Ergotron 20 series Assembly Instructions

Keyboard Drawer
Assembly Instructions
Hello! Thank you for choosing Anthro.
Before beginning installation of your Keyboard Drawer, please take a moment to review the parts listed to verify that
your shipment is complete.
The Cart (shown shaded) is not included with this accessory. An electric drill &
mounting holes for your Keyboard Drawer. It may also be helpful to review the assembly instructions of all Anthro
products you purchased and are planning to include in this installation.
SAVE THESE INSTRUCTIONS!
Component list for part #'s 18xx, 20xx & 30xx.
01–Caddy Glides ...................... Qty. 1 pr. .........225-5190-00
02–Keyboard Drawer ....................Qty. 1................(see below)
18"W X 11"D (18xx) ............ ........................100-6489-xx
20"W X 11"D (20xx) ........... ........................100-6359-xx
30"W X 11"D (30xx) ........... ........................100-6304-xx
• 09/18
300-5215-00 rev. D
01
02
3
03– /
4
04–10-24 X
05–10-24 Acorn Nuts............... Qty. 4............. 325-5023-00
A 1 / " Hex Key, has been provided to assist you in this assembly.
8
1
/ " drill bit may be required to drill the
8
05
03
" Wood Screws ............... Qty. 12 .......... 325-5106-00
3 / " Cap Screws...... Qty. 4............. 325-5232-00
8
Built with Anthro-DNA™
04
