Contura
RC500EX Direct Vent Gas Fireplace
®
MODELS:
RC500EX-NG Natural Gas
Warning
Fire or Explosion Hazard
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour: CSA/ANSI 2.17:19
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-514
RC500EX-LP Propane
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
CSA 2.33:19
CSA 2.17-2017
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
07.26.22
Advertisement
Table of Contents
Related Manuals for Regency Contura RC500EX
Summary of Contents for Regency Contura RC500EX
- Page 1 Owners & Contura RC500EX Direct Vent Gas Fireplace ® Installation Manual MODELS: RC500EX-NG Natural Gas RC500EX-LP Propane Warning Fire or Explosion Hazard Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 The model RC500EX has been approved by Intertek for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Stove.
-
Page 3: Table Of Contents
table of contents Installation Precautions ............. 25 Copy of Safety Label ............4 Safety Precautions for the Installer ........25 Unit Dimensions with Vertical Venting ........5 Vent Restrictor Position ............. 25 Unit Dimensions with Horizontal Venting ......5 Reversible Flue Collar ............25 Gas Line Dimensions ............5 Exterior Vent Terminal Locations ........ -
Page 4: Copy Of Safety Label
This is a copy of the label that accompanies NOTE: Regency units are constantly being ® each Direct Vent Freestanding Gas Stove. We improved. Check the label on the unit and if have printed a copy of the contents here for there is a difference, the label on the unit is your review. -
Page 5: Unit Dimensions With Vertical Venting
dimensions Unit Dimensions With Vertical Venting 18-13/16" (478mm) 22-1/8" (562mm) 17-1/4" (437mm) 19-5/16" (490mm) Unit Dimensions With Horizontal Venting Gas Line Dimensions 22-13/16" (579mm) 18-13/16" (478mm) 4-5/16" knock out 4-5/16” knock out If exiting from base of appliance Gas line-If exiting from gas line rear of appliance 19-5/16"... -
Page 6: Manufactured Mobile Home Requirements
MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency product has been tested and listed by Intertek as a Direct Vent Wall Furnace to the following ® standards: VENTED GAS FIREPLACE HEATERS ANSI Z21.88:19 / CSA 2.33:19 and GAS-FIRED APPLIANCES FOR USE AT HIGH ALTITUDES CAN / CGA 2.17-M91. -
Page 7: Warning Carbon Monoxide Poisoning Hazard
WARNING CARBON MONOXIDE POISONING HAZARD Failure to follow the steps outlined below for each appliance connected to the venting system being placed into operation could result in carbon monoxide poisoning or death. The following steps shall be followed for each appliance connected to the venting system being placed into operation, while all other appliances connected to the venting system are not in operation: 1. -
Page 8: Ma Code - Co Detector
installer's information MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 9: Gas Installation Checklist
This general checklist does not contain all pertinent installation details or specifics and does not supersede the guidelines in this manual. Your Regency dealer/installer should use it in conjunction with manual instructions. Please follow all local codes and jurisdictions in authority. - Page 10 REGENCY GAS INSTALLATION CHECKLIST Finishing If applicable, is only noncombustible material installed in the noncombustible areas? Do clearances meet installation and manual requirements? Do the mantels and/or projections comply with the installation manual? If applicable, was the solid fuel fireplace warning plate installed?
-
Page 11: Owner's Information
owner's information Remote/Receiver Pairing This remote is paired with the control module. If this ever requires programming/pairing, refer to program/pair the remote control to the ignition control board as per below. To code the receiver to the hand held remote, follow the procedure below. -
Page 12: Lighting Procedure
owner's information Lighting Procedure 1) STOP! Read the safety information above on this label. 2) Ensure the three-way switch on the ignition control module is in the ON/MANUAL <REMOTE> position and the dry contact/remote override toggle switch is in the <OFF/REMOTE> position. OFF/REMOTE 4) The pilot valve will open and the ignition (spark) will start (up to 90 seconds maximum). -
Page 13: Important Message
Electrical Code CSA C22.1 in Canada. CHILDREN AND ADULTS SHOULD jurisdiction to determine the need for a permit prior to starting the installation. BE ALERTED TO THE HAZARDS OF This Regency Mobile/Manufactured Home ® HIGH SURFACE TEMPERATURES, Listed appliance comes factory equipped with... -
Page 14: Copy Of The Lighting Plate Instructions
owner's information Copy of the Lighting Plate Instructions FOR YOUR SAFETY READ BEFORE LIGHTING POUR VOTRE SÉCURITÉ – À LIRE AVANT LA MISE EN MARCHE WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 15: Remote Control Operating Instructions
owner's information DEXEN Operating Instructions U39EX Remote Control Operating Instructions FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLING OR OPERATING THIS CONTROL COULD CAUSE PERSONAL INJURY AND/OR PROPERTY DAMAGE. DESCRIPTION The TX580 multifunctional remote control was designed for maximum compatibility with hearth products. - Page 16 owner's information DISPLAY SCREEN (NOT AVAILABLE) (NOT AVAILABLE) (NOT AVAILABLE) CONTINUOUS PILOT FUNCTION BUTTONS Button Function Button Function ''Power Button'' “Mode Button” Use to turn the unit on and off. Used to access the AUX component and Split burner. (Not available) “Thermostat / Timer Button”...
- Page 17 U39EX owner's information OPERATION This remote is paired with the control module. If this ever requires programming/pairing, refer to this manual to program/pair the remote control to the ignition control board. Operation Content: Adjusting Light Intensity: 1. Press the “Light Button” to control the light intensity. Temperature Unit Selection 2.
- Page 18 owner's information Cancelling Thermostat/Timer: 1. Press the “Thermostat / Timer Button” to select the “FLAME HEIGHT” on the remote display. 2. “FLAME HEIGHT” will flash on the remote display. 3. Use the “Flame Button” to select the flame height between 1 (min) to 5 (max).
-
Page 19: First Fire
owner's information First Fire restored. If the remote is misplaced, the unit can be shut off by flipping the main ON/OFF switch, located behind the front cover plate, to The first fire in your stove is part of the paint curing the OFF position. -
Page 20: Opening The Front Glass Door
owner's information Opening the Front Glass Door 1. Open lower door on unit by pulling forward. 2. Locate latch behind right handle, pull latch down. 3. Front of latch will drop down and release door handle. Pull door handle forward to open door. Handle Latch located behind handle... -
Page 21: Safety Screen Installation / Removal
owner's information Safety Screen Installation / Removal The safety screens must be installed and kept on the unit at all times. 1. Remove stove top—see instructions in manual. 2. Install front screen bracket over left side (nonfunctional door handle). t t o o o o l l t t i i p p 3. -
Page 22: General Vent Maintenance
1. Check the Venting System for corrosion in areas purchase your replacement door from an authorized that are exposed to the elements. These will Regency dealer only, and follow our step-by-step ® appear as rust spots or streaks, and in extreme instructions for replacement. -
Page 23: Outside Side Glass Replacement
owner's information Outside Side Glass Accent Light Bulb Fan Maintenance / t t o o o o l l t t i i p p Replacement Replacement Replacement If your fan requires maintenance or replacement, 1. Turn off stove and allow it to return to room 1. -
Page 24: Installer's Information
installer's information General Safety Information Installation Checklist 1. Provide adequate clearances for servicing, proper operation and around the air openings into the combustion chamber. 1. Locate your appliance. Refer to the following 1. The appliance installation must conform with sections: local Canadian Electrical Code. -
Page 25: Venting Introduction
installation Venting Introduction Installation Precautions Safety Precautions for the Installer The Horizontal Termination Kit and other approved These venting systems are engineered products venting systems as per table on next page, in that have been designed and tested for use with the 1. -
Page 26: Exterior Vent Terminal Locations
installation Exterior Vent Terminal Locations Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 22"(56cm) 22"(56cm) from the center line of the terminal (check with the local code) -
Page 27: Clearances To Combustibles
installation t t o o o o l l t t i i p p Clearances to Combustibles Locating Your Gas Stove Accent Light Bulb Install 1. Turn off stove and allow to return to room When selecting a location for your stove, ensure The clearances listed are MINIMUM distances. -
Page 28: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
Note: Olympia Ventis DV venting is only approved for certain models. See list of approved models in cross-reference chart. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: Olympia Ventis DV venting is only approved for certain models. See list of approved models in cross-reference chart. - Page 29 TM-4TR VDV-FS04 * Not available from Regency ***Olympia Ventis DV application for the following units only when using 4" x 6-5/8" vent system: B36XTE, B36XTCE, all City Series 40 models, CV72E/CB72E (power-vented models only), G600C, G600C-1, G600EC, G800C, G800C-1, G800EC, P36, P36E, and RC500E.
-
Page 30: Rigid Pipe Venting Systems
installation Rigid Pipe Venting Systems Horizontal or Vertical Terminations Non-metallic venting systems shall not interchange components with another listed or unlisted metallic vent system. Alternate Vertical Horizontal Termination Termination Caps Storm Collar Vinyl Siding Standoff (Optional) Flashing Horizontal Termination Ceiling Firestop Wall Thimble Pipe Length Adj.Pipe Length... -
Page 31: Venting Arrangements - Vertical Venting
installation Venting Arrangements - Vertical Venting Horizontal Terminations for All Venting Systems The shaded areas in the diagram below show all allowable combinations of vertical runs with horizontal terminations. Maximum one 90 elbow (two 45 elbows equal one 90 elbow). Important: The IPI/CPI switch on the hand-held remote control transmitter must be turned to CPI (Continuous Pilot Ignition) at all times. -
Page 32: Venting Arrangements - Horizontal Venting
installation Venting Arrangements - Horizontal Venting Vent Restrictor Set 2 No Vent Restrictor (Factory Set) 40-5/16" (1022mm) **Note: If termination is rear vented at a minimum to centerline height of 40-5/16" (1022 mm) and horizontal length greater than 12" (305 mm) to a maximum of 18" (457 mm), only a rear vent riser or snorkel may be used. See manual for details. | RC500EX... - Page 33 installation Horizontal Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option H + H1 With these options, maxi- mum total pipe length is 30 2' Min. 4' Max. feet with minimum of 6 feet total vertical and maximum 3' Min.
- Page 34 installation Vertical Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option V + V1 With these options, max. total pipe length is 30 feet 1' Min. 4' Max. 2' Min. with min. of 6 feet total vertical and max.
-
Page 35: Co-Linear 3" - 3" Flex Pipe Venting
installation Co-Linear 3" - 3" Flex Pipe Venting (Masonry Chimney Applications Only) Important: The IPI/CPI switch on the hand-held remote control transmitter must be turned to CPI (Continuous Pilot Ignition) at all times. This will avoid nuisance pilot outages during operation of this appliance when using these venting configurations on this page. See Remote manual for setup of this IPI/CPI switch. -
Page 36: Vertical Termination With Co-Linear Flex System
installation Vertical Termination With Co-Linear Flex System THE APPLIANCE MUST NOT BE Masonry chimneys may take various contours which the flexible liner will ac- CONNECTED TO A CHIMNEY FLUE commodate. However, keep the flexible liner as straight as possible, avoid SERVING A SEPARATE SOLID FUEL unnecessary bending. -
Page 37: Dv Stove Horizontal Vent Kit
installation Direct Vent Stove Horizontal Vent Kit Direct Vent 2 ft. Stove Vent Kit (Part # 946-116) and DV 4 ft. Stove Vent Kit (946-216) includes all the parts needed to install the RC500E Direct Vent unit with minimum horizontal and vertical vent dimensions. For installations that require longer vertical and/or horizontal vents use the Dura-Vent sys- AstroCap Thimble... - Page 38 installation 12. Install the spring spacers onto the pipe sections. 13. Secure the 4" dia. flex liner with adapter onto the stove collar. Put a bead of Mill-Pac around the appliance adapter and secure with 3 screws (#8 x 1/2, stainless steel). 14.
-
Page 39: Residential And Manufactured Homes / Mobile Homes Minimum Horizontal Termination Installations
installation Residential and Manufactured Homes / Mobile Homes Minimum Horizontal Termination Installations Planning Your Venting Installation Note: These are the minimum pieces required. Other parts may be required for See the "Exterior Vent Terminal Locations" your particular installation. section for requirements. Minimum components for a Horizontal Installation: When planning your installation, it will be necessary 380-946... -
Page 40: Dura-Vent Termination Kit
installation Dura-Vent Termination Kit Planning Your Dura-Vent Warning: Always maintain required Be sure to check the vent termination clearance requirements from decks, windows, soffits, gas Installation clearances (air spaces) to nearby regulators, air supply inlets and public walkways as combustibles to prevent a fire specified in the "Exterior Vent Terminal Locations"... -
Page 41: Horizontal Terminations
installation 2. Assemble the desired combination of pipe and NOTE: For Snorkel terminations in ABOVE You will require the following components with your elbow to the appliance adapter with pipe seams new Direct Vent Freestanding Gas Stove. Please oriented down. Offset the pipe seams as double grade installations, follow national review your product to make sure you have every- seams in one place will cause the outer pipe to... -
Page 42: Vertical Terminations
installation If installing riser vent terminal, follow steps c) Before connecting the vent pipe to the below: vent termination, slide the black deco- rative wall thimble cover over the vent 1. Take the Riser Vent terminal and separate pipe, then slide the Wall Penetration the Backing Plate from the Riser Vent Front Heat Shield over the vent pipe. - Page 43 installation 6. Continue to assemble pipe lengths. 7. Ensure vent is vertical and secure the base of the flashing to the roof with roofing rails, Note: If an offset is necessary in the slide storm collar over the pipe section and attic to avoid obstructions, it is seal with a mastic.
-
Page 44: Converting Class A Metal Chimney To Direct Vent System
installation Converting Class A Metal 4. Pass the flex pipe down through the center of the chimney system, and center the adaptor Chimney to Direct Vent System Termination on the top of the chimney pipe. Drill four 1/8" diameter holes through the adaptor and into Top Adaptor the chimney top. -
Page 45: Cathedral Ceilings
installation Note: If you are using a 6" square sup- 8. Ensure vent is vertical and secure the base of Since some municipalities have additional local the flashing to the roof with roofing rails, slide port you may find it difficult to codes it is always best to consult with your local storm collar over the pipe section and seal with authorities and the CAN/CGA B149 installation... -
Page 46: Aeration Adjustment
Note: Aeration Adjustment should only Pilot Outlet be performed by an authorized Propane Fully open Main Gas Outlet Regency Installer at the time of ® Main Gas Inlet installation or service. Note: Air shutter setting is the same regardless of the media/log set installed. -
Page 47: Opening The Front Glass Door
installation Opening the Front Glass Door 1. Open lower door on unit by pulling forward. 2. Locate latch behind right handle, pull latch down. 3. Front of latch will drop down and release door handle. Pull door handle forward to open door. Handle Latch located behind handle... -
Page 48: Front Grill Removal / Installation
installation installation Front Grill Removal / Installation Front Grill Removal / Installation The front grill is easily removed to allow easier access for removing the burner or inner panels - follow steps below to remove. The front grill is easily removed to allow easier access for removing the burner or inner panels - follow steps below to remove. 1. -
Page 49: Enamel Panel Installation
RC500E installation ENAMEL PANEL INSTALLATION Enamel Panel Installation Remove the 2 lower screws to remove the steel inner panels. Shut off the unit and allow to cool to room temperature. tooltip Lift off the front safety screen (if installed) and open the front door (see details in manual). -
Page 50: Conversion Kit From Ng To Lp
installation Conversion Kit From NG to LP Conversion from NG to LPG RC500EX THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 7. Slide the three-way switch on the ignition Each Kit contains one LP control module to ''OFF'' position. Conversion Kit #367-969 NG Conversion Kit Contains: Qty. - Page 51 installation LP Setting 16. Slide the control module to remote position. Remote 17. Install the burner. Set the burner aeration to full open for LP. See aeration adjustment details in the manual. 18. Open the gas line. Check for gas leaks with a proper soapy solution or leak detector. 19. Attach the label "This unit has been converted to LPG" near or on top of the serial # decal. 20. Replace yellow "NG" label with red "LPG" label. 21. Reinstall logs, media, door, access panel and pedestal door. Turn ON the electrical supply. 22. Turn ON using the remote control (the remote control is still with the control module).
-
Page 52: Log Set Installation
RC500E installation LOG INSTALLATION Log Set Installation Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty. *Paint is included if touch ups are required. - Page 53 RC500E installation 8. Ensure Logs 2 & 3 are still connected after installing onto the burner. 11. Install Log 5 - place darker end of the log into the triangle created From the left side - push left side of Log 1 forward until it is touching by Logs 1,2 &...
- Page 54 RC500E installation 14. 3lb of glass crushed glass installed on the burner - there will be 17. Log 7 should touch Log 3 when in position, as shown below. 1/2lb leftover. Log 7 placement Glass Crystal amount 18. Place the glowing wool on the crushed glass as shown below. 15.
-
Page 55: Optional Media Installation
installation installation Optional Media - Crushed Glass and Volcanic Stone Installation Optional Media - Crushed Glass and Volcanic Stone Installation A combination of glass crystals and volcanic stones can be installed on the burner as an option to the log set. A combination of glass crystals and volcanic stones can be installed on the burner as an option to the log set. -
Page 56: Optional Wall Thermostat
Wall Thermostat Any alteration to the product that causes sooting or carboning that results in damage All Regency stoves ship with a full function remote to the exterior facia is not the responsibility control as standard equipment. This allows for of the manufacturer. -
Page 57: Wiring Diagram With Optional Wall Thermostat
Do not Regency® offers an optional programmable cut or remove the grounding thermostat but any 250-750 millivolt rated non prong from this plug. -
Page 58: Copy Of The Lighting Plate Instructions
operating instructions Copy of the Lighting Plate Instructions FOR YOUR SAFETY READ BEFORE LIGHTING POUR VOTRE SÉCURITÉ – À LIRE AVANT LA MISE EN MARCHE WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 59: Normal Operating Sounds Of Gas Appliances
Note: If you have an incorrect flame by a qualified field service person, to ensure and body. Therefore, the varying thicknesses of pattern, contact your Regency ® that the flow of combustion and ventilation air steel will expand and contract at slightly different dealer for further instructions. -
Page 60: Glass Gasket
In the event that you break your glass by impact, steps to reinstall. purchase your replacement from an authorized Vent Reassembly / Regency dealer only. Replacement glass is shipped Replacement already installed into the door frame. Reinstall as per Glass Installation in the "Glass Installation" section. -
Page 61: Gas Maintenance
Gas Maintenance Gas Maintenance Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) • Burner ports & burner air shutter • Pressure relief gaskets/doors •... -
Page 62: Troubleshooting
maintenance Troubleshooting For proper control operations, the control module must be electrically connected to the gas valve and all the ignition wiring connectors plugged in. Gas valves with an electric “ON/OFF” switch must have the switch set to “ON”. The light on the control module provides a self-diagnosis indication. IMPORTANT : Should any of these error codes or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. -
Page 63: Main Assembly
parts list Main Assembly 6 7 8 9 12 2 14 10 RC500EX |... - Page 64 parts list Main Assembly 367-574/P Valve Assembly - NG 367-576/P Valve Assembly - LP 911-380 DEXEN Valve NG 911-381 DEXEN Valve LP 904-162 Burner Orifice #43 NG 904-163 Burner Orifice #54 LP 911-396-ASM Pilot Assembly IPI NG 2 Flame 911-397-ASM Pilot Assembly IPI LP 2 Flame 910-036 Pilot Orifice NG #51 0.977.165...
- Page 65 parts list Main Assembly 366-082 Inner Back Curved Panel 366-051 Top Baffle 366-107 Light Housing 366-108 Light Shield 911-072 Halogen bulb G9/120V/25W (High Temp) 366-085 Air Adjustment Cover Plate 932-009 Tubing SS Flexible 3/8 x 9 inch 904-599 Fitting Elbow 90 Degree (Located At Orifice End) 904-633 Connector 3/8 Comp x 3/8 Male 904-600...
-
Page 66: Accessories
parts list 936-271 Glass Gasket Tadpole Tape 1 1/2 (Sold Per Foot) (6 Feet required) 366-074 Lytherm White Gasket Inner Side Glass (Each) 366-075 Lytherm White Gasket Inner Front Glass 936-238 Outer Side Glass Gasket (Sold Per Foot) 366-549 Glass Clips/Screws Complete Package 366-106 Light Socket Bracket (ea) 366-086F... - Page 67 notes RC500EX |...
-
Page 68: Warranty
FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. Revision Date: February 2019 Regency Gas Products Warranty | RC500EX... - Page 69 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: February 2019 Regency Gas Products Warranty RC500EX |...
- Page 70 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 71 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 72 warranty | RC500EX...
- Page 73 notes RC500EX |...
- Page 74 notes | RC500EX...
- Page 76 Dealer Name & Address: _______________________________________ ___________________________________________________________ Installer: ___________________________________________________ Phone #: ___________________________________________________ Date Installed: _______________________________________________ Serial #: ____________________________________________________ Printed in Canada Regency and AstroCap™ are trademarks of FPI Fireplace Products International Ltd. ® © Copyright 2022, FPI Fireplace Products International Ltd. All rights reserved.
