Stack STACK102 Installation Instructions

Microwave sensor

Installation Instructions STACK102

1) Provide 5V DC on pad 1 (4.75V-5.25V)

2) Provide DC ground onto PAD3

3) Connect PAD 2 (IF) to the µPC for signal processing

4) Operating temperature: -10-70° C

PAD1

PAD2

PAD3

NOTICE:

This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry

Canada.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference

that may cause undesired operation.

NOTICE:

Changes or modifications made to the equipment not expressly approved by Stack

may void the FCC / IC authorization to operate this equipment.

The use of the transceiver is authorized into mobile or fixed devices taking into

account the conditions listed below :

• OEM Integrator may be sure that the end user manual may not contain any

information about the way to install or remove the module from the final

product.
