INSTALLATION
INSTRUCTIONS
PARTS LIST
Cargo cover
TOOLS AND SUPPLIES REQUIRED
Small flat-tip screwdriver
Illustration of the Cargo Cover in the Vehicle
CARGO COVER
© 2015 American Honda Motor Co., Inc. – All Rights Reserved.
Accessory
CARGO COVER
P/N 08U45-TG7-100
INSTALLATION
NOTE: Be careful not to damage the body.
1.
AII01913-6 (1506)
Application
2016 PILOT
Pull each strap, and fold down the left and right third
row seats.
2 STRAPS
(Pull.)
Publications No.
VERSION 1
Issue Date
JUN 2015
THIRD ROW SEATS
(Fold down.)
1 of 3
08U35-TG7-1000-91
Advertisement
Table of Contents
Related Manuals for Honda 08U45-TG7-100
Summary of Contents for Honda 08U45-TG7-100
-
Page 1: Installation Instructions
THIRD ROW SEATS (Pull.) (Fold down.) TOOLS AND SUPPLIES REQUIRED Small flat-tip screwdriver Illustration of the Cargo Cover in the Vehicle CARGO COVER 1 of 3 © 2015 American Honda Motor Co., Inc. – All Rights Reserved. AII01913-6 (1506) 08U35-TG7-1000-91... - Page 2 Attach each hook of the cargo cover to the headrestraint stay. 4 HEADRESTRAINT STAYS 4 HOOKS CARGO COVER 2 of 3 AII01913-6 (1506) © 2015 American Honda Motor Co., Inc. – All Rights Reserved.
- Page 3 Use a sponge or cloth and a solution of mild liquid dishwashing soap and water, then wipe dry with a clean cloth or sponge. 3 of 3 © 2015 American Honda Motor Co., Inc. – All Rights Reserved. AII01913-6 (1506)
