Step

Connect the Bottom Frame

1
Important: Assemble on a level surface.
1. Gather 4 corner rails and
4 frame rails.
2. Point all swedged ends
clockwise.
3. Slip swedged ends of
tubing into the next piece
of tubing.
__________________________________________________________________________________________________

Add Uprights

Step
2
1. Gather 8 uprights, 16 clamps, 8 -
2. With the nut on top, loosely clamp all posts to the bottom frame at each corner and half way along each side
for Option 1, and one third of the way along the long sides for Option 2 (as shown below).
3. Stand corner posts up and tighten clamps. Let the center posts lie on the ground.
4
Option 1 - Dog Kennel
10'(W) x 10'(L) x 6'(H)
Option 2 - Dog Run
5'(W) x 15'(L) x 6'(H)
5
/ " x 2" carriage bolts with nuts.
16
1-888-632-4453
Option 1
Option 2
