22" PANEL MOUNT INDUSTRIAL MONITOR
REVISION C
USER MANUAL
Model No. HIS-ML22- _ _ _ C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIS-ML22 C Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hope Industrial Systems HIS-ML22 C Series

  • Page 1 22" PANEL MOUNT INDUSTRIAL MONITOR REVISION C USER MANUAL Model No. HIS-ML22- _ _ _ C...
  • Page 2: Table Of Contents

    Table of Contents Safety and Regulatory Information ��������������������������������������������������������������������������������3 FCC Notice ����������������������������������������������������������������������������������������������������������������������������� 3 Hazardous Locations �������������������������������������������������������������������������������������������������������������� 4 Waste Electrical and Electronic Equipment Directive (WEEE) ����������������������������������������������� 4 Mechanical Drawings ������������������������������������������������������������������������������������������������������5 Front and Side Views �������������������������������������������������������������������������������������������������������������� 5 Bottom View ���������������������������������������������������������������������������������������������������������������������������� 5 Rear View ������������������������������������������������������������������������������������������������������������������������������� 6 Installation Instructions ��������������������������������������������������������������������������������������������������7 Step 1: Prepare for Installation ����������������������������������������������������������������������������������������������...
  • Page 3: Safety And Regulatory Information

    Safety and Regulatory Information Safety and Regulatory Information WARNING! To prevent fire or shock hazard, do not expose live components to rain or moisture. Dangerously high voltages are present inside the unit� Do not disassemble the unit. Refer servicing to qualified personnel only. Operator could be exposed to dangerously high voltage if AC power is not connected properly�...
  • Page 4: Hazardous Locations

    Users should contact their supplier and check the terms and conditions of the purchase contract� When purchased directly from Hope Industrial Systems, you may contact technical support for disposal arrangements.
  • Page 5: Mechanical Drawings

    Mechanical Drawings Mechanical Drawings Front and Side Views 558.8 mm (22.00") 374.7 mm 296.1 mm 314.6 mm (14.75") (11.66") (12.39") 473.8 mm 7.1 mm 50.0 mm (18.65") (0.28") (1.97") Bottom View 499.2 mm (19.65") 57.1 mm (2.25") 7.1 mm (0.28") 558.8 mm (22.00") ML22C User Manual, 99176B, December 2022...
  • Page 6: Rear View

    Mechanical Drawings Rear View 249.0 mm (9.80") 50.0 mm (1.97") 100 mm VESA Mounting Pattern (M4 screws provided, 16 mm maximum depth of screw) 173.5 mm (6.83") ML22C User Manual, 99176B, December 2022...
  • Page 7: Installation Instructions

    Installation Instructions Installation Instructions Step 1: Prepare for Installation IMPORTANT! Perform the following steps BEFORE installation of the monitor into the panel. 1� Ensure that sufficient power is available. 2� Ensure that sufficient space is available to allow for proper air flow into and out of the unit�...
  • Page 8: Step 2: Bench-Test Configuration

    Installation Instructions Step 2: Bench-test Configuration Make sure everything works before installing into the production environment.  TIP! If using a KVM extender, please refer to the installation instructions included with the KVM extender module. It is particularly important to bench-test the full configuration prior to final installation.
  • Page 9 II, III, Division 2 Hazardous Location requirements.  TIP! To avoid incompatibility issues, use only certified video adapters available from Hope Industrial Systems. Many 3rd-party signal adapters are known to cause signaling issues� Power Connection The HIS-ML22 is available with either AC or DC power input.
  • Page 10: Connect And Set Up Touch Screen

    To use the touch screen Serial (RS-232) interface, a serial cable may be ordered separately� Instructions below apply to Windows systems� Contact Hope Industrial Systems if you require a CD-ROM with documentation and touch screen drivers. For a full list of downloadable drivers, please check the following address: https://www�HopeIndustrial�com/support/drivers/...
  • Page 11 Installation Instructions Installing the Driver: Serial (RS-232) Connections Serial Connections must be made before installing the driver.  1� Connect one end of the Serial cable to the Serial input port on the rear of the monitor� Connect the other end to the Serial port on the host computer. Tighten the screw locks on the cable connectors to ensure adequate strain relief�...
  • Page 12: Step 3: Install Into Panel

    Once you have completed the full bench-test configuration and confirmed that all components are working properly, you are ready to install the monitor into its panel cutout. WARNING! Hope Industrial Systems will not assume liability for damage to internal electronics due to improper installation� Contact Hope Industrial Systems if you need additional assistance�...
  • Page 13 6� Refer to the enclosure mounting diagram below. 7� Insert the unit into the front of the panel and re-attach the collar� NOTE: Contact Hope Industrial Systems if for any reason your application does not allow for installation of the collar�...
  • Page 14: Video Settings

    Video Settings Video Settings Setting the Timing Mode Setting the timing mode of your computer graphics adapter (or other video source) is important for maximizing the quality of the screen image and for minimizing eye strain. The timing mode consists of the resolution (e.g. 1680 x 1050) and refresh rate (or vertical frequency; e.g. 60 Hz). After setting the timing mode, use the On-Screen Display (OSD) controls to adjust the screen image.
  • Page 15: Control Panel Buttons

    Video Settings Control Panel Buttons Use the control panel buttons located on the back of the monitor to display and adjust various settings on the On-Screen Display (OSD) menu. CONTROL PANEL BUTTONS 1� To open the OSD menu, press the Menu button. NOTE: All OSD menus and adjustments screens disappear automatically after 60 seconds.
  • Page 16 Video Settings Button Control Functions Menu • Opens the OSD menu� • Exits the submenu� • Exits the OSD menu� Select / When the OSD menu IS NOT displayed: Navigate Down • Shortcut to Auto setup function� When the OSD menu IS displayed: •...
  • Page 17: On-Screen Display (Osd) Menus

    Video Settings On-Screen Display (OSD) Menus To open the OSD menu, press the Menu button once. Main Menu Description Picture Includes the Contrast, Brightness, Sharpness, and Color functions� VGA Settings Includes the Timing, Auto setup, H total, V position, H position, and Phase functions�...
  • Page 18 Video Settings Color Menu The Color submenu in the Picture menu includes the Auto color, Theme mode, Gamma, Color balance, and User color functions� Color Menu Description Auto color Auto color is an auto adjust routine to compensate, for example, analog signal level drops on long VGA cables.
  • Page 19: Vga Settings Menu

    Video Settings Color Menu Description Color balance Provides several color adjustment modes, including preset color temperatures and a User color mode that allows individual adjustment of Red, Green, and Blue. The factory default setting for this product is Normal� • User color allows individual adjustment of Red, Green, and Blue�...
  • Page 20: Setup Menu

    Video Settings VGA Settings Menu Description H total Allows the user to fine tune the horizontal timing by increasing or decreasing the total horizontal pixels. H total affects how the image is stretched horizontally. V position (Vertical Moves the screen image up and down. Position) H position (Horizontal Moves the screen image left and right.
  • Page 21 Video Settings Setup Menu Description The OSD submenu provides several adjustments for the OSD menu settings. • Time out sets the length of time (in seconds) the OSD screen is displayed. For example, with a "60" setting, if a control is not pushed within 60 seconds, the display screen disappears�...
  • Page 22 Video Settings Setup Menu Description Source scan Allows the user to turn source scan "On" or "Off." When Source scan is enabled and there is no active video signal present, the display will cycle through video connections until a video source is detected�...
  • Page 23: Cleaning Instructions

    Cleaning Instructions Cleaning Instructions CAUTION! DO NOT USE ABRASIVE MATERIALS, SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS, ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. All displays may be cleaned using any standard glass cleaner as long as there is no abrasive or oily content.
  • Page 24: Troubleshooting

    If the problem still exists, try bypassing the KVM extender. If this fixes the problem and allows the monitor to work properly, then the KVM extender is the source of the problem� Please refer to the troubleshooting section of the KVM extender manual or contact Hope Industrial Systems for additional assistance. Symptom Causes...
  • Page 25 Troubleshooting Symptom Causes Solutions "Scanning Ports / No Video cable is not plugged Check the video cable connection at Signal" message box in correctly� the monitor, PC, and/or KVM extender. and no image on the PC is not powered on� Ensure PC is powered on�...
  • Page 26: Touch Screen Troubleshooting

    Troubleshooting Touch Screen Troubleshooting Applies to touch screen monitors only� To be sure that you have the most current driver, please check the following address: https://www�HopeIndustrial�com/support/drivers/ Symptom Causes Solutions No response Touch screen cable is not Make sure either the USB or Serial touch when touching plugged in correctly.
  • Page 27: Specifications

    Specifications Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 22" diagonal Image Size (W x H) 473�8 mm x 296�1 mm (18�65" x 11�66") Native Resolution WSXGA+ (1680 x 1050, 16:10 aspect ratio) Minimum Resolution VGA (640 x 480) Pixel Pitch 0�282 mm x 0�282 mm Number of Colors...
  • Page 28: Video

    Input Connectors • HD-15, DVI-I • Optional adapters are available for other connection types (contact Hope Industrial Systems for details) Input Signal Formats • RGB Analog video, 0.7/1.0 Vp-p, 75 Ohms Compatible sync modes: Separate H/V sync, Composite sync, Sync on Green •...
  • Page 29: Physical

    Specifications Physical Enclosure Type Panel mount; rear collar compresses gasket against panel (5/16" maximum panel thickness); held by 14 M5 studs Panel Rating (with proper Built to IP65/IP66 standards installation) • NEMA/UL Type 12/4 (Black Powder-Coated Faceplate) • NEMA/UL Type 12/4/4X (Stainless Steel Faceplate) Depth •...
  • Page 30: Compliances And Certifications

    Specifications Compliances and Certifications Electrical • UL/EN/IEC62368-1, UL Recognized Component (File No. E212889) • UL 508A Listed (File No� E318630) • FCC Class A • CAN ICES-3A/NMB-3A • • UKCA • NOM (Registration No. NOM-019-SCFI-1998) NOTE: DC power must use shielded DC input cable Environmental •...
  • Page 31: Warranty Statement

    The warranty remains in force for a five year period beginning on the date we invoice you. If Hope Industrial Systems repairs or replaces a product under warranty, its warranty term is not extended, but the repair itself is warranted for 90 days�...
  • Page 32 Phone: +39 80 0740414 Phone: +33 8 05 08 05 19 Phone: +49 800 001 0486 HopeIndustrial.it HopeIndustrial.fr HopeIndustrial.de Spain Mexico Phone: +34 91 1438229 Phone: +52 800 9531935 HopeIndustrial.es HopeIndustrial.mx ML22C User Manual, 99176B, December 2022 © 2023 Hope Industrial Systems, Inc.
