Operation and Service Guide: Showers
P.O. Box 309 • Menomonee Falls, WI 53052-0309
1.800.BRADLEY • 1.262.251.6000 • bradleycorp.com
WS-1X Showerheads
154-139 Arm
110-115 Nut
269-1679WE15 Head
WS-1X Basic Showerhead S24-172WE15
154-139 Arm
110-115 Nut
153-117 Adaptor
*Add suffix WE15 for 1.5 GPM Flow.
S24-008 Head
Add suffix WE20 for 2.0 GPM Flow
(Example: S24-173WE15 or S24-173WE20)
Standard Institutional Showerhead S24-173 *
154-139 Arm
110-115 Nut
153-117 Adaptor
S54-002 LBJ
S24-008 Head
Standard Institutional Showerhead
with Lockable Ball Joint S24-174 *
Bradley • 215-1369-19A Rev. G: ECN 17-03-015
1 of 2
Advertisement
Related Manuals for Bradley WS-1X
Summary of Contents for Bradley WS-1X
- Page 1 Add suffix WE20 for 2.0 GPM Flow (Example: S24-173WE15 or S24-173WE20) Standard Institutional Showerhead S24-173 * 154-139 Arm 110-115 Nut 153-117 Adaptor S54-002 LBJ S24-008 Head Standard Institutional Showerhead with Lockable Ball Joint S24-174 * Bradley • 215-1369-19A Rev. G: ECN 17-03-015 1 of 2...
- Page 2 Lockable Ball Joint (S-LBJ) S24-174WE20 2.0 gpm (7.6 L/min) 1.7 gpm (6.6 L/min) * 2.5 GPM flow rate does not meet California Energy Commission 20 CCR T.20, Div. 2, 1601-1609. Bradley • 215-1369-19A Rev. G: ECN 17-03-015 2 of 2...
