2.3 Control Terminal Connection

Name
Battery +
PV+ / Load +
PV—/Load—
Battery—
Earth
Dip Switch 1
Dip Switch 2, 3
Dip Switch 4, 5, 6
Dip Switch 7
Dip Switch 8
VR1, VR2
BCD Switch 0
BCD 1~A
BCD B~F
Communication IN
Communication OUT
BTS+
BTS—
Battery cable Positive connection
Connecting terminal for Solar Array or DC Load Positive
Connecting terminal for Solar Array or DC Load Negative
Battery cable Negative connection
Connecting terminal for Ground
ON or OFF to choose battery charge control mode or load control
mode
Selection of battery voltage for 12V or 24V or 48V system
Battery charge control mode: Battery charging algorithm
Load control mode: Load control disconnect/reconnect algorithm
Battery charge control mode: Auto / Manual Equalization
Load control mode: Auto / Manual Reconnect
ON: Potentiometer of VR1, VR2 setting range
OFF: Dip switch 4~6 setting range
User define battery charging programs or user define standard low
voltage disconnect and reconnect
SunStar unit is operating alone.
*When the BCD Switch is not placed at 0 and the fault message of
" Alarm: CPF01 Wait for Combi" will be displayed if the SunStar unit
is not communicating with CombiPlus/SuperCombi
st
th
1
~10
SunStar units are communicating with CombiPlus
/SuperCombi
They are operating as the 10
Communication port for CombiPlus/SuperCombi
Communication port for the next SunStar unit
Connecting terminal for Battery Temperature Sensor Positive
Connecting terminal for Battery Temperature Sensor Negative
2-2
Description
th
SunStar unit
