Operating Instruction; Battery Specifications; Battery Replacement - Fenix HL16 Operating Instruction

Intelligent overheat protection protects from high surface temperature

Made of quality aluminum and plastic

Certified by CPSIA and REACH

Secure lock for kids: the included Allen wrench is needed for battery cover opening. For

adult use, remove the screw and replace the battery
Accessories: AA battery, Allen wrench, Spare O-ring

Operating Instruction

General Mode
Press and hold the switch for 0.5 seconds to turn ON/OFF the headlamp.
With the lamp switched on, single click the switch to cycle through High→Low→Med.
Red Light
Single click the switch to enter Red light, one more clicking to enter Red flash. Click once again to
turn off red light mode.
The headlamp memorizes the last brightness level used in White light mode. When next turned
on, the previously used brightness level is recalled.
Mode Switching
With the lamp on Red light mode, press and hold to activate White light mode.

Battery Specifications

Types
Ni-MH Battery
ARB-L14-1600U
Alkaline Battery
Lithium Battery
(Non-rechargeable)
Li-ion Battery
(Rechargeable)
Warning: 1. It is prohibited to use banned battery in case of overvoltage explosion. Quality
battery is strongly recommended.
2. If the lamp will not be used for an extended period, remove the battery, or the lamp
could be damaged by electrolyte leakage or battery explosion.

Battery Replacement

1. Unscrew the locking screw to open the battery cover. Lower the holder to 90°angle, and press
Nominal
Dimensions
Voltage
AA 1.2V
14500 1.5V
AA 1.5V
AA 1.5V
10440 3.7V
Usability
Recommended √√
Recommended √√
Usable √
Cautious
！
Banned ×
