Kusam-meco KM 2775 Operation Manual

An ISO 9001:2008 Company
11 FUNCTIONS 34 RANGES
Model KM 2775
AC CURRENT
Range
Resolution
±(2.0%rdg + 4dgts)
400 A 0.1 A
±(2.0%rdg + 4dgts)
2000 A 1 A
Frequency Response : 40Hz ~ 1kHz
AC VOLTAGE
Range
Resolution
±(2.0%rdg + 3dgts)
400 mV 0.1 mV
±(1.5%rdg + 3dgts)
4 V 1 mV
±(1.5%rdg + 3dgts)
40 V 10 mV
±(1.5%rdg + 3dgts)
400 V 100 mV
±(1.5%rdg + 3dgts)
600 V 1 V
Overload Protection : 600V AC RMS
Frequency Response : 0 ~ 400mV at 40Hz ~ 100Hz
4V ~ 600V at 40Hz ~ 500Hz
FREQUENCY
Range
Resolution
±(0.3%rdg + 2dgts)
4 KHz 1 Hz
±(0.3%rdg + 2dgts)
20 KHz 10 Hz
Overload Protection : 500V AC rms or 500V DC
Trigger level : 0.2V
Please do not change to any other DCV or Ohm range when you are
inputing 600V AC/DC. Make sure that you have turned off the input
voltage and then you can change to another range for testing.
®
An ISO 9001:2008 Company
D:\Chhaya\My Documents\Chhaya\backup\catlogs\NEW CAT\2013-14\KM 2775 revised 28 march 15.cdr
®
3¾ DIGIT 2000A AC/DC
DIGITAL CLAMPMETER
SPECIAL FEATURES :
Auto Ranging
Full Automatic measurement
Range change function
Data Hold function freezes the reading
Continuity & Diode Measurements
Auto Power Off
Low Battery Indication
GENERAL SPECIFICATIONS :
Sensing : Average Sensing.
Jaw opening size : 55mm Max.
Display : 3¾ digits 4000 counts LCD display
Sample Rate : Approx. 2 times per second
Response Time : Approx. 1 second
Low Battery : "
operating level.
Over range indication : "O.L" indicated
Operating Principle : Dual slope integration
Storage Temperature : -20°C to 60°C, <80% R.H.
Temperature & Humidity for Guaranteed accuracy @ -10°C to 50°C at <80% R.H.
Power Supply : Standard 9V battery
Dimension : 260(L) X 95(W) X 43(D) mm
Weight : Approx. 515 gm (battery included)
ELECTRICAL SPECIFICATIONS - KM 2775
Accuracy is ± (% reading digits + number of digits ) or otherwise specified, at 23°C ± 5°C & less than equal to 80% R.H.
DC CURRENT
Accuracy Range
Resolution
400 A
2000 A
DC VOLTAGE
Accuracy Range
400 mV
4 V
40 V
400 V
600 V
Overload Protection : 600V AC RMS
CONTINUITY TEST
Range
Accuracy
400
Overload Protection : 500V AC rms or 500V DC
WARNING
G-17, Bharat Industrial Estate, T. J. Road, Sewree (W), Mumbai - 400 015. INDIA.
Sales Direct.: 022 -24156638,
Email : kusam_meco@vsnl.net,
" sign appears on the display when the battery Voltage drops below accurate
Accuracy
±(1.5%rdg + 4dgts)
0.1 A
±(1.5%rdg + 4dgts)
1 A
Accuracy
Resolution
±(1.0%rdg + 3dgts)
0.1 mV
±(1.0%rdg + 3dgts)
1 mV
±(1.0%rdg + 3dgts)
10 mV
±(1.0%rdg + 3dgts)
100 mV
±(1.0%rdg + 3dgts)
1 V
Audible Threshold
Less than 25
All Specifications are subject to change without prior notice
Tel. : 022-24124540, 24181649,
SAFETY :
IEC/EN61010-1 EN61010-2-32 CAT III 600V
Withstand Voltage : 6000V
ACCESSORIES :
Test leads, Carrying Case, Battery installed,
User's Manual.
CAPACITANCE
Accuracy
Range
Resolution
4 nF
1 pF ±(3.0%rdg + 5dgts)
(30p~4nF)
10 pF ±(2.0%rdg + 5dgts)
40 nF
100 pF ±(2.0%rdg + 5dgts)
400 nF
4 F
±(2.0%rdg + 5dgts)
1 nF
40 F ±(2.5%rdg + 5dgts)
10 nF
400 F ±(2.5%rdg + 5dgts)
100 nF
1 F ±(2.5%rdg + 5dgts)
4 mF
Overload Protection : 500V AC rms or 500V DC
RESISTANCE
Range Accuracy
Resolution
±(1.5%rdg + 3dgts)
400 0.1
±(1.5%rdg + 3dgts)
4 K 1
±(1.5%rdg + 3dgts)
40 K 10
±(1.5%rdg + 3dgts)
400 K 100
±(1.5%rdg + 3dgts)
4 M 1 K
±(2.0%rdg + 4dgts)
40 M 10 K
Overload Protection : 500V AC rms or 500V DC
DIODE TEST
Accuracy
Range
Resolution
±(1.5%rdg + 3dgts)
2 V 1 mV
Fax : 022 - 24149659
Website : www.kusamelectrical.com
