Contura
RC500E Direct Vent Gas Fireplace
®
MODELS:
RC500E-NG Natural Gas
Warning
FIre or explosion Hazard
failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour:
919-877
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
RC500E-LP Propane
Installer: Please complete the details on the back cover
CSA 2.17-2017
ANSI Z21.88-2017
CSA 2.33-2017
Homeowner: Please keep these instructions for future reference.
and leave this manual with the homeowner.
Owners &
Installation Manual
10.12.18
Advertisement
Table of Contents
Related Manuals for Regency Contura RC500E
Summary of Contents for Regency Contura RC500E
- Page 1 Owners & Contura RC500E Direct Vent Gas Fireplace ® Installation Manual MODELS: RC500E-NG Natural Gas RC500E-LP Propane Warning FIre or explosion Hazard failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 The model RC500E has been approved by Intertek for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Stove.
-
Page 3: Table Of Contents
table of contents Copy of Safety Label .............4 Accent light bulb install ..........25 Unit dimensions with vertical venting ......5 4” x 6-5/8” Rigid Pipe Cross Reference Chart Unit dimensions with horizontal venting ......5 Rigid Horizontal or Vertical Terminations .....28 Gas line dimensions ............5 Venting Arrangements - vertical venting ......29 Venting Arrangements - Horizontal venting ....30 Collinear 3"... -
Page 4: Copy Of Safety Label
NOTE: Regency This is a copy of the label that accompanies ® units are constantly being each Direct Vent Freestanding Gas Stove. We improved. Check the label on the unit and if have printed a copy of the contents here for there is a difference, the label on the unit is your review. -
Page 5: Unit Dimensions With Vertical Venting
dimensions unit dimensions with vertical venting 18-13/16" (478mm) 22-1/8" (562mm) 17-1/4" (437mm) 19-5/16" (490mm) unit dimensions with horizontal venting gas line dimensions 22-13/16" (579mm) 18-13/16" (478mm) 4-5/16” knock out gas line R2-3/16” 5-3/8” 19-5/16" to C/L base of unit (490mm) RC500E |... - Page 6 MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency product has been tested and listed by Intertek as a Direct Vent Wall Furnace to the following ® standards: VENTED GAS FIREPLACE HEATERS ANSI Z21.88-2017 / CSA 2.33-2017 and GAS-FIRED APPLIANCES FOR USE AT HIGH ALTITUDES CAN / CGA 2.17-M91.
- Page 7 WARNING CARBON MONOXIDE POISONING HAZARD Failure to follow the steps outlined below for each appliance connected to the venting system being placed into operation could result in carbon monoxide poisoning or death. The following steps shall be followed for each appliance connected to the venting system being placed into operation, while all other appliances connected to the venting system are not in operation: 1.
-
Page 8: Owner's Information
owner's information Remote/Receiver coding To code the receiver to the hand held remote, follow the procedure below. 1. Open the lower door on the unit. 2. Plug in 120 volt power cord into a grounded receptacle or install 4 AA batteries into battery pack and plug into battery terminals located near the gas valve. -
Page 9: Important Message
Electrical Code CSA C22.1 in Canada. CHILDREN AND ADULTS SHOULD BE jurisdiction to determine the need for a permit prior to starting the installation. ALERTED TO THE HAZARDS OF HIGH This Regency Mobile/Manufactured Home ® SURFACE TEMPERATURES, ESPE- Listed appliance comes factory equipped with... -
Page 10: Lighting Procedure
owner's information lighting procedure Note: The first try for ignition will last approximately 60 seconds. If there is no IMPORTANT: The remote control system supplied with this appliance has several options for starting/operating the appliance using the power button flame ignition (rectification) the board will stop sparking for approximately and ON/OFF key on the hand held transmitter. -
Page 11: Copy Of The Lighting Plate Instructions
owner's information copy of the lighting plate instructions FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 12: Proflame Ii Remote Control Operating Instructions
owner's information PROFLAME II REMOTE CONTROL OPERATING INSTRUCTIONS proflame 2 remote control operating Instructions IMPORTANT:The Proflame Transmitter 2 is an integrated part of the TECHNICAL DATA Proflame 2 System, which consists of these elements: • Proflame 2 Transmitter, to be used in conjunction with: REMOTE CONTROL •... - Page 13 owner's information Temperature indication Display Remote-Flame Control With the system in the "OFF" position, press the Thermostat Key and The profl ame has six (6) fl ame levels. With the system on, and the fl ame the Mode Key at the same time. Look at the LCD screen on the transmit- level at the maximum in the appliance, pressing the Down Arrow Key ter to verify that a C or F is visible to the right of the room temperature once will reduce the fl...
- Page 14 owner's information Smart Thermostat (Transmitter Operation) Remote dimmer control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The Smart Thermostat function adjusts the fl ame height in accordance light control. To activate this function use the Mode Key (fi g. 1) to index to the difference to the AUX icon (fi...
-
Page 15: First Fire
Note: When the glass is cold and the appliance is lit, it may cause All Regency stoves ship with a full function remote condensation and fog the glass. control as standard equipment. This allows for basic This condensation is normal and... - Page 16 maintenance KEY LOCK Continous Pilot/Intermittent Pilot (CPI/IPI) selection With the system in "OFF" position press the Mode Key (fi g. 1) to index This function will lock the keys to avoid unsupervised operation. to the CPI mode icon (fi g. 19 & 20). To activate this function, press the MODE and UP Keys at the same Pressing the Up Arrow Key will activate the Continous Pilot Ignition mode time (fi...
-
Page 17: Opening The Front Glass Door
owner's information opening the front glass door 1. Open lower door on unit by pulling forward. 2. Locate latch behind right handle, pull latch down. 3. Front of latch will drop down and release door handle. Pull door handle forward to open door. Handle Latch located behind handle... -
Page 18: Safety Screen Installation / Removal
installation safety screen installation / removal The safety screens must be installed and kept on the unit at all times. 1. Open front door -- see instructions in manual (P. 15). 2. Install the front safety screen by hooking the screen over the front door-- then close the door. -
Page 19: General Vent Maintenance
In the event that you break your glass by impact, purchase 1. Check the Venting System for corrosion in areas your replacement door from an authorized Regency ® that are exposed to the elements. These will... -
Page 20: Outside Side Glass Replacement
owner's information outside side glass accent light bulb fan maintenance / replacement tooltip replacement replacement If your fan requires maintenance or replacement, access to the fan is through the rear access panel 1. Turn off stove and allow it to return to room 1. -
Page 21: Installer's Information
requirements installer's information MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 22: General Safety Information
installer's information general safety installation 1. Provide adequate clearances for servicing, proper operation and around the air openings information checklist into the combustion chamber. 1. Locate your appliance. Refer to the following 1. The appliance installation must conform with 2. The appliance must be installed on a flat, solid, sections: local Canadian Electrical Code. -
Page 23: Venting Introduction
installation venting installation safety precautions for introduction precautions the installer The Horizontal Termination Kit and other approved These venting systems are engineered products 1. Wear gloves and safety glasses for protection. venting systems as per table on next page, in that have been designed and tested for use with the combination with the Direct Vent Freestanding Gas RC500E. -
Page 24: Exterior Vent Terminal Locations
installation Exterior Vent Terminal Locations Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 22"(56cm) 22"(56cm) from the center line of the terminal (check with the local code) -
Page 25: Clearances To Combustibles
installation clearances to locating your accent light bulb combustibles gas stove install tooltip Accent light bulbs are packed in the manual When selecting a location for your stove, ensure The clearances listed are MINIMUM distances. pack. that the clearances listed above are met as well Measure the clearance to both the appliance and as ensuring that there is adequate accessibility the chimney connector. -
Page 26: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: The listed manufacturers may have other lengths not shown on this chart, which would also be approved. - Page 27 installation Description Selkirk American Metal Security ICC Excel Olympia Simpson Metal-Fab™ Ventis DV* Direct Temp™ Products® Secure- Vent® Direct Direct Vent Pro ® Sure Seal Amerivent Direct Attic Insulation Shield 12” 46DVA-IS 4DAIS12 SV4RSA VDV-AIS04 N/A@ FPI Attic Insulation Shield 4DAIS12 TM-4AS - Cold Climates 36”...
-
Page 28: Rigid Horizontal Or Vertical Terminations
installation Rigid Pipe Venting Systems Horizontal or Vertical Terminations Non-metallic venting systems shall not interchange components with another listed or unlisted metallic vent system. Alternate Vertical Horizontal Termination Termination Caps Storm Collar Vinyl Siding Standoff (Optional) Flashing Horizontal Termination Ceiling Firestop Wall Thimble Pipe Length Adj.Pipe Length... -
Page 29: Venting Arrangements - Vertical Venting
installation Venting Arrangements - vertical venting Important: The IPI/CPI switch on the hand-held remote control transmitter must be turned to CPI (Continuous Pilot Ignition) at all times. This will avoid nuisance pilot outages during operation of this appliance when using these venting configurations on this page. See Remote manual for setup of this IPI/CPI switch Horizontal (Feet) Vent Restrictor on Set 3 CPI MODE... -
Page 30: Venting Arrangements - Horizontal Venting
installation Venting Arrangements - Horizontal venting Vent Restrictor Set 2 No Vent Restrictor (Factory Set) 40-5/16" (1022mm) | RC500E... - Page 31 installation Horizontal Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option H + H1 With these options, maxi- mum total pipe length is 30 2' Min. 4' Max. feet with minimum of 6 feet 3' Min. 5' Max.
- Page 32 installation Vertical Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option V V + V1 With these options, max. total pipe length is 30 feet with min. 1' Min. 4' Max. 2' Min. of 6 feet total vertical and max. 2' Min.
-
Page 33: Collinear 3" - 3" Flex Pipe Venting
installation co-linear 3" - 3" flex pipe venting (masonry chimney applications only) Important: The IPI/CPI switch on the hand-held remote control transmitter must be turned to CPI (Continuous Pilot Ignition) at all times. This will avoid nuisance pilot outages during operation of this appliance when using these venting configurations on this page. See Remote manual for setup of this IPI/CPI switch. -
Page 34: Vertical Termination With Co-Linear Flex System
installation vertical termination with co-linear flex system THE APPLIANCE MUST NOT BE Masonry chimneys may take various contours which the flexible liner will ac- CONNECTED TO A CHIMNEY FLUE commodate. However, keep the flexible liner as straight as possible, avoid SERVING A SEPARATE SOLID FUEL unnecessary bending. -
Page 35: Dv Stove Horizontal Vent Kit
installation dv stove horizontal vent kit DV 2 ft. Stove Vent Kit (Part # 946-116) and DV 4 ft. Stove Vent Kit (946- 216) includes all the parts needed to install the RC500E Direct Vent unit with minimum horizontal and vertical vent dimensions. For installations that require longer vertical and/or horizontal vents use the Dura-Vent system as shown in AstroCap Thimble... - Page 36 installation Hint: leave an extra 12" to 16" of length, this will make the final assembly easier to work with. 9. Secure the 4" dia. flex liner to the 4" adapter with Mill-Pac and 3 of the #8 x 1/2" screws (stainless steel).
-
Page 37: Residential And Manufactured Homes / Mobile Homes Minimum Horizontal Termination Installations
installation Residential and Manufactured Homes / Mobile Homes Minimum Horizontal Termination Installations Planning Your Venting Installation See the "Exterior Vent Terminal Locations" You will require the following components with your new RC500E Direct Vent Freestanding Gas Stove. section for requirements. Please review your product to make sure you have everything you need. - Page 38 / mobile homes minimum horizontal termination installations Planning Your venting Installation You will require the following components with your new Regency Rear Vent Direct Vent Freestand- ® See the "Exterior Vent Terminal Locations" ing Gas Stove. Please review your product to make sure you have everything you need. In the section for requirements.
-
Page 39: Dura-Vent Termination Kit
installation dura-vent termination kit thimble is suitable for 2 x 4 or 2 x 6 wall construc- Be sure to check the vent termination clearance Planning Your Dura-Vent tion.) Select the amount of vertical rise desired requirements from decks, windows, soffits, gas Installation for "vertical-to-horizontal"... -
Page 40: Horizontal Terminations
installation 2. Assemble the desired combination of pipe You will require the following components with and elbow to the appliance adapter with pipe Riser Vent your new Direct Vent Freestanding Gas Stove. Termination seams oriented down. Offset the pipe seams Please review your product to make sure you as double seams in one place will cause the have everything you need. -
Page 41: Vertical Terminations
installation c) Before connecting the vent pipe to the vent termination, slide the black decorative wall thimble cover over the vent pipe, then slide the Wall Penetration Heat Shield over the vent pipe. Dia. 3. d) Slide the appliance and vent assembly towards the wall carefully inserting the vent pipe into the riser vent terminal assembly. - Page 42 installation 7. Ensure vent is vertical and secure the base of the flashing to the roof with roofing rails, slide storm collar over the pipe section and seal with a mastic. 8. Install the vertical termination cap by twist locking it. Notes: a) For multi-storey vertical installations, a Ceiling Fire stop is required at the...
-
Page 43: Converting Class-A Metal Chimney To Direct Vent System
installation converting class-a 4. Pass the flex pipe down through the center of the chimney system, and center the adaptor metal chimney to Termination on the top of the chimney pipe. Drill four 1/8" direct vent system diameter holes through the adaptor and into Top Adaptor the chimney top. -
Page 44: Cathedral Ceilings
installation Note: If you are using a 6" square sup- 8. Ensure vent is vertical and secure the base of Since some municipalities have additional local the flashing to the roof with roofing rails, slide codes it is always best to consult with your local port you may find it difficult to storm collar over the pipe section and seal with authorities and the CAN/CGA B149 installation... -
Page 45: Aeration Adjustment
Natural Gas 1/4" (6.4 mm) Note: Aeration Adjustment should only be performed by an authorized Propane Fully open Regency Installer at the time of ® Note: Air shutter setting is the same regardless installation or service. of the media/log set installed. -
Page 46: Opening The Front Glass Door
installation opening the front glass door 1. Open lower door on unit by pulling forward. 2. Locate latch behind right handle, pull latch down. 3. Front of latch will drop down and release door handle. Pull door handle forward to open door. Handle Latch located behind handle... -
Page 47: Front Grill Removal / Installation
installation front grill removal / installation The front grill is easily removed to allow easier access for removing the burner or inner panels - follow steps below to remove. 1. Remove 2 screws from the front of 2. Slide out lower plate securing the grill, then lift 3. -
Page 48: Enamel Panel Installation
RC500E installation ENAMEL PANEL INSTALLATION enamel panel installation The same screws that released the baffle will release the Shut off the unit and allow to cool to room temperature. steel inner panel. Lift off the front safety screen (if installed) and open the front door (see details in manual). -
Page 49: Conversion Kit From Ng To Lp
installation RC500E conversion kit from NG to LP CONVERSION KIT FROM NG TO LP THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! Loosen right side screw on pilot hood cover. Pivot cover to the WARNING left to reveal pilot hood. - Page 50 installation 19. Reverse steps 6 through 1. 13. Disconnect the NG stepper motor wires from the IFC (Intermittent Fireplace Control) in locations shown below. 20. Ensure the pilot light is in the correct orientation to the Burner. Reconnect the gas and electrical supply to the appliance. Start the appliance.
-
Page 51: Log Set Installation
installation RC500E log set installation LOG INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty. *Paint is included if touch ups are required. - Page 52 RC500E installation 8. Ensure Logs 2 & 3 are still connected after installing onto the burner. 11. Install Log 5 - place darker in of the log into the triangle created by From the left side - push left side of Log 1 forward until it is touching Logs 1,2 &...
- Page 53 RC500E installation 14. 3lb of glass crushed glass installed on the burner - there will be 17. Log 7 should touch Log 3 when in position, as shown below. 1/2lb leftover. Log 7 placement Glass Crystal amount 18. Place the glowing wool on the crushed glass as shown below. 15.
-
Page 54: Optional Media Installation
installation optional media - crushed glass and volcanic stone installation A combination of glass crystals and volcanic stones can be installed on the 4. Re-install burner. burner as an option to the log set. 5. Spread the crushed glass evenly on the burner and place the volcanic Shut off the gas and electrical supply. -
Page 55: Optional Wall Thermostat
installation optional wall thermostat manual operation final check (no remote) A wall thermostat may be installed if desired. Before leaving this unit with the customer, the installer Connect the wires as per the wiring diagrams. must ensure that the appliance is firing correctly. To override the remote - open the front lower This includes: door and locate the reset button. -
Page 56: Wiring Diagram Without Thermostat
installation wiring diagram without thermostat If any of the original wires as supplied with the appliance must be replaced, it must be replaced with CSA type SEW (200 C) or its equivalent. This heater does not require a 120V A.C. supply for operation. In case of a power failure, the burner switch and the optional remote control/thermostat will continue to operate. -
Page 57: Wiring Diagram With Thermostat
operating instructions wiring diagram with thermostat SPARK GREEN MAIN BLACK LINE BLACK FLAME DETECT Thermostat( Optional) (Millivolt) GREY BATTERY HOLDER GREY ON/OFF ON/OFF SWITCH BAT -/+ IPI/CPI EV GND YELLOW/GREEN EV P/M ORANGE GREEN BLACK MOTOR BROWN YELLOW ORANGE SPLIT FLOW BLACK BLACK BLACK... -
Page 58: Lighting Procedure
operating instructions lighting procedure Note: The first try for ignition will last approximately 60 seconds. If there is no IMPORTANT: The remote control system supplied with this appliance has several options for starting/operating the appliance using the power button flame ignition (rectification) the board will stop sparking for approximately and ON/OFF key on the hand held transmitter. -
Page 59: Copy Of The Lighting Plate Instructions
operating instructions copy of the lighting plate instructions FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 60: Normal Operating Sounds Of Gas Appliances
Note: If you have an incorrect flame pat- body. Therefore, the varying thicknesses of steel that the flow of combustion and ventilation air will expand and contract at slightly different rates tern, contact your Regency dealer ® is not obstructed. -
Page 61: Glass Gasket
Note: Do not touch bulb with bare hands, use gloves Push the pipe sections completely together, the Regency dealer only. Replacement glass is shipped or a tissue to handle bulb. minimum pipe overlap is 1-1/4". Secure all outer already installed into the door frame. -
Page 62: Main Assembly
parts list Main assembly 6 7 8 9 12 | RC500E... - Page 63 parts list Main Assembly 366-574/P Valve Assembly - NG 366-576/P Valve Assembly - LP 911-084 Novasit Valve NG 885 SIT IPI 0.885.001 911-085 Novasit Valve LP 885 SIT IPI 0.885.002 904-162 Burner Orifice #43 NG 904-163 Burner Orifice #54 LP 911-006 Pilot Assembly IPI NG 2 Flame 0.199.050 911-007...
- Page 64 parts list Main Assembly 366-079 Inner Back Curved Panel 366-051 Top Baffle 366-047 Light Housing 366-045 Light Shield 911-072 Halogen bulb G9/120V/25W (High Temp) 366-085 Air Adjustement Cover Plate 932-009 Tubing SS Flexible 3/8 x 9 inch 904-599 Fitting Elbow 90 Degree (Located At Orifice End) 904-633 Connector 3/8 Comp x 3/8 Male 904-600...
- Page 65 parts list 936-271 Glass Gasket Tadpole Tape 1 1/2 (Sold Per Foot) (6 Feet required) 366-074 Lytherm White Gasket Inner Side Glass (Each) 366-075 Lytherm White Gasket Inner Front Glass 936-238 Outer Side Glass Gasket (Sold Per Foot) 366-549 Glass Clips/Screws Complete Package 366-046 Light Socket Bracket (ea) 366-086F...
-
Page 66: Warranty
Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase. - Page 67 notes RC500E |...
- Page 68 FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. Revision Date: December 2016 Regency Gas Products Warranty | RC500E...
- Page 69 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: December 2016 Regency Gas Products Warranty RC500E |...
- Page 70 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 72 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Printed in Canada Regency and AstroCap™ are trademarks of FPI Fireplace Products International Ltd. ® © Copyright 2018, FPI Fireplace Products International Ltd. All rights reserved.
