3. Go to the Advanced Options by clicking
4. In the Device Status, check the connection status of the selected scanner if it says
OK.
Note: If there is a network conflict issue with the scanner, in the Network
Configuration section, click
Option 2: Manual Configuration
If there is an issue with network connection or you need to set a static IP address for your scanner, you must use the manual
configuration.
1. In the Device Status, select the desired scanner.
2. In the Network Configuration, clear the
the Apply button.
3. Enter values for the IP address, subnet mask, and default gateway.
4. Click Apply to apply all changes.
Note: If you use a network hub to connect multiple devices at a common
connection point in a network, the IP address of the network adapter in your
PC should be the same as a default gateway of the device and the subnet
mask of the network adapter should be the same as the subnet mask of the
device. For example, if the IP address and subnet mask of your PC's network
adapter is 192.168.61.1
same as in your PC,
However, if you use a router for your network connection, the default gateway and subnet mask of all connected
devices including your PC should follow the IP address and subnet mask of your router.
The IP address of a PC's network adapter can be checked in the properties of your local network.
To access the TCP/IPv4 properties in Windows™, perform the following steps:
a) On the Windows Start menu, click
b) Under Network and
network status and
c) In the left pane, click
settings.
Local Area
d) Right-click
Properties.
3D Systems, Inc.
Advanced Options
Auto Configure to reconfigure the network.
Use DHCP
and 255.255.255.0, the default gateway and subnet mask address of the device should be the
192.168.61.1 and 255.255.255.0.
Control Panel.
Internet, click View
tasks.
Change adapter
Connection, then click
to check the network configurations.
check box located just above
