- Page 1 FINNPIPETTE PDP INSTRUCTIONS FOR USE OPERATING BUTTON GRIPPY HANDLE DIGITAL DISPLAY FINNTIP PDP Thermo Electron Oy P.O.Box 100, Fin-01621 Vantaa, Finland Tel. +358-9-329 100, fax -358-9-3291 0414 www.thermo.com/finnpipette...
-
Page 2: Product Description
[1] The Polymerase Chain Reaction process PCR, is covered by US patents issued to the Cetus Corporation. DESCRIPTION OF FINNTIP PDP (Fig.4) FINNPIPETTE PDP tips are supplied in racks of 96 or bags of 960. The product code numbers are as follows: Cat.No. - Page 3 TIP EJECTION (Fig.3) 1. To remove the tip and plunger from the pipette simply press the operating button all the way down. 2. Then release the operating button. 3. This action simutaneously ejects the tip and the plunger. PIPETTING TECHNIQUE Figure 6 A = Ready Position B = Pipetting Stop...
-
Page 4: Maintenance
MAINTENANCE When the FINNPIPETTE PDP is not in use make sure it is safely stored in a vertical position, preferably on a Finnpipette Stand. SHORT TERM CHECKING The pipette should be checked at the beginning of each day for dust and dirt on outside surfaces of the pipette. -
Page 5: Checking The Calibration
Test liquid: Water, distilled or deionized, “grade 3” water conforming ISO 3696. Tests are done in a draft-free room at a constant (±0.5°C) temperature of water, pipette and air between 20°C to 25°C. The relative humidity must be above 55%. Especially with volumes under 50 µl the air humidity should be as high as possible to reduce the effect of evaporation loss. - Page 6 = number of measurements cv is the relative value of standard deviation. cv = 100% x s / v PACKAGE The FINNPIPETTE PDP is shipped in a specially designed package containing the following items: 1. The pipette 2. Instruction manual 3. Service tool 4.
-
Page 7: Troubleshooting
TROUBLE SHOOTING The following table is a guide to possible problems and their solutions. Solution Fault Possible reason Attach firmly Leakage Tip incorrectly attached Clean tip cones Foreign bodies thoroughly and between tips and attach new tips tip cones Follow instructions Inaccurate Incorrect operation carefully... -
Page 8: Conversion Table
CONVERSION TABLE Value of the conversion factor Z (µl/mg), as a function of temperature and pressure, for distilled water. Temper- Air pressure ature °C hPA (mbar) 1013 1067 1.0018 1.0018 1.0019 1.0019 1.0020 1.0020 15.5 1.0018 1.0018 1.0019 1.0020 1.0020 1.0021 1.0019 1.0020 1.0020 1.0021 1.0021 1.0022 16.5 1.0020 1.0020 1.0021 1.0022 1.0022 1.0023... - Page 9 25 µl 200 µl...
- Page 10 Tip Ejection Pipetting...
-
Page 11: Spare Parts
No. Item Product Codes 25 µl 200 µl Service Tool 10589070 10589070 1057490 1057500 Handle Back 10588030 10588030 Limiter 1092990 1092990 Handle 2204030 2204040 Locking Pieces 1058180 1058180 Plunger 1106230 1106300 Oper. Spring 1130720 1130720 Ring 1006500 10. Tip Cone 1058790 10588000 11. - Page 12 Product specifications are subject to change without prior notice. Finpipette and Finntip are registered ® ® trademarks of Thermo Electron Oy. Thermo Electron Oy P.O.Box 100, Fin-01621 Vantaa, Finland Tel. +358-9-329 100, fax -358-9-3291 0414 www.thermo.com/finnpipette...
