www.ergotron.com
1x
1
11.8"
(300 mm)
14.6"
(370 mm)
Drawer Insert
Weight = 2 lbs (.8 kg)
2.3"
(58 mm)
888-97-045-G-00 rev. C • 09/09
User's Guide - English
Guía del usuario - Español
Manuel de l'utilisateur - Français
Gebruikersgids - Nederlands
Benutzerhandbuch - Deutsch
Guida per l'utente - Italiano
:
用户指南 : 汉语
사용자 안내서 : 대한민국
A
14mm (9/16")
3.4"
(86 mm)
14.4"
(367 mm)
3"
(76 mm)
11.6"
(295 mm)
StyleView® SV32 AutoLock Drawer
<4 lbs (1.8 kg)
(without insert)
<2 lbs (.8 kg)
(with insert)
EN
User Guide
B
C
1x
4x
ST4.2 x 8mm
WARNING
IMPACT HAZARD!
MOVING PARTS CAN CRUSH AND CUT.
Minimize Lift Tension BEFORE:
· Removing Mounted Equipment.
· Shipping Cart
· Storing Cart
To Minimize Lift Tension
1. Lower worksurface to lowest position.
2. Turn adjustment nut at top of riser
counterclockwise until it stops
(Adjustment may require 40-60 revolutions).
Failure to heed this warning may result in
serious personal injury or property damage!
For More information and instructions refer to product
guide at http://4support.ergotron.com or contact
Ergotron Customer Care at 1-800-888-8458.
14mm (9/16")
822-052
1/6
