Technical Data - M1-Sporttechnik Spitzing Pedelec Operating Manual

TECHNICAL DATA

TEST STANDARD EN14766
DISPLAY
LCD Display
DRIVE
Drive type: Mid drive Clean Mobile by TQ-Systems Germany
Drive performance: 48V
250 W nominal (Pedelec)
500 W nominal (S-Pedelec)
800 W nominal (R-Pedelec)
Speed: max. 25 km/h (Pedelec), max. 45 km/h (S-Pedelec), No limitation (R-Pedelec)
Torque: max. 120 Nm; Guarantee: 2 years:
BATTERY
Type: Lithium-Ion
Capacity: 18.27 Ah, 877 Wh or 20.8 Ah, 1,048 Wh
Nominal voltage: 48 V
Operating temperature range: - 15°C to + 60°C
Guarantee: 2 years or 500 complete charging cycles within 2 years
CHARGER
Charge duration: approx. 3.5 h for 100 %, approx. 1 h for 80 %
Charger: 110 / 240 Volt AC, 5A, built-in fan
