Summary of Contents for Hope Industrial Systems HIS-ML21-CGBC
- Page 1 Hope Industrial Systems, Inc. User Manual 21.3” Panel Mount Industrial Monitor Model No. HIS-ML21-CGBC, -CTBC, -SGAC, -STAC...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety and Regulatory Information ..............3 Using the LCD Display ..................4 Setting the Timing Mode ................4 Self-Test Feature Check (STFC) ............... 5 User Controls ..................... 6 Automatic Save ..................7 Direct Access Features ................7 OSD Functions .................. -
Page 3: Safety And Regulatory Information
Safety and Regulatory Information Warning To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dangerously high voltages are present inside the unit. Do not disassemble the unit. Refer servicing to qualified personnel only. This equipment is not intended for use in critical applications where its failure to operate would create immediate life threatening circumstances. -
Page 4: Using The Lcd Display
Using the LCD Display Setting the Timing Mode Setting the timing mode on the PC is important for maximizing the quality of the screen image and minimizing eye strain. The timing mode consists of the resolution (example 1600 x 1200) and refresh rate (or vertical frequency;... -
Page 5: Self-Test Feature Check (Stfc)
Self-Test Feature Check (STFC) Your monitor provides a self-test feature that allows you to check whether the monitor is function- ing properly. Turn off both your computer and the monitor. Unplug the video cable from the back of the computer. Turn on the monitor. -
Page 6: User Controls
User Controls Your LCD monitor allows you to easily adjust the characteristics of the image being displayed. All of these adjustments are made using the control buttons on the rear of the monitor. While you use these buttons to adjust the controls, an OSD shows you their numeric values as they change. Rear Control Buttons and Indicators Button / Indica- Functions... -
Page 7: Automatic Save
Automatic Save Whenever you open the OSD and allow an adjustment window to remain active for about 3 seconds without pressing other buttons, the monitor automatically saves any adjustment you have made. These changes are saved into a user area in the monitor. The monitor can save adjustments for up to 4 user modes. -
Page 8: Osd Functions
OSD Functions Accessing the menu system 1. Push the Menu button to display the main OSD menu. 2. Use the "– , +" buttons to move from one function to another. As you move from one icon to another, the Function Name changes. See the Table starting on the next page to view a complete list of all of the functions available for the monitor. - Page 9 OSD: Input Menu Description Use to select PC or other external input sources connected to the Monitor. Source List Use to select the screen of your choice. Analog Digital Video S-Video Edit Name Name the input device connected to the input jacks to make your input source selection easier.
- Page 10 OSD: Picture (Analog / Digital : PC) Menu Description MagicBright is a new feature providing the optimum viewing environment de- MagicBright pending on the contents of the image you are watching. Currently four different modes are available: Text, Internet, Entertain and Custom. Each mode has its own pre-configured brightness value.
- Page 11 Menu Description Image Lock is used to fine-tune and get the best image by removing noise that Image Lock creates unstable images with jitter and shimmer. If satisfactory results are not obtained using the Fine adjustment, use the Coarse adjustment and then use Fine again.
- Page 12 OSD: Picture (Digital : Digital DVD) Menu Description The Monitor has four automatic picture settings ("Dynamic", "Standard", "Movie" Mode and "Custom") that are preset at the factory. You may also select "Custom" which automatically recalls your personalized picture settings. Dynamic: Select this mode to view a sharper image than in "Standard" mode.
- Page 13 Menu Description The Monitor has four automatic picture settings ("Dynamic", "Standard", "Movie" Mode and "Custom") that are preset at the factory. You can activate either Dynamic, Standard, Movie, or Custom. You may also select "Custom" which automatically recalls your personalized picture settings. Dynamic: Select this mode to view a sharper image than in "Standard"...
- Page 14 OSD: MagicColor Pro Menu Description Implements the natural color chroma according to the display screen. Automatical- MagicColor ly adjusts to the display screen. Can improve the tones. Intelligent: Enhance natural color except skin tone. Full: Displays both natural skin tones and enhanced colors. Demo: Displays the improved image on the left and the original on the right.
- Page 15 OSD: PIP (Analog / Digital : PC) Menu Description Turn the PIP Screen on or off. Select the input source for the PIP. Source Analog / Digital(PC) - Video / S-Video Mode Change the Size of the PIP window. Size If you select in Size, Position will not be activated.
- Page 16 OSD: Setup Menu Description Language You can choose one of 11 languages. Changes the opaqueness of the background of the OSD. Transparency High Medium Opaque Blue Screen If no signal is being received or the signal is very weak, a blue screen automatically replaces the noisy picture background.
-
Page 17: Troubleshooting
Troubleshooting If you have a problem setting up or using your LCD monitor, you may be able to solve it yourself. Before contacting customer service, try the suggested actions that are appropriate to your prob- lem. Symptom Checklist Solution Is the power cord con- Check the power cord connection and supply. - Page 18 Symptom Checklist Solution You can see this message when the signal from Can you see "Not Opti- the video card exceeds the maximum resolution mum Mode", "Recom- and frequency that the monitor can properly han- mended mode : 1600 X dle.
- Page 19 Symptom Checklist Solution I cannot see Have you locked the On Unlock the OSD by pressing the MENU button for the On Screen Screen Display (OSD) at least 5 seconds. Display. Menu to prevent changes? The screen Is the screen displaying Check the signal cable connection or try using a shows strange only one color as if look-...
-
Page 20: Display Modes
Display Modes If the signal from the computer system is the same as one of the monitor’s standard signal modes, the screen is adjusted automatically. If the signal from the computer is not the same as one of the standard signal modes, the screen may not display properly or it may not display at all. In this case adjust the mode on the computer system. -
Page 21: Information For Resistive Touchscreen Monitors
Information for Resistive Touchscreen Monitors The enclosed CD-ROM contains documentation and drivers for all major operating systems (touchscreen monitors only). To assure you have the most current information, check the follow- ing Internet addresses: http://www.hismonitors.com/Touchscreen_Drivers.htm... -
Page 22: Installation Instructions
Installation Instructions Preparing for Installation Important! Perform the following steps BEFORE Installation of the monitor into the panel. 1. Ensure that sufficient power is available. 2. Ensure that sufficient space is available to allow for proper airflow into and out of the unit. 3. - Page 23 Installation into Panel Refer to the drawing below. Locate position in panel for mounting of the monitor. Assure that there is adequate space begin the panel. Allow extra space (0.5 in. behind and on each side) for air ventilation. Cut a rectangular hole in the panel. Clean and deburr. Dimensions: 21.13”...
-
Page 24: Cleaning
Cleaning Any standard glass cleaner can be used to clean the touchscreen or protective safety glass win- dow. Always spray the glass cleaner on the cloth or towel and then clean the touchscreen. Glass cleaner sprayed directly on the monitor could possibly leak inside a non-sealed unit and cause damage. -
Page 25: Drawings
Drawings Front View... - Page 26 Bottom and Rear View (Showing cutout dimensions)
-
Page 27: Specifications
Specifications Display Thin-film transistor (TFT) Active Matrix Liquid Crystal Type Size 21.3” diagonal Image size 17.00” (432mm) x 12.75” (324mm) SXGA (1600 x 1200) @ 60 Hz Native resolution DDC1/2B compatible Plug and Play VGA (640 x 480), operation in native resolution will ensure Minimum resolution best results 0.27mm (H) x 0.27 mm (V) - Page 28 Electrical 85-132 VAC / 170-265 VAC (47-63 Hz) Monitor input 63 watts (max.) Power consumption DPMS/energy star, < 2W Power management UL 60950 3 Edition / cUL recognized component; FCC Class A Compliance Environmental Temperature 0-50°C Humidity 10% to 90% non-condensing Shock 30g (1/2 sine, 11 msec.) Vibration...
- Page 29 Physical 2.2” (56mm) MAX behind panel Depth Stainless Steel Bezel Front bezel outside 22.28” (566mm) W x 17.87” (454mm) H x 0.28” (7mm) thick (not dimensions including gasket) Cutout dimensions 21.13” (537mm) W x 16.70” (424mm) H ; +/- .020” Net weight Black Carbon Steel Model –...
- Page 30 (This page left blank)
-
Page 31: Warranty Statement
Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent. What Does This Warranty Cover and What is the Period of Coverage? The warranty remains in force for a three year period beginning on the date we invoice you for the product unless it is a keyboard, for which the warranty period is one year. - Page 32 Hope Industrial Systems, Inc. 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 www.HISmonitors.com 2007 Hope Industrial Systems, Inc. Publication ML21 September 2007...
