- Page 1 Hope Industrial Systems, Inc. User Manual 19” Universal Mount Industrial Monitor Model No. HIS-UM19-___C...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety and Regulatory Information ............. 3 Warning ..................... 3 FCC Notice ....................3 Using the LCD Display ................. 4 Setting the Timing Mode ................4 OSD and Power Lock Settings ..............4 Adjusting the Screen Image ................. 5 Main Menu Controls .................. -
Page 3: Safety And Regulatory Information
Safety and Regulatory Information Warning To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dangerously high voltages are present inside the unit. Do not disassemble the unit. Refer servicing to qualified personnel only. This equipment is not intended for use in critical applications where its failure to operate would create immediate life threatening circumstances. -
Page 4: Using The Lcd Display
Using the LCD Display Setting the Timing Mode Setting the timing mode is important for maximizing the quality of the screen image and minimiz- ing eye strain. The timing mode consists of the resolution (example 1280 x 1024) and refresh rate (or vertical frequency;... -
Page 5: Adjusting The Screen Image
Adjusting the Screen Image Use the buttons on the rear control panel to display and adjust the On-Screen Display (OSD) con- trols which display on the screen. Do the following to adjust the screen image: 1. To display the Main Menu, press button [1]. NOTE: All OSD menus and adjustment screens disappear automatically after about 30 seconds. -
Page 6: Main Menu Controls
Main Menu Controls Adjust the menu items shown below by using the up ▲ and down ▼ buttons. Control Explanation Auto Image Adjust automatically sizes, centers, and fine tunes the video signal to eliminate waviness and distortion. Press the [2] button to obtain a sharper image. NOTE: Auto Image Adjust works with most common video cards. - Page 7 Explanation Control Manual Image Adjust displays the Manual Image Adjust menu. o H./V. Position moves the screen image left or right and up or down. Press button [2] to toggle between Horizontal and Vertical. The Horizontal setting moves the screen im- age to the left or to the right.
-
Page 8: Installation Instructions
Installation Instructions Preparing for Installation Important! Perform the following steps BEFORE Installation of the monitor 1. Ensure that sufficient power is available. 2. Ensure that sufficient space is available to allow for proper airflow around the enclosure. 3. Ensure that the air temperature around the unit (top and bottom) will not exceed the rated specifications of the unit. -
Page 9: Installation Using Vesa Mounting
Installation using VESA mounting All units come standard with a 100mm square VESA mounting pattern with M4 threads. If this mounting method is used, consider the following: o M4 screws should not protrude into the rear cover by more than ¼ ”. o The capacity of the arm or mounting plate selected should take into account the total weight of the monitor and its center of gravity. -
Page 10: Installation Using The Bench Top Mounting Option
Installation using the bench top mounting option 1. Insure mounting surface is smooth enough to seal with gasket and create mounting pat- tern in surface per the above diagram. 2. Install first two opposing ¼-20 flat head screws (two different lengths provided) 3. -
Page 11: Installation Using Pedestal Mounting Option
Installation using pedestal mounting option 1. Prepare the mounting surface for installation of the pedestal by referring to the illustration. 2. Install the pedestal using appropriate hardware and methods for the mounting surface selected taking strength, cable routing and sealing into consideration. 3. - Page 12 Installation using yoke and pedestal mounting option (continued from previous page) Note: The ¾” conduit and other sealing hardware are not required for NEMA 12 monitors or NEMA 4/4X monitors with the 4-cable gland.
-
Page 13: Installation Using Fixed Pedestal Mounting Option
Installation using fixed pedestal mounting option 1. Prepare the mounting surface for installation of the pedestal by referring to the illustration. 2. Install the pedestal using appropriate hardware and methods for the mounting surface se- lected taking strength, cable routing and sealing into consideration. 3. - Page 14 Installation using fixed pedestal mounting option (continued from previous page)
-
Page 15: Touchscreen Driver Installation
Touchscreen Driver Installation The enclosed CD-ROM contains documentation and drivers for all major operating systems. To assure you have the most current information, check the following Internet addresses: http://HISmonitors.com/Touchscreen_Drivers.htm Cleaning CAUTION! DO NOT USE ABRASIVE MATERIALS SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. -
Page 16: Troubleshooting
Troubleshooting Note: The following steps apply when unit does not come with a KVM extender. For troubleshooting with a KVM extender installed, please refer to the Installer/User Guide that comes with that equipment. Blank Screen After installing the power adapter and connecting I/O cable to a PC, the monitor displays a blank screen. -
Page 17: Drawings
Drawings Front View... -
Page 18: Side And Rear View
Side and Rear View... -
Page 19: Specifications
Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 19.0” diagonal Image size 14.82” (376mm) x 11.85” (301mm) Native resolution SXGA (1280 x 1024) @ 60 Hz Plug and Play DDC1/2B compatible Minimum resolution VGA (640 x 480), operation in native resolution (1280 x 1024) will ensure best results Pixel pitch 0.294mm (H) x 0.294 mm (V) -
Page 20: Electrical
Electrical Power Input 100–240 VAC, 50-60 Hz (autoswitch) Power consumption 33 watts, typical Power management DPMS/energy star, < 1W Environmental Temperature 0-45°C (consult factory for installation instructions when con- tinuous 24/7 operation exceeds 40°C) Humidity 20% to 90% non-condensing Shock 30g (1/2 sine, 11 msec.) Vibration 0.006 inch p-p 15-57Hz, 1.0g 57-640Hz sine... -
Page 21: Compliance
Compliance Electrical UL 60950 3 Edition, cUL recognized component; CE; FCC Class A Environmental RoHS Enclosure Type Self-contained, stainless steel or painted carbon steel Environmental rating NEMA 12, 12/4, or 12/4/4X (built to IP65 standards) Seal NEMA 12 gland, NEMA 4 gland, ¾” conduit, or 4-cable gland Mounting VESA pattern 100mm square, M4 threads Optional Yoke mounting with ¼-20 internal thread interface... - Page 22 (this page left blank)
-
Page 23: Warranty Statement
Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent. What Does This Warranty Cover and What is the Period of Coverage? The warranty remains in force for a three year period beginning on the date we invoice you for the product unless it is a keyboard, for which the warranty period is one year. - Page 24 Hope Industrial Systems, Inc. 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 www.HISmonitors.com 2006 Hope Industrial Systems, Inc. Publication UM19 December 2006...
