  • Page 1 TPMS Lite Installation Guide ST542119-002 TPMS Lite Installation Guide Sensor Installation Antenna Installation Configuration Software Display Gauge CAN Message Formats Troubleshooting...
  • Page 2 TPMS Lite Installation Guide ST542119-002 This page intentionally left blank.
  • Page 3: Tools Required

    TPMS Lite Installation Guide ST542119-002 1. TPMS Lite Sensor Installation _________________________________________________________ Tools Required The following tools will be required for the fitting process: Torx (R) T20 Screwdriver /Torque driver (RS 662-608, DemonTweeks BIKTORXKEY) 4Nm Torque screwdriver ¼” Drive (e.g. Teng Tools 1492SD) 11mm x 50mm Socket (e.g.
  • Page 4 TPMS Lite Installation Guide ST542119-002 Valve Fitting Ensure the wheel rim is cleaned and degreased around the valve and wheel well (Green area). Insert valve into wheel rim. Fit the spacer ring (D) and then the collar nut (E) finger tight.
  • Page 5 TPMS Lite Installation Guide ST542119-002 Insert the installation bar (G) into the valve body and tighten the collar nut (E) to a torque of 4Nm +/-0.5Nm Press the sensor down into the wheel well so that base of the sensor is touching the rim.
  • Page 6 TPMS Lite Installation Guide ST542119-002 Tighten the Torx screw (A) to 4Nm +/- 0.5N Once tightened check the sensor is still in contact with the rim.
  • Page 7 TPMS Lite Installation Guide ST542119-002 The sensor is now fitted correctly to the rim and ready for the tyre mounting. NOTE: It is recommended to fit some identifying mark on the outside of the tyre to indicate the rim is fitted with a TPMS sensor. This will alert tyre fitters to the fact there is a sensor...
  • Page 8 TPMS Lite Installation Guide ST542119-002 Incorrect Fitting Examples The following are examples of bad fitment that will degrade the performance of the system: Sensor not in contact with rim. Sensor antenna pointing away from wheel centre and sensor base not...
  • Page 9: Antenna Details

    Antenna Details The Stack TPMS antenna is an advanced Dual-Band Antenna (DBA). For optimum system performance, care should be taken to fit the antennas according to the guidelines in this document. The system performance can be impaired with poor antenna placement.
  • Page 10 TPMS Lite Installation Guide ST542119-002 The antenna must be mounted radially from the centre of the tyre. The Ground plane can point towards or away from the centre of the wheel. The antenna can be mounted behind NON conductive panels (Kevlar, GRP) In a typical installation you will achieve 90-120deg of RFID coverage and 270 degrees of SAW coverage.
  • Page 11 TPMS Lite Installation Guide ST542119-002 The SAW_Strength and RFID_Strength indicators can be used to tune the antenna position. Antenna Placement The antenna installation is normally done in several parts. The first is to choose an initial location for the antenna based on the above guidelines and measure the signal strength during a complete wheel rotation.
  • Page 12 TPMS Lite Installation Guide ST542119-002 Antenna Placement Restrictions If you have to mount the antenna to a conductive surface (metal, carbon) then you MUST space it off the surface by 10mm. Dual lock is ideal for this. Should you have to mount the antenna behind a conduction surface then please ensure that you cut a window for the antenna that is the same as the dimensions below.
  • Page 13 Keeping a hard copy log during antenna installation is a useful way of capturing the data in the field but can also be helpful in aiding a Stack engineer diagnose possible problems with an installation. A sample log may look like this:...
  • Page 14 TPMS Lite Installation Guide ST542119-002...
  • Page 15: System Requirements

    TPMS Lite Installation Guide ST542119-002 3. TPMS Lite Configuration Software Set-up _________________________________________________________ Introduction This guide will describe the TPMS configuration software and how to use the features in it. This software can be used to configure the TPMS control unit and to monitor the values in real time being measured.
  • Page 16 TPMS Lite Installation Guide ST542119-002 Serial (COM) Select the port you have connected the TPMS Control unit to and press the Connect button. If the connection is made to the box the program will display to the Information Tab and display the information for the unit. To confirm a connection has been...
  • Page 17: Can Configuration

    TPMS Lite Installation Guide ST542119-002 Read Config Read Config Config Status CAN Configuration The TPMS interrogator has a fully configurable CAN bus output. This is used to send data to the TPMS gauge and can also be used to connect the system to a data logger.
  • Page 18: Real-Time Monitoring

    TPMS Lite Installation Guide ST542119-002 CAN Receive ID The TPMS interrogator can receive data over the CAN bus. Display Fitted Unchecking this option stops the TPMS interrogator sending the CAN messages to the gauge. This is useful if the gauge CAN IDs are taken by another device on the system and should not be sent out by the TPMS interrogator.
  • Page 19 TPMS Lite Installation Guide ST542119-002 The Monitor window displays the values from each of the 4 wheels. The monitored parameters are listed below. Parameter Range Optimum Description Pressure 0-320psi Measured pressure Temperature 0-320DegC Measured temperature System Status Green No Sensor Detected...
  • Page 20 Importing Sensors The TPMS Lite system allows for 3 sets of wheels to be configured. Each set can contain up to 4 sensors. The sensors need to be imported to the TPMS sensor library before being configured for use in the box.
  • Page 21 TPMS Lite Installation Guide ST542119-002 The configuration utility will scan the directory and list the sensors that are available for importing. You can identify the sensors you have by looking at each sensor’s individual label which has its id printed on it.
  • Page 22 TPMS Lite Installation Guide ST542119-002 Select All Import To export the pincode library click the export button, select the directory to export the pincode files too, select the files required and click Export. The files will be saved in the directory specified...
  • Page 23 TPMS Lite Installation Guide ST542119-002 The sensors that have valid imported PIN codes will now be listed. Unchecked Black text = Pincode Valid not authorised in the interrogator Checked Black text = Pincode valid and authorised in the interrogator Checked Red text = Sensor authorised in interrogator but no valid pincode in library Select each sensor by ticking the checkbox next to the sensor id.
  • Page 24 TPMS Lite Installation Guide ST542119-002 Set Configuration Selected Set To assign a sensor to a set, click on the corner and a drop down of the sensors that are authorised will appear. Select the sensor required for this corner. Note: The configuration software will only allow valid sensor assignments, for example it is not possible to select the same sensor in the same wheel set.
  • Page 25: Misc. Options

    TPMS Lite Installation Guide ST542119-002 The wheel set configuration can be written to the box by pressing the write config button. Misc. Options The “misc.” options allow the user to configure the way the atmospheric compensation and out of range values are handled by the interrogator.
  • Page 26 TPMS Lite Installation Guide ST542119-002 Atmospheric Adjust Out-Of-Range Adjust...
  • Page 27: Connection And Setup

    The TPMS display gauge has been designed to display pressure and temperature data in real-time from a Stack TPMS system. The gauge allows you to set alarms and parameters to alert you to tyre problems while the vehicle is running on track.
  • Page 28 TPMS Lite Installation Guide ST542119-002 Gauge Layout Numeric display Pressure Status Temperature Status Corner Indicators Switches The gauge has been designed to provide a clear and simple view of the status of the tyres on the vehicle. There is also a numeric display which can display any of the pressures or temperatures required for more in depth information.
  • Page 29 TPMS Lite Installation Guide ST542119-002 Corner Indicators In normal operation the gauge will display the status of the tyres via 4 LEDS on each “corner” of the gauge. These corners are positioned on the dial to reflect the real life position of the wheels on the vehicle this allows for quick “at a glance”...
  • Page 30: Acknowledging Alarms

    TPMS Lite Installation Guide ST542119-002 Alarms The gauge features a configurable pressure and temperature thresholds for each of the wheels. There is an upper and lower pressure limit and an upper and lower temperature threshold. The wheels are constantly monitored to see if they fall outside these thresholds. If they do the gauge will display an alarm.
  • Page 31: Menu Descriptions

    TPMS Lite Installation Guide ST542119-002 Menu Descriptions  – Scroll Mode This sets the way the gauge scrolls round the temperature and pressure values that are displayed on the numeric display. The options are as follows: Scroll Order Mode ...
  • Page 32 TPMS Lite Installation Guide ST542119-002  - Gauge Threshold Type The gauge thresholds can be setup to work in two different ways.  - (Single) in this mode all wheels are compared against a single pressure band and a single temperature band.
  • Page 33 TPMS Lite Installation Guide ST542119-002  - Pressure Units The pressure units can be selected as either PSI or Bar. To change the menu option, press the switch on the gauge to cycle through them. To select the new option press the switch on the gauge.
  • Page 34 TPMS Lite Installation Guide ST542119-002  – Switch 2 Function Switch 2 can be configured for 3 functions.  – Illumination Level Pressing switch 2 will cycle through the 4 brightness levels for the gauge.  – Illumination Toggle Switch 2 can now be a toggle switch or vehicle input and will toggle between High brightness and Low brightness.
  • Page 35 Wheel Set Selection The TPMS lite system has 3 wheel sets which can be configured. The driver will be able to set which set the interrogator will read and scale the data for. This will be done by setting the  menu to  and then pressing external switch 2 momentarily to change the set number.
  • Page 36 TPMS Lite Installation Guide ST542119-002 5. TPMS Lite Control Unit CAN Message Format _________________________________________________________ Background This section will describe the CAN message format for the TPMS control unit. CAN Transmit Message Format The TPMS control unit outputs the following CAN messages:...
  • Page 37 TPMS Lite Installation Guide ST542119-002 CAN Receive Message Format The TPMS interrogator can receive CAN messages to control some parameters Byte Byte Byte Byte Byte Byte Byte4 Byte6 Atmospheric Pressure Moving Moving CAN ID Car Speed (mb) Spare Mode Spare...
  • Page 38 TPMS Lite Installation Guide ST542119-002 6. TPMS Installation Troubleshooting _______________________________________________________ Issue Possible Solution Action Needed SensorID allocated to wrong Assign sensor to correct corner. Sensor readings corner in interrogator. incorrect. Sensor is damaged. Send back? Atmospheric pressure Set correct pressure or set to compensation set to wrong 1013 for no compensation.
  • Page 39 Stack® is a registered trademark of Stack Limited. Information in this publication is subject to change without notice and does not represent a commitment on the part of Stack Limited. No responsibility is accepted for error or omission. Copyright © 2011 Stack Limited...
