- Page 1 Original Instructi nG3LB Tool – Instruction Manual Supplement. This must accompany the Manual (07900-00930) for the STD Genesis® nG3 tool nG3LB Tool Hydro-Pneumatic Power Tool...
-
Page 2: Intent Of Use
Intent of Use The Genesis® nG tool must “only” be used for placing 3/16” & 1/4” NeoBolt® as outlined in “Tool setting guide – Small diameter NeoBolt®: (07900-01071 GB) Tool Specification Air Pressure Minimum - Maximum 5-7 bar Free Air Volume Required @ 5.5 bar 4.3 litres Stroke... -
Page 3: General Assembly
General Assembly Base Tool – 71256-02000 ® View Shows ¼” NeoBolt nose equipment (not supplied as standard) Parts List nG3LB NEOBOLT PLACING TOOL VARIANT PARTS LIST PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION 71256-02001 BODY MACHINED 07007-02136 SPRING 07003-00472 O-RING 71256-02006 LOCK NUT 71256-02003... - Page 4 Stroke Information The diagrams below show the minimum and maximum stroke conditions when rotating the adjusting nut 8. When the adjusting nut is unscrewed beyond the maximum allowable stroke, air will start to leak from the rear of the adjusting nut. Do not use the tool if the air leaks from the tool.
- Page 5 Fitting Procedure – 3/16” NeoBolt Nose Equipment When placing 3/16” NeoBolt, a spacer is required to reduce the stroke of the tool. Spacer part number 71256-02011. To fit spacer, follow procedure below: Remove adjusting nut 8 Unscrew Nyloc nut 9 Unscrew adjusting stop 10 Fit 3/16”...
- Page 6 Data shown is subject to change without prior notice as a result of continuous product development and improvement policy. Your local STANLEY Engineered Fastening representative is at your disposal should you need to confirm latest information.
