Campbell CELL200-Series Quick Manual

Part Number 35035
Revision: 02/2019
www.campbellsci.com/cellular-communications
1. Introduction
NOTE:
This Quick Deploy Guide is a general reference to give the
installer an overview of the steps required to make this
system operational. The Product Manual is the definitive
source for detailed installation instructions and
information.
For best results, update to the latest data logger
operating system and version of Device Configuration
Utility.
NOTE:
CR3000, CR1000 and CR800-series users must refer to the
CELL200 Product Manual. This Quick Deploy Guide does
not apply.
You should have received two Quick Deploy Guides with your
CELL200-series module. The one you follow will depend on
whether your module was configured with a private dynamic
or public static IP address.
The Provisioning Report received with your Cellular Data
Service shows whether the module was configured with a
private dynamic or public static IP address. See
1) for an example of a Campbell Scientific Provisioning Report.
Other cellular providers should provide similar information.
USE THIS GUIDE if your module has a public static IP address.
4G LTE Cellular Module
For Public Static IP Addresses
FIGURE 1-1 (p.
FIGURE 1-1. Static IP provisioning report
Additionally, Campbell Scientific cellular modules configured
with a public static IP address will have two stickers on the
module, as shown in FIGURE 1-2
module phone number and data plan. The second sticker will
show the static IP address. USE THIS GUIDE.
Campbell Scientific cellular modules configured with a private
dynamic IP address will have one sticker on the module. It will
show the module phone number and data plan. USE THE
OTHER GUIDE.
FIGURE 1-2. Module with public static IP address
2. Campbell Scientific cellular data
service
Campbell Scientific can provide subscriptions to cellular
service through Verizon, AT&T, T-Mobile, Vodafone, Telstra,
and over 600 other providers worldwide. When this cellular
service is purchased with the module, the module will come
pre-provisioned with the required SIM card and APN. If you
have already purchased the CELL200 series, call Campbell
Scientific to set up service.
(p. 1). One sticker will show the
