Connect The Bottom Frame; Add Uprights - Petsafe Do-It-Yourself Dog Run Assembly Instructions Manual

Step

Connect the Bottom Frame

1
Important: Assemble on a level surface.
1. Gather 4 corner rails and
2 frame rails.
2. Point all swedged ends
clockwise.
3. Slip swedged ends of
tubing into the next piece
of tubing.
__________________________________________________________________________________________________

Add Uprights

Step
2
1. Gather 6 uprights, 12 clamps, 6 -
2. With the nut on top, loosely clamp all posts to the bottom frame at each corner and half way along
each side (2A).
3. Stand corner posts up and tighten clamps. Let the center posts lie on the ground.
2A
4
5
/ " x 2" carriage bolts with nuts.
16
