Installation Instructions P D - V 8
1) Provide 5V DC on pad 1 (4.75V-5.25V)
2) Provide DC ground onto PAD3
3) Connect PAD 2 (IF) to the µPC for signal processing
4) Operating temperature: -10-70° C
PAD1
PAD2
PAD3
The use of the transceiver is authorized into mobile or fixed devices taking into
account the conditions listed below :
• OEM Integrator may be sure that the end user manual may not contain any
information about the way to install or remove the module from the final
product.
Microwave Sensor
Advertisement
Table of Contents
Related Manuals for Stack PD-V8
Summary of Contents for Stack PD-V8
- Page 1 Installation Instructions P D - V 8 Microwave Sensor 1) Provide 5V DC on pad 1 (4.75V-5.25V) 2) Provide DC ground onto PAD3 3) Connect PAD 2 (IF) to the µPC for signal processing 4) Operating temperature: -10-70° C PAD1 PAD2 PAD3 The use of the transceiver is authorized into mobile or fixed devices taking into...
- Page 2 • The antenna of the module may not be removed, replaced nor modified. The antenna must not be co-located or operating in conjunction with any other antenna or transmitter. No additional antenna must be used. Microwave Sensor Microwave Sensor IC:20845-STACK102 IC:20845-STACK102 FCC ID:2AIWWPD-V8 FCC ID:2AIWWPD-V8 MODEL:PD-V8 MODEL:PD-V8 20X12mm...
- Page 3 FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. ...
