- Page 1 Hope Industrial Systems, Inc. Hope Industrial Systems, Inc. Hope Industrial Systems, Inc. Hope Industrial Systems, Inc. User Manual 21.3” Panel Mount Industrial Monitor Model No. HIS-ML21-_ _ _ D...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY AND REGULATORY INFORMATION ..........3 Warning .....................3 FCC Notice ....................3 USING THE LCD DISPLAY ................4 Setting the Timing Mode................4 OSD and Power Lock Settings ..............4 ADJUSTING THE SCREEN IMAGE ..............5 ON-SCREEN DISPLAY CONTROLS.............6 INSTALLATION INSTRUCTIONS..............10 Preparing for Installation................10 Installation into Panel................11 TOUCHSCREEN DRIVER INSTALLATION ..........12 CLEANING ....................13... -
Page 3: Safety And Regulatory Information
Safety and Regulatory Information Warning To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dangerously high voltages are present inside the unit. Do not disassemble the unit. Refer servicing to qualified personnel only. This equipment is not intended for use in critical applications where its failure to operate would create immediate life threatening circumstances. -
Page 4: Using The Lcd Display
Using the LCD Display Setting the Timing Mode Setting the timing mode of your computer graphics adapter (or other video source) is important for maximizing the quality of the screen image and for minimizing eye strain. The timing mode consists of the resolution (example 1600 x 1200) and refresh rate (or vertical frequency; example 60 Hz). -
Page 5: Adjusting The Screen Image
Adjusting the Screen Image Use the buttons on the rear control panel to display and adjust the On-Screen Display (OSD) controls which display on the screen. Do the following to adjust the screen image: 1. To display the OSD Main Menu, press button [1]. NOTE: All OSD menus and adjustment screens disappear automatically after 15 seconds. -
Page 6: On-Screen Display Controls
On-Screen Display Controls Adjust the menu items shown below by using the up ▲ and down ▼ buttons. Control Explanation Indicator Light The indicator light on the rear of the monitor glows green when the display is powered on and receiving a valid video signal; orange when the display is in power-save mode. - Page 7 Control Explanation Color Adjust provides several color adjustment modes, including preset color temperatures and a User Color mode which allows independent adjustment of red (R), green (G), and blue (B). The factory setting for this product is 6500K (6500 Kelvin). o sRGB –...
- Page 8 Control Explanation Manual Image Adjust displays the Manual Image Adjust menu. o PIP allows two images to be displayed simultaneously as picture-in-picture PIP Position moves the PIP windows and control screen PIP Swap swaps the main and sub window o H./V. Position moves the screen image left or right and up or down o Horizontal Size adjusts the width of the screen image o Fine Tune sharpens the focus by aligning text and/or graphics with pixel boundaries.
- Page 9 Control Explanation Setup Menu displays the menu shown below. o Language Select allows you to choose the language used in the menus and control screens. o Resolution Notice advises of the optimal resolution to use. o OSD Position allows you to move the on-screen display menus and control screens o OSD Timeout sets the length of time an on-screen display screen is displayed.
-
Page 10: Installation Instructions
Installation Instructions Preparing for Installation Important! Perform the following steps BEFORE installation of the monitor into the panel. 1. Ensure that sufficient power is available. 2. Ensure that sufficient space is available to allow for proper airflow into and out of the unit. 3. -
Page 11: Installation Into Panel
Installation into Panel Refer to the drawing below. Locate position in panel for mounting of the monitor. Assure that there is adequate space behind the panel. Allow extra space (0.5 in. behind and on each side) for air ventilation. Cut a rectangular hole in the panel. Clean and deburr. Dimensions: 21.13”... -
Page 12: Touchscreen Driver Installation
Touchscreen Driver Installation The enclosed CD-ROM contains documentation and drivers for all major operating systems (touchscreen models only). To assure you have the most current information, check the following Internet address: http://HopeIndustrial.com/Touchscreen_Drivers.htm... -
Page 13: Cleaning
Cleaning CAUTION! DO NOT USE ABRASIVE MATERIALS SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS ON THE DISPLAY, AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. Resistive Touchscreen Model Any standard glass cleaner can be used to clean the touchscreen. Always spray the glass cleaner on the cloth or towel and then clean the touchscreen. -
Page 14: Video Troubleshooting
Video Troubleshooting Blank Screen After installing the power cable and connecting video cable to a PC, the monitor displays a blank screen. Press the power button and check to see if the power LED is lit. • If the LED is not lit, make sure the PC is powered on. Make sure all •... -
Page 15: Drawings
Drawings Front View... -
Page 16: Bottom And Rear Views (Showing Cutout Dimensions)
Bottom and Rear Views (Showing Cutout Dimensions) -
Page 17: Specifications
Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 21.3” diagonal Image Size 17.00” (432 mm) W x 12.75” (324 mm) H Native Resolution UXGA (1600 x 1200) @ 60 Hz Plug and Play DDC1/2B compatible Minimum Resolution VGA (640 x 480) Pixel Pitch 0.255 mm x 0.255 mm... -
Page 18: Electrical
Electrical Power Input 100-120/220-240 VAC, 2/1 A, 60/50 Hz Power Consumption 53 W (typical) Power Management DPMS/energy star, < 2W Compliances and Certifications Electrical UL 508A Listed (File No. E318630); FCC Class A Environmental RoHS Enclosure UL 50E (File No. E318630) Functional Panel Controls (rear) Power, 1 (OSD), 2 (Select), Up, Down... -
Page 19: Warranty Statement
Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent. What Does This Warranty Cover and What is the Period of Coverage? We warrant this product to be free from defects in material and workmanship, subject to the conditions set forth below. - Page 20 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 Toll Free: (877) 762-9790 Phone: (678) 762-9790 Fax: (678) 762-9789 Sales and Customer Service: sales@HopeIndustrial.com Support and Returns: support@HopeIndustrial.com Accounting Department: accounting@HopeIndustrial.com www.HopeIndustrial.com Publication ML21D, January 2010 © 2010 Hope Industrial Systems, Inc.
