batteries (as illustrated). 3. Insert two new " AAA " (1.5 V) dry batteries and make sure the position of + and –...
PREPARATION BEFORE INSTALLATION INDOOR UNIT INSTALLATION DRAWING The indoor unit may be mounted in three different ways: Exposed Half conceated Concealed Mounting plate Grid (field supply) Floor lnstallation Wall Installation REQUIRED INSTALLATION CLEARANCE DISTANCES DIAGRAM 59"(150 cm) or more 59"(150 cm) or more 59"(150 cm) or more...
SELECTION OF INSTALLATION LOCATION Basic requirements Installing the unit in the following places may cause malfunction. If it is unavoidable, please consult a qualified person: • A place with strong heat sources, vapors, flammable or explosive gas or volatile objects spread in the air.
REQUIREMENTS FOR ELECTRICAL CONNECTION Safety precautions • You must follow the electric safety regulations when installing the unit. • According to the local safety regulations, use qualified power supply circuit and circuit break. • Make sure the power supply matches with the requirement of the device. Unstable power supply or incorrect wiring may cause malfunction and damage the unit or fire hazard.
INSTALLATION INSTALLATION OF INDOOR UNIT Step 1: Install wall-mounting plate (for surface wall installation only) CAUTION The mounting plate should be installed on a wall which can support the weight of the indoor unit. • Referring to drawings below, temporarily secure the mounting plate to the wall; adjust it in horizontal position with the level meter and then point out the screw fixing holes on the wall.
Page 21
Step 2: Open piping hole • Choose the position of piping hole according to the direction of outlet pipe. • Open a piping hole with a diameter of 55 mm in the spot indicated by the symbol “ “ as illustrated below.
Page 22
CAUTION • The suggested shortest pipe length is 8.2 ft. (2.5 m), in order to avoid noise and vibration from the outdoor unit. (Mechanical noise and vibration may occur depending on how the unit is installed and the environment in which it is used.) •...
Page 23
Step 4: Test drainage system • Remove the air filters and pour some water into the drain pan to check if water flow goes through the pipe correctly and observe carefully the joint to see if it leaks or not. Step 5: Connect the pipe of indoor unit Coat here with refrigeration oil •...
Page 24
Step 6: Insulation of refrigerant pipe • Refrigerant gas pipe surface temperature can reach 110 °C. Make sure the chosen insulation material can withstand this temperature. • Insulating pipe should be made of polyethylene foam with a heat transfer rate of 0.041 to 0.052W/mK (0.035 to 0.045kca/(mh°C).
Page 25
NOTES: • All wires of indoor and outdoor unit should be connected by a qualified person. • If the length of power connection wire is insufficient, please contact your dealer for a new one. Do not extend the wire by yourself. •...
Page 26
3 tabs Upper casing Casing Front grille Front Side casings panel Remove Side front grille casings Open the front panel Remove 4 screws Remove the pillar Remove 7 screws Bottom frame Casing Casing Remove the pillar Remove the pillar • Put the bound pipes in the wall pipe and then make them pass through the wall hole. •...
MALFUNCTION MALFUNCTION ANALYSIS Please check below items before asking for servicing. If the malfunction still cannot be eliminated, please contact a qualified person. Phenomenon Items to check Solution Ask a qualified person to replace circuit Circuit break trips off? break. Is there a power failure? Wait until power resumes.
MAINTENANCE CLEANING AND MAINTENANCE WARNING • Turn off the unit and disconnect the power before cleaning to avoid electric shock. • Do not wash the unit with water to avoid electric shock. • Do not use volatile liquid or mineral oils to clean the unit. •...
CLEANING THE FRONT PANEL Step 1: Open the front panel • Slide the two stoppers on the left and right sides inward until you hear a “click”. Step 2: Remove the front panel String • Remove the string to allow the front panel to fall forward.
CLEANING THE FILTER The air filter absorbs CO, CO2, benzene, aldehydes, odor of gasoline, etc. It will absorb poisonous material in the air that is smaller than 1 μm, such as dust, pollen, bacteria and virus. NOTES: • Never dismantle the air filter except for cleaning; otherwise it may cause some error. •...
Page 31
NOTES : • Do not remove the air purifiers from their frame when cleaning with water. • After washing, shake off remaining water and dry in a cool and shady place. • Since the purifiers are made out of paper, do not wring out the filter when removing water from it. Step 5: Install the air purifiers and air filter •...
OPERATION TEST 1. Before operation test • Ensure that the customer is satisfied. • Inform the customers about the important notes of the appliance. 2. Operation test • Put through the power, press the ON/OFF button on the remote control to start the unit. •...
