Ergotron StyleView SV32 AutoLock User Manual page 4

6
14mm (9/16")
Follow these instructions
to tighten or loosen
tension.
a
7
a
Ensure that the main power system batteries are installed and functioning.
The power does not need to be turned on at the power system user interface.
b
Programming New Codes
1
Enter Master Code on Keypad.
2
Numbers 3 and 5 on the Keypad will start fl ashing, indicating the Master Code has been accepted.
3
Simultaneously press 3 and 5 while they are fl ashing.
4
All the numbers will light (you have 3 seconds to enter a code).
5
Enter a new code—any sequence of 5 numbers. (The fi rst code programmed is the new Master Code.)
6
When the code is accepted, all of the LEDs will fl ash once in acknowledgement (you have 3 seconds to enter the next code).
7
You can then proceed to program up to 10 personal codes by repeating steps 5 and 6.
8
When fi nished entering new codes, system will exit program mode after 3 seconds with a series of LED fl ashes.
4/6
It is important that you adjust this product according to the weight of the mounted equipment as described in the following steps. Any time equipment
is added or removed from this product, resulting in a change in the weight of the mounted load, you should repeat these adjustment steps to ensure
safe and optimum operation.
Adjustments should move smoothly and easily through the full range of motion and stay where you set it. If adjustments are diffi cult and do not stay in
the desired position, follow the instructions to loosen or tighten the tension to create a smooth, easy adjustment motion. Depending on your product
and the adjustment, it may take several turns to notice a diff erence.
Release brake to move riser.
NOTE: Adjustment may require 40 - 60
revolutions.
b
(Default Master Code: 12345)
c
888-97-045-G-00 rev. C • 09/09
