Summary of Contents for Sunlighten mPulse

  • Page 1 U S E R M A N U A L...
  • Page 2 Congratulations! You are now the owner of an mPulse sauna. With ® Sunlighten infrared heat, you are empowered to improve your quality of life. Just follow our assembly instructions and sauna protocol to begin your wellness journey with the very best in infrared therapy.
  • Page 3: Table Of Contents

    TA B L E O F C O N T E N T S PRE-INSTALLATION Specifications ....................4 Pre-Installation/Warnings ................6 OPERATING INSTRUCTIONS Control Screen/Initial Setup ............... 7 Sauna Settings ....................8 Health Programs .................... 11 Scheduling Sauna Sessions ................. 13 Media Apps .....................
  • Page 4: Specifications

    M P U L S E S E R I E S S P E C I F I C AT I O N S 5-20R aSPIRE USA / CAN Dimensions 43.6” x 41.6” x 78.6” 110.7 cm x 105.6 cm x 199.6 cm (W x L x H) Power 120v, 1820 watts, 20a...
  • Page 5 I N T E R N AT I O N A L E L E C T R I C A L S P E C I F I C AT I O N S REGION VOLTAGE/AMPS EXTERIOR POWER CORD Europe Aspire: 230V-7.5A Aspire: H07RN-F,250V-16A,Plug type: MT-32 or NS-13...
  • Page 6: Pre-Installation/Warnings

    P R E - I N S TA L L AT I O N Have a certified electrician install a dedicated outlet for sauna. Failure to do so will void all warranty. Remember your sauna should be assembled by 2 or more people. Do not place plumbing or plumbing fixtures in the sauna.
  • Page 7: Operating Instructions

    To turn On: Press and hold the power button in the lower right corner for 5 seconds, until the screen turns on. The screen will be blank for a few seconds before the Sunlighten logo appears. If left on, the tablet will go into sleep mode and can be woken by quickly touching the power button.
  • Page 8: Sauna Settings

    3. Settings/Setup In the SETTINGS tab, you will be able to adjust initial setup options. • Set up a wireless internet connection • Download latest software update • Watch basic usage tutorial • Adjust screen brightness • Select display mode (standard or simplified) •...
  • Page 9 6. Duration/Temperature Settings Standard: Rotate the time or temperature dials to your desired temperature. Simplified: Use the arrow buttons to adjust to your desired time or temperature. 7. Adjust Lights • Select Adjust Lights tab • For exterior lights, select on/off •...
  • Page 10 USB drive at: http://www.sunlighten.com/shop/mpulse-anywhere-access/ 11. Sunlighten Software Reset The Sunlighten Software Reset option does not erase application settings, those application settings are saved on an internal memory card. For factory data reset instructions visit sunlighten.com/customer-care 12. Create New User (Optional) If you are tracking your progress with a biofeedback device, you should set up a User profile.
  • Page 11: 13. Health Programs

    13. Health Programs The wellness programs are designed to emit the optimal blend of infrared wavelengths - based on 56 clinical studies - to achieve the desired result. To begin a program: • Select Health Program tab • Select the desired program from left side menu •...
  • Page 12 Preset Health Program Guide PROGRAM DURATION INFRARED USED Detoxification 37 Minutes Far / Mid Starts at a high intensity to increases the body’ s core temperature then reduces to a low, comfortable intensity level. IR combination improves vascular access flow to reach toxins at the cellular level. Relaxation 40 Minutes Far / Mid / Near...
  • Page 13: Scheduling Sauna Sessions

    14. Create A Program • Select Create Program • Enter a name, duration and set heaters to desired output. • Heaters can be set individually in segments adding up to 60 minutes • The length of a segment indicates how long a heater setting will run Edit or Delete a Custom Program: If you have one or more custom programs, the Delete and Edit options will be available.
  • Page 14: Media Apps

    16. Schedule a Session Use the Schedule feature to set a program to run automatically at a future time. The Android panel can not be ‘Shutdown’ as the scheduler will not power on the tablet to run a future program. Allow the screen to go in to low power mode, i.e., the screen is blacked out but still has power to allow a future schedule to power on the tablet.
  • Page 15 2. The radio must be in “AUX” mode to have sound output from the running application. Use the SRC on the stereo to set to R-Aux or Aux 3. With the latest Sunlighten App version on the ‘Settings and Setup Screen’ you will have the ability to download and install additional applications as they are released for installation.
  • Page 16 18. How to Play a Movie from USB Flash Drive Using the front USB port, plug in your USB flash drive and navigate to Media/Applications button. Select MXPlayer from the list. 19. Help Menu Visit this section for common FAQs for sauna use. Note: Diagnostic Software will run quick - checks and will not stop.
  • Page 17: Warm Up Time/Usage

    & room. REMEMBER, you are required to have an authorized Sunlighten cover over your sauna if it is outside or exposed to the weather in order to maintain your warranty.
  • Page 18: Sauna Protocol

    Drink at least 24 oz. of water or electrolyte to rehydrate. • Dry off with Bamboo Carbon Towel. Cool down naturally or with a refreshing shower. • Every six months, clean wood and glass with our Natural Sauna Cleaning Kit. Available at www.sunlighten.com/shop/...
  • Page 19: Faq

    ASSEMBLY Can I assemble my sauna outdoors? Yes, if you protect it with a Sunlighten canvas, sauna cover. If you place your sauna outdoors without a Sunlighten cover, your warranty will be void. The sauna covers are custom made and may not arrive until after you receive your sauna. Do not install your sauna outdoors prior to receiving your cover.
  • Page 20 What is the best temperature to use my sauna? First, it is important to understand that health benefits are a result of efficient infrared emissivity, not air temperature. Sunlighten saunas are 95-99% emissive to deliver the highest concentration of infrared. With that, the optimal sauna experience occurs between 100-130°F.
  • Page 21 Sunlighten All Natural Glass Cleaner. You may dust the outside of the sauna with a dry dust cloth. Do not use chemical cleaners on your sauna. Light sandpaper can be used to treat stains on the inside of the sauna. Sunlighten Natural Sauna Cleaning Kit can be purchased at sunlighten.com/shop.
  • Page 22: Troubleshooting

    T R O U B L E S H O O T I N G G U I D E ISSUE SOLUTION An electrical component Check all connections - see pg. 11. A newly assembled unit with a non- is not working after functioning electrical component (control panel, heater panels, lights, assembling speakers) will most likely have a missed or loose connection.
  • Page 23 E R R O R C O D E S & D I A G N O S T I C S DIAGNOSTIC RESULT CODES Error No. Cause/Solution The Control Panel cannot communicate with the Power Control Box. After unplugging your sauna, remake the connection of the computer cable (RS232) at the bottom of your front wall and the left side of the power box.
  • Page 24: Warranty

    Sunlighten Corp. shall not be liable for the loss of use of the sauna or other incidental or consequential damages. Under no circumstances shall Sunlighten Corp. or any of its representatives be held liable for injury to any persons or damages to any properties.
  • Page 25 ETL SAFETY CERTIFIED The ETL Listed Mark is proof of product compliance (electrical, gas and other safety standards) to North American safety standards. Authorities Having Jurisdiction (AHJ’s) in 50 states and Canada and retailers accept the ETL Listed Mark as proof of product safety.
  • Page 28 0 9 0 4 2 0 1 8 US / CAN 7373 W. 107th St. | Overland Park, KS 66212 913.754.0831 | sunlighten.com international support@sunlighten.com or contact your local Sunlighten representative...
