e) In the Local Area Connection Properties dialog, select
f) Make sure that all the addresses are configured properly.
When you use a network hub to connect multiple devices at a common connection
point in a network, the following settings are recommended for the network
adapter:
g) Finally, click OK
Updating Device Firmwares
Geomagic Capture includes the latest device firmware for the Geomagic Capture Series 3D scanner. If the scanner firmware is
incompatible, a message will appear when the application is started up. You can simply update the device firmware by clicking
the message.
Note: If there is an issue with updating the device firmware, you must use the manual device firmware update to control
scanners.
a) Go to Settings by clicking
b) Click Update....
c) Windows Explorer will be initiated. Find a
• For Geomagic Capture for SolidWorks / Geomagic Capture for SpaceClaim / Geomagic Design Direct / Geomagic Con-
trol / Geomagic Studio / Geomagic Wrap: ~<Product Installation Path>\capture\hardware\Geomagic Capture\driver\Scanner
Modules\Gocator
• For Geomagic Design X / Geomagic Verify / Geomagic XOS: ~<Product Installation Path>\bin\GeomagicCapture\bin\driver\
Scanner Modules\Gocator
d) Select the file and click Open. The update will take a couple of minutes to complete.
3D Systems, Inc.
to accept the changes.
Settings to manually update the firmware.
upgrade.dat file
Internet Protocol Version 4
at:
10
(TCP/IPv4), and then click Properties.
OK
in
