Read and Save These Instructions
All Hoods Must Be Installed By A Qualified Installer
INSTALLATION INSTRUCTIONS
Read All Instructions Thoroughly Before Beginning Installation
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
A. Installation work and electrical wiring must be done by qualified
person(s) in accordance with all applicable codes and standards,
including fire-rated construction. Switch power off at service panel
and lock the service disconnecting means to prevent power from
being switched on accidentally during installation.
B. When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
C. Ducted fans must always be vented to the outdoors.
D. Sufficient air is needed for proper combustion and exhausting of
gases through the flue (chimney) of fuel burning equipment to
prevent back drafting. Follow the heating equipment
manufacturer's guideline and safety standards such as those
published by the National Fire Protection Association (NFPA), and
the American Society for Heating, Refrigeration and Air
Conditioning Engineers (ASHRAE), and local code authorities.
WARNING - TO REDUCE THE RISK OF FIRE, USE ONLY METAL
L111
ISLAND RANGE HOOD
DUCTWORK
Page 1
(Rev. 02/08)
U L
C
US
R
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vent-a-Hood ISLAND RANGE HOOD
Summary of Contents for Vent-a-Hood ISLAND RANGE HOOD
-
Page 1: Read And Save These Instructions
Read and Save These Instructions All Hoods Must Be Installed By A Qualified Installer INSTALLATION INSTRUCTIONS ISLAND RANGE HOOD Read All Instructions Thoroughly Before Beginning Installation WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: A. - Page 2 20 feet, increase the duct diameter by one inch for every ten feet of duct. A 90 degree elbow is equal to 5 feet of duct. Using Vent-A-Hood roof jacks or wall louvers (back page) will ensure proper efficiency. Airflow must not be restricted at the end of the duct run. Do not use screen wire or spring-loaded doors on wall louvers or roof jacks.
- Page 3 Custom hoods may require additional specification consideration. 2) When installing an island range hood, it is recommended that the bottom edge of the hood be located no more than 30” above the cooking surface. Exceeding recommended mounting height may compromise performance.
- Page 4 Installation Details Continued 18” Tall Island Connection Diagram 36”- 54” Widths 8" Round 8" Round 9" 16" 5" 600 CFM T200 Dual Blower VP565 Standard Transition (Top View) (Included) 18” Tall Island Connection Diagram 60”- 66” Widths 9" 11" 11" 5"...
- Page 5 Installation Details Continued Warning: Make sure power is off and locked at the service disconnecting means on the service panel during installation. 7) FOR HOODS WITH REMOVABLE BLOWER MOUNTING ASSEMBLIES ONLY. IF HOOD DOES NOT HAVE A REMOVABLE BLOWER MOUNTING ASSEMBLY, PROCEED DIRECTLY TO STEP 9. Remove each blower deck assembly by removing the 12 screws around the blower mounting plate.
- Page 6 Installation Details Continued 12) From inside the hood, using UL listed wire nuts, attach the “neutral” wire(s) to the white lead(s), the “hot” wire(s) to the black lead(s), and the ground wire(s) to the green lead(s). Plug the motors into the hood and reinstall the blower motors using the three retaining screws that were previously removed in Step 9.
- Page 7 ACCESSORIES VENTING WALL LOUVER WALL LOUVER WALL LOUVER WALL LOUVER 8 5/8” 11” 1 1/2” FLANGE 13” 1 1/2” FLANGE 1 1/2” FLANGE 10” 2” FLANGE 6”,7”, 8” 11” 13” 3 1/4” MODEL MODEL MODEL MODEL VP526 6” RD VP554 10” RD VP555 12”...
