Vent-a-Hood K250 ARS Installation Instructions

Under cabinet range hood with air recovery system

Read and Save These Instructions

All Hoods Must Be Installed By A Qualified Installer

INSTALLATION INSTRUCTIONS

UNDER CABINET RANGE HOOD

WITH AIR RECOVERY SYSTEM

Read All Instructions Thoroughly Before Beginning Installation

WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,

OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:

A. Installation work and electrical wiring must be done by qualified

person(s) in accordance with all applicable codes and standards,

including fire-rated construction. Switch power off at service panel

and lock the service disconnecting means to prevent power from

being switched on accidentally during installation.

B. When cutting or drilling into wall or ceiling, do not damage electrical

wiring and other hidden utilities.

C. Sufficient air is needed for proper combustion and exhausting of

gases through the flue (chimney) of fuel burning equipment to

prevent back drafting. Follow the heating equipment manufacturer's

guideline and safety standards such as those published by the

National Fire Protection Association (NFPA), and the American

Society for Heating, Refrigeration and Air Conditioning Engineers

(ASHRAE), and local code authorities.

L164 0418A

Page 1

U L

Table of Contents

Need help?

Do you have a question about the K250 ARS and is the answer not in the manual?

Page 1 Read and Save These Instructions All Hoods Must Be Installed By A Qualified Installer INSTALLATION INSTRUCTIONS UNDER CABINET RANGE HOOD WITH AIR RECOVERY SYSTEM Read All Instructions Thoroughly Before Beginning Installation WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: A.
Page 2 Installation Details 1) Read all instructions thoroughly before beginning installation. Note: These instructions apply to standard hoods only. Custom hoods may require additional specification consideration. NOTE: For optimum performance, the Air Recovery System (ARS) filter assembly will require routine maintenance. In order to accommodate this requirement, the enclosure must be constructed with at least one removable outside panel that is large enough to remove the filter assembly or assemblies.
Page 3 Model Volts Amps K250 ARS 7) Insert the electrical wire through the electrical wire clamp allowing 3” - 4” of wire inside the enclosure for hookup. Tighten the electrical wire clamp. 8) From inside the hood, using UL listed wire nuts, attach the “neutral” wire to the white lead, the “hot” wire to the black lead, and the ground wire to the green lead inside the junction box.
