Kusam-meco KM 2009 Operation Manual

Ac / dc digital clampmeter with data logging function & pc interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
An ISO 9001:2008 Company
Model - KM 2009
(Reference Diagram)
Solar panel power
Measuring charging current:
®
An ISO 9001:2008 Company
Chhaya Computer/D:/Chhaya/My Document/Chhaya/backup/Catlogs/New cat/KM 2009.cdr
®
AC / DC DIGITAL CLAMPMETER WITH
DATA LOGGING FUNCTION & PC INTERFACE
GENERAL SPECIFICATIONS :
SAFETY :
IEC1010-1, IEC1010-2-032,
pollution degree 2, CAT III (600V)
AC CURRENT
DC CURRENT
DIAGRAM OF MEASURING CURRENT
Measuring DC current
Test current consumption
I
-
+
12 V DC
Accumulator
G-17, Bharat Industrial Estate, T. J. Road, Sewree (W), Mumbai - 400 015. INDIA.
Sales Direct.: 022 -24156638,
Email : kusam_meco@vsnl.net,
ELECTRICAL SPECIFICATIONS : KM 2009
Range
Resolution
0.1
A
0.0A ~ 600A
Range
Resolution
0.1
A
0.0A ~ 600A
L
N
-
+
Measure AC line current
Device powered
by DC
All Specifications are subject to change without prior notice
Tel. : 022-24124540, 24181649,
FOR SOLAR APPLICATIONS
Power Consumption : about 10mW
Peak Hold : Press "HOLD" without release,
the meter will show the peak value.
Battery Voltage : "
" indicating the battery
voltage is lower then 7.2V. Then the battery
have to be changed.
Operating Temperature and Humidity :
0
0
0 C ~ 40 C : below 80% R.H.
Storage Temperature and Humidity :
0
0
-10 C ~ 60 C : below 70%rh
Insulation Strength : AC 2kV/rms
(between the alloy of the clamp & housing)
Auto Power Off : 5 minutes after power on,
it will power off automatically to lower the
power consumption.
Power : Standard 9V battery.
Dimension : 175(W) x 70(H) x 38(T)mm
Weight : Approx. 180g (with battery)
ACCESSORIES :
Carrying Case, Battery installed,
User's Manual, RS232 PC Interface CD.
Accuracy
±(2% rdg + 3 dgts)
Accuracy
±(2% rdg + 3 dgts)
+
Measure consumption
Fax : 022 - 24149659
Website : www.kusamelectrical.com
Wire Position

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KM 2009 and is the answer not in the manual?

Questions and answers

Related Manuals for Kusam-meco KM 2009

Summary of Contents for Kusam-meco KM 2009

  • Page 1 SAFETY : ACCESSORIES : IEC1010-1, IEC1010-2-032, Carrying Case, Battery installed, pollution degree 2, CAT III (600V) User's Manual, RS232 PC Interface CD. ELECTRICAL SPECIFICATIONS : KM 2009 AC CURRENT Range Accuracy Resolution ±(2% rdg + 3 dgts) 0.0A ~ 600A...
  • Page 2 * AC/DC Current Adaptor AC / DC * Thermo Anemometer DIGITAL CLAMPMETER * Thermo Hygrometer * Distance Meter Model KM 2009 * Digital Lux Meter * Network Cable Tester * Power Factor Regulator * Earth Resistance Tester * Digital Panel Meters...

  • Page 3: Table Of Contents

    AC / DC INDEX DIGITAL CLAMPMETER Warning............01 Model KM 2009 Introduction............02 Electrical Signs..........03 Electrical Specifications........03 Clampmeter Structure ........05 Operating Method..........06 How to change Battery........11 Accessories............11 Test Certificate..........12 Warranty............13...

  • Page 4: Warning

    Users shall carry out safety operation based on Warning instruction listed in this manual e.g. " " and danger Thank you for purchasing our company's High signs on this manual. Accuracy Leakage Clampmeter. For better use of this Please use mA to test leakage current ( test by product, please: clamping grounding line, single-phase line together).

  • Page 5: Electrical Signs

    II) ELECTRICAL SIGNS 30mm x 35mm Clamp Size Extremely dangerous! Operators shall strictly ad here Tested wire in the jaw center; Error Test Position to safety rules; otherwise there would be dangers may increase by 1.5%rdg max if of electric shock to cause personal injuries or casualties deviate the center Dangerous! Operators shall strictly adhere safety rules;...

  • Page 6: Operating Method

    VI) LCD Display IEC1010-1, IEC1010-2-032, Pollution Applicable Safety Rules level 2,CAT III (600V) V) Structure of the Leakage Clampmeter 1. DC indication 7. Unit annumeiated HOLD 2. AC indication 8. Reading 3. Negative polarity indication POWER 4. LCD battery symbol ZERO 5.
  • Page 7 2. AC/DC measurement switch 1) Power on. 2) Press ~/ to DC or AC measurement. The tester default to DC measurement after boot up. Conduct Adjust Zero before measure DC current. Press ~/ to switch the AC/DC function. LCD will display DC or AC to corresponding switch function.
  • Page 8 2) Press "HOLD" + "POWER" keys to enter into data access Measuring DC current mode and display shows Unit 1 storage data automatically; and then press "HOLD" key again to turn Test current consumption Solar panel power the page of stored data; "NULL" will display when there is no data stored in the memory, press "POWER"...

  • Page 9: Ix How To Change Battery

    X) Accessories KM 2009 MODEL NO. __________ Clamp tester 1 pc RS 232 Com cable...

  • Page 10: Warranty

    This warranty does not apply for damaged Ic’s, fuses, burnt PCB's, disposable batteries, carrying case, test leads, or to any product which in “KUSAM-MECO’s” opinion, has been misused, altered, neglected, contaminated or damaged by accident or abnormal conditions of operation or handling.
