SETTINGS
A
Device Status
Manages device connection status. All listed devices can be connected or disconnected by selecting or clearing the check box
next to the name of each device.
Exposure Settings
B
Allows users to adjust an exposure value.
A scan that shows a lot of red is over-exposed, and a scan that shows a lot of blue and black is under-exposed. This option is
linked with the Exposure option in the Scan menu.
Under-Exposed
Resolution
C
Adjusts the resolutions of scanners.
High
•
– Constructs a high-density mesh (1/1 capture ratio).
Medium
•
– Constructs a medium-density mesh (1/4 capture ratio).
•
Low
– Constructs a low-density mesh (1/9 capture ratio).
3D Systems, Inc.
Over-Exposed
19
Optimal
