Installation instructions

Please read and follow the
your dryer!

Accessories

Please check you received the following accessories with your Fisher & Paykel dryer. You will find them inside the drum:
• 1 x Drying rack
• 1 x Drain hose
• 1 x Installation instructions and user guide

Unpacking

To ensure the best performance from your new dryer please follow the instructions below.
Removing the packaging
1. Remove the outer packaging (including the polystyrene packer and plastic wrapping). All packaging must be
removed prior to use.
2. Tilt the machine backwards and 'walk' it off the base one foot at a time. Not doing so may cause damage to
your floor and dryer.
3. Remove all packaging and accessories from inside the drum.
https://producthelp.fisherpaykel.com/nz/Dry/Dryers/Condensing/DE8060P2/User_Guide_DE8060P2/02_Installation_instructions
'Safety and
warnings' and 'installation instructions' sections carefully before using
Updated: Fri, 01 Mar 2019 03:41:55 GMT
Powered by
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DE8060P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fisher & Paykel DE8060P

Summary of Contents for Fisher & Paykel DE8060P

  • Page 1: Installation Instructions

    Installation instructions Please read and follow the ‘Safety and warnings’ and ‘installation instructions’ sections carefully before using your dryer! Accessories Please check you received the following accessories with your Fisher & Paykel dryer. You will find them inside the drum: •...

  • Page 2: Installation Options

    Ensure packaging materials are kept out of reach of children. • Please help protect the environment and dispose of the packaging from around the • dryer in an environmentally friendly manner. Location • The dryer must be installed in a well-ventilated, dust- free environment.

  • Page 3: Leveling The Machine

    BE USED between the products and fitted correctly to the washing machine. Stacking Kit White: Part No. 427976. 3. Move the machine into the desired position. Do not lift the dryer by the top panel. 4. Have a minimum clearance on all sides of at least 20 mm. 5.

  • Page 4: Connecting The Drain Hose

    Draining The dryer is equipped with a condenser unit which accumulates water during the drying cycle. This water is collected in the removable water tank located at the top left of the dryer. The accumulated water must be emptied after each drying cycle.

  • Page 5: Electrical Connection

    Electrical connection 1. This appliance must be connected to a 220 V – 240 V, 50 Hz, sinusoidal, 10 A electrical supply. 2. Uncoil the power cord, remove and discard the plastic pin cover and plug into a power socket. 3.
  • Page 6 5. Have you performed the installation test cycle? 6. If external draining is preferred, is the white drain hose attached to the correct outlet and hooked into a standpipe or tub? Machine specifications - DE8060P Capacity (kg)* Dimensions (mm) Width...
  • Page 7 Amps (maximum) Heating Power (W) 1800 *Capacity refers to the maximum dry weight of items the machine can dry at any one time. Some cycles have a lower maximum capacity (see the ‘Drying cycles’ section). ** The exact height of your dryer is dependent on how far the feet are extended from the base of the machine.
