SOlARWATT
iNSTAllATiON iNSTRuCTiONS
f OR fRAmED glASS-glASS SOlAR mODulES
Vision 60M high power
Vision 60M style
The following directives and standards must be complied with when planning, setting up, and maintaining grid-
connected PV systems:
Eu-STANDARDS
EUROCODE 1 (EN 1991-1)
Actions on structures
EN 13501
Fire behavior of building materials and building
component
EN 60728-11
Setting up and operating (grounding) aerial systems
EN 62305
Lightning protection
EN 62446
Grid-coupled photovoltaic systems
IEC 60364
Erection of low-voltage systems
solarwatt INstallatIoN INstrUCtIoNs | EN
Vision 60P style
Vision 60P
VDE-DiRECTiVES
VDE 0100
Erection of low-voltage systems
VDE 0105-100
Operation of electrical systems
EXCluSiON Of liABiliTY
The warranty terms available at
www.solarwatt.net apply.
VDE TEST mARk
CONTENTS
Disposal
Information for complaints
You can check the current status of
the installation instructions at www.
solarwatt.net.
Weitere Sprachversionen finden
Sie unter www.solarwatt.net.
Please find other languages at
www.solarwatt.net.
P.10
P.11
P.15
P.16
P.16
P.16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vision 60M high power and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for solarwatt Vision 60M high power

  • Page 1: Table Of Contents

    INstallatIoN INstrUCtIoNs | EN SOlARWATT iNSTAllATiON iNSTRuCTiONS f OR fRAmED glASS-glASS SOlAR mODulES Vision 60M high power Vision 60P style Vision 60M style Vision 60P The following directives and standards must be complied with when planning, setting up, and maintaining grid- CONTENTS connected PV systems: Eu-STANDARDS VDE-DiRECTiVES EUROCODE 1 (EN 1991-1) VDE 0100 Actions on structures Erection of low-voltage systems Information on the solar module P.10 EN 13501 VDE 0105-100 Fire behavior of building materials and building Operation of electrical systems Transport and storage P.10 component Installation P.11 EN 60728-11 EXCluSiON Of liABiliTY...
  • Page 2: Information On The Solar Module

    PROCEDuRE iN ThE EVENT Of TRANSPORT als and are therefore extremely stable and long-lasting. The DAmAgE solar modules should nevertheless be left in the packaging un- til installation to help prevent any damage. The modules should be stored in a dry place and protected from weather conditions. You are responsible for checking the goods and packaging The packaging (film, tape, pallet, etc.) should be recycled. for transport damage immediately on receipt. If any Contact the responsible local waste disposal company. damage is discovered, note it on the shipping papers describing each pallet in detail, and take photographs as documentary evidence. Have the driver countersign these notes. If more than 33 % solar modules on one pallet are damaged, refuse to accept the pallet. Please fill out the „Transport Damage Complaint Notification“ form (www. solarwatt.net) and return it to SOLARWATT GmbH. STATUS: 02/2017 | AZ-TM-PMS-0673 | InSTAllATIon InSTrUcTIonS rev. 011 | Subject to change | © 2017 SolArWATT GmbH...
  • Page 3: Installation

    EUROCODE 1 (EN 1991-1). modules. In regions with particularly high snowfall, the pressure load calculated in accordance with the standard based on local snow load information may be significantly exceeded due to snow Framed SOLARWATT solar modules can be fastened in a number overhang or build-up on the solar modules, which could result of ways: Please refer to the details to the following pages. in above-average stress on the bottom frame edge. SOLARWATT therefore tests its modules above and beyond the standard IEC 61215 Ed.2 and in accordance with additional standards, taking into account additional loads in the event of snow overhang STATUS: 02/2017 | AZ-TM-PMS-0673 | InSTAllATIon InSTrUcTIonS rev. 011 | Subject to change | © 2017 SolArWATT GmbH...
  • Page 4 Fastening on long sides Fastening on short sides The maximum pressure load to the solar module The maximum pressure load to the solar module for the installation conditions is 2,400 N/m². for the installation conditions is 2,400 N/m². 100 mm 100 mm Vertical installation for increased snow load (only modules with additional feature “crossrail”) Fastening on long sides and short side The maximum pressure load to the solar module for the 100 mm installation method is 3,750 N/m². 100 mm 100 mm 100 mm areas approved for fastening substructure STATUS: 02/2017 | AZ-TM-PMS-0673 | INSTALLATION INSTRUCTIONS Rev. 011 | Subject to change | © 2017 SOLARWATT GmbH...
  • Page 5 Fastening on long sides The maximum pressure load to the solar module for the installation conditions is 3,500 N/m². Fastening on short sides 200 mm In addition, this fastening mode requires a central, round or linear support on the lower frame side (central support). The maximum pressure load to the solar mod- ule for the installation conditions is 2,400 N/m². 200 mm WARNiNg areas approved for fastening The solar modules are not designed for concentrated irradiation. Bundling or concen- trating solar irradiation through lenses or mirrors is therefore not permitted and can substructure damage the solar modules. NOTE It is not permitted to use SOLARWATT solar modules as overhead glazing. For roof instal- NOTE lation, these solar modules may only be installed over a fi re-resistant roof covering. Under mechanical load, no contact be- NOTE tween solar glass and hard materials (eg. metal, glass) may occur. The drainage holes in the module frame must not be covered, The solar module heats up during operation. Ensure that there is suffi cient rear as it could cause frost damage one the mod- ventilation to avoid reductions in yield. Also ensure that no fl ammable gases can ule frame. Do not place any plug connectors escape or accumulate close by. in the frame for this reason. STATUS: 02/2017 | AZ-TM-PMS-0673 | INSTALLATION INSTRUCTIONS Rev. 011 | Subject to change | © 2017 SOLARWATT GmbH...
  • Page 6 SYSTEm Fixed in place by inserting in a supporting frame The maximum pressure load to the solar module for the installation method is 2,400 N/m². WARNiNg Solar modules generate electrical energy on the front side during incidence of light. A system with multiple solar modules can generate life-threatening voltages and electrical currents. Do not touch the electrical connections or cable ends while the solar module is exposed to light. SCREW fiXTuRES Fastening on the fastening holes with screws Fastening on the fastening holes Only use the holes provided in the frame (diameter: 9 mm). The maximum pressure load to the solar module for the installation method is 2,400 N/m². areas approved for fastening substructure Additional system-specifi c load limits can be found in the download area at www.solarwatt.net STATUS: 02/2017 | AZ-TM-PMS-0673 | INSTALLATION INSTRUCTIONS Rev. 011 | Subject to change | © 2017 SOLARWATT GmbH...
  • Page 7: Electrical Connection And Grounding

    ElECTRiCAl CONNECTiON AND gROuNDiNg SOLARWATT solar modules are equipped at the factory with IEC 61730). Solar modules in this application class can be used high-quality solar cables and reverse-polarity protected, shock in systems with unrestricted access, the relevant regulations proof plug connectors. The connection of the string line has must be complied with. SOLARWATT solar modules qualifi ed to be done with identical connectors manufacture and type as within this application class in accordance with IEC 61730 fulfi ll to the module connecting cable. To be able to ensure this the the requirements of protection rating II with correct electri- module connector at the beginning and the end of the string cal installation. may be removed and replaced (More information in the down- Junction box with load area at www.solarwatt.net). The allowed cross-section and bypass diodes outer-diameter of the cable and instruction of the manufactur- er have to comply. The following table shows matching cable- sets, plugs, cables and installation accessories. When connect- Cell connector ing the modules, ensure that the plugs engage with an audible click. The common bending radii of at least 5 times the outer cable diameter must be complied with. It is recommended to lay Solarcell the cable fi rmly so that they are not subjected to mechanical loads. The cable and connector must not exposed to moisture and will not rest on the ground or fl oor. To ensure safety and compliance with the technical data of the products, only origi- nal tools of the manufacturer may be used in the self-assembly of solar cables.
  • Page 8: Maintenance And Servicing

    VDE 0105-100. anol- or water-isopropanol intermixture and a soft nonabra- DiSPOSAl Dispose of defective or old solar modules properly; they should charge. The WEEE Directive is nationally oriented, meaning never be disposed of with domestic waste. The disposal of solar that each EU Member State has its own legal regulations and modules is regulated in the EU Waste Electrical and Electronic practical handling for the sale and return of PV modules. Equipment Directive (WEEE). Old solar modules can be mostly Contact us by e-mail at info@solarwatt.net and specify the returned in usual commercial quantities to nearby municipal number and type of modules to be returned. We will then coor- collection sites and local civic waste collection points at no dinate all further details for returning your modules. NOTES ON COmPlAiNTS If you still have cause for complaint despite the high quality of our products, please contact your dealer directly or: SOLARWATT GmbH | Maria-Reiche-Str. 2a | 01109 Dresden | Germany Tel. + 49 351 8895-0 | Fax + 49 351 8895-111 | info@solarwatt.net Certified in accordance with ISO 9001 and ISO 14001 | BS OHSAS 18001:2007...
