- Page 1 Hope Industrial Systems, Inc. User Manual 12” Industrial LCD Monitor Model No. HIS-ML12-SXA...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety and Regulation Information ......3 Factory Preset Timing ..........4 Panel Controls and OSD Functions ......5 OSD Function Descriptions ........6 Installation Instructions ..........7 Cleaning ..............9 Troubleshooting ............10 Drawings ..............11 Specifications ............13 Warranty Statement .......... -
Page 3: Safety And Regulation Information
Safety and Regulatory Information Warning To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dangerously high voltages are present inside the unit. Do not disassemble the unit. Refer servicing to qualified personnel only. This equipment is not intended for use in critical applications where its failure to operate would create immediate life threatening circumstances. -
Page 4: Factory Preset Timing
Factory Preset Timing If the selected timing is NOT included in the table below, the monitor will use the most suitable available timing. Resolution Horizontal Vertical Pixel Frequen- Mode Freq. Freq. cy (MHz) (KHz) (Hz) 640 x 350 31.469 70.087 25.175 VGA-350 640 x 400... -
Page 5: Panel Controls And Osd Functions
Panel Controls and OSD Functions Controls Description DC On/Off switch* Press the power switch to turn the monitor ON/OFF Menu Button Pressing the menu button the first time brings up the OSD (On Screen Display) menu. Plus (+) and Minus (-) The + and –... -
Page 6: Osd Function Descriptions
OSD Function Descriptions FUNCTION DESCRIPTION Brightness 101 scales of brightness are available to choose from (0 to 100) Contrast 256 scales of contrast are available (0 to 255) H. Position For adjustment of the display’s horizontal position. V. Position For adjustment of the display’s vertical position. Phase 32 scales are available to adjust the focus and clarity of the display (0 to 31). -
Page 7: Installation Instructions
Installation Instructions Preparing for Installation Important! Perform the following steps BEFORE Installation of the moni- tor into the panel. 1. Ensure that sufficient power is available. 2. Ensure that sufficient space is available to allow for proper air flow into and out of the unit. - Page 8 Installation into Panel Refer to the drawing below. Locate position in panel for mounting of the monitor. Assure that there is adequate space begin the panel. Allow extra space (0.5 in. behind and on each side) for air ventilation. Cut a rectangular hole in the panel. Clean and deburr. Dimensions: 12.12”...
-
Page 9: Cleaning
Cleaning Resistive Touchscreen model Any standard glass cleaner can be used to clean the touchscreen. Always spray the glass cleaner on the cloth or towel and then clean the touchscreen. Glass cleaner sprayed directly on the monitor could possibly leak inside a non-sealed unit and cause damage. Vinegar or ammonia will not hurt the touchscreen. -
Page 10: Troubleshooting
Troubleshooting Blank Screen After installing the power adapter and connecting I/O cable to a PC, the monitor displays a blank screen. • Press the power button and check to see if the power LED is lit. • If the LED turns green, make sure the PC is powered on. Make sure all cables are connected. -
Page 11: Drawings
Drawings Front and Side Views Rear View (showing Cutout Dimensions) -
Page 12: Specifications
Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 12.1” diagonal Image size 9.7” (246mm) W x 7.3” (184.5mm) H Native resolution SVGA (800 x 600) Plug and Play DDC1/2B compatible` Minimum resolution VGA (640 x 480) Pixel pitch 0.3075mm x 0.3075mm Number of colors 16 million... - Page 13 Electrical Power Adapter Input 100VAC – 240VAC, 50-60 Hz Power adapter output 12VDC @ 2.5 amps Monitor input 12VDC Power consumption Approximately 30 watts Power management DPMS/energy star, < 3W Compliance UL 1950, cUL 959; FCC Class A Environmental Temperature 0-50°C (consult factory for installation instructions when con- tinuous 24/7 operation exceeds 40°C) Humidity...
- Page 14 Enclosure Type Panel mount; rear collar compresses gasket against panel, held by 8 10-32 studs Panel rating NEMA 12/4/4X (with proper installation) – built to IP65 stan- dards Physical Depth 1.6” (2.5” at connectors) behind panel maximum Bezel Stainless Steel Front bezel outside di- 13.3”...
-
Page 15: Warranty Statement
Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent. What Does This Warranty Cover and What is the Period of Coverage? We warrant this product to be free from defects in material and workmanship, subject to the condi- tions set forth below. - Page 16 Hope Industrial Systems, Inc. 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 www.HISmonitors.com 2001 Hope Industrial Systems, Inc. Publication UM-ML15-1.2 Nov 2001...
