solarwatt BLUE 60P Installation Instructions Manual

Roof solution
Hide thumbs Also See for BLUE 60P:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

SOLARWATT
BLUE ROOf
SOLUTION
SolaRWatt Blue 60P | SolaRWatt Blue 60M
The following guidelines, directives, and DIN standards must be complied with when planning, setting up, and
maintaining grid-connected PV systems:
DIN STANDARDS
DIN EN 1991-1 (DIN 1055)
Actions on structures
DIN EN 13501 (DIN 4102)
Fire behavior of building materials and building
components
DIN 18015
Electrical installations in residential buildings
DIN 18382
VOB Construction tendering and contract regulations
- Part C: General technical specifications for building
works (ATV) - low- and medium voltage systems with
nominal voltage up to 36 kV
DIN 43870
Meter panels
DIN EN 60728-11
(VDE 0855-1) Setting up and operating (grounding)
aerial systems
DIN EN 62305 (VDE 0185-305)
Lightning protection
DIN EN 62446
Grid-coupled photovoltaic systems
VDE PROVISIONS
DIN VDE 0100-510
Erection of low-voltage systems - Part 5-51: select-
ing and setting up electrical equipment - general
provisions
DIN VDE 0100-712
Erection of low-voltage systems - Part 7-712:
Requirements for special installations or locations -
solar photovoltaic (PV) power supply systems
DIN VDE 0100-737
Erection of low-voltage systems - damp and wet
areas and rooms and outdoor systems
DIN VDE 0105-100
Operation of electrical systems
PROPERTy INSURER DIRECTIVES (VDS)
VDS 2023
Guidelines for fire protection in structural systems
VDS 2024
Guidelines for fire protection for
the installation of electrical equipment in fixtures
ExCLUSION Of LIABILITy
The warranty terms available at www.solarwatt.de
apply.
VDE TEST MARK
inStallation inStRuctionS
C ONTENTS
Disposal
Information for complaints
You can check the current status of
the installation instructions at www.
solarwatt.de.
3 Weitere Sprachversionen finden
Sie unter www.solarwatt.de.
3 Please find other languages at
www.solarwatt.de.
P.11
P.11
P.15
P.16
P.16
P.16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLUE 60P and is the answer not in the manual?

Questions and answers

Related Manuals for solarwatt BLUE 60P

Summary of Contents for solarwatt BLUE 60P

  • Page 1: Table Of Contents

    SOLARWATT  BLUE ROOf  SOLUTION SolaRWatt Blue 60P | SolaRWatt Blue 60M The following guidelines, directives, and DIN standards must be complied with when planning, setting up, and maintaining grid-connected PV systems:   C ONTENTS DIN STANDARDS DIN VDE 0100-712 Erection of low-voltage systems – Part 7-712: DIN EN 1991-1 (DIN 1055) Requirements for special installations or locations – Actions on structures solar photovoltaic (PV) power supply systems Information on the solar module P.10 DIN EN 13501 (DIN 4102) DIN VDE 0100-737 Fire behavior of building materials and building Erection of low-voltage systems – damp and wet Transport and storage P.11 components areas and rooms and outdoor systems Installation P.11 DIN 18015 DIN VDE 0105-100 Electrical installations in residential buildings Electrical connection...

  • Page 2: Information On The Solar Module

    CONGRATULATIONS ON THE   PURCHASE Of yOUR SOLARWATT SOLAR MODULE These instructions describe the assembly, connection, exclusively in Germany is ensured by multiple tests carried maintenance, and disposal of solar modules. Please read them out on the products throughout the entire production pro- carefully and comply with them accordingly. cess. SOLARWATT solar modules are VDE-tested and fulfill the requirements of the extended test standard IEC 61215 Ed.2, The installation and electrical connection of photovoltaic as well as the safety standard IEC 61730. In SOLARWATT's systems may only be carried out by specialist personnel, own research and development department, tests are carried who are familiar with this work through their professional out using measuring, testing, and environmental simulation qualifications. For the installation of the other components, equipment which go above and beyond the current valid comply with the relevant installation instructions from the standards and enable us to optimize our products continually. manufacturer. The manufacturer is unable to monitor whether If treated correctly, your SOLARWATT solar modules will offer these instructions and the conditions and methods for instal- you several decades of service. lation, operation, use, and maintenance of the inverter are complied with. SOLARWATT recommends insuring the PV system against reduced yields or damage with SOLARWATT Full Coverage for Incorrect installation can cause damage to property, which complete security. Further information is available from your could consequently pose a risk to people. SOLARWATT accepts SOLARWATT partner or online at www.solarwatt.de. no responsibility or liability for losses, damage, or costs resulting from incorrect installation, operation, use, or Information on the solar module maintenance or losses, damage, or costs which are connected to any of the above in any way. The SOLARWATT installation...

  • Page 3: Transport And Storage

    TRANSPORT AND STORAGE SOLARWATT solar modules are made from high-quality materi- als and are therefore extremely stable and long-lasting. This PROCEDURE IN THE   means that, together with the environmentally-friendly, EVENT Of TRANSPORT DAMAGE resource-saving QUICKSTAXX® packaging solution, safe transportation (tested in accordance with ISTA 3E) and easy commissioning are guaranteed. The solar modules should nev- You are responsible for checking the goods and packag- ertheless be left in the packaging until installation to help ing for transport damage immediately on receipt. If any prevent any damage. The modules should be stored in a dry damage is discovered, note it on the shipping papers place and protected from weather conditions. The packaging describing each pallet in detail, and take photographs (film, tape, pallet, etc.) should be recycled. Contact the as documentary evidence. Have the driver countersign responsible local waste disposal company. these notes. If more than ten solar modules on one pal- let are damaged, refuse to accept the pallet. Please fill The fully biodegradable QUICKSTAXX® packaging edges can out the "Transport Damage Complaint Notification" form be disposed of as household waste or in a suitable compost (www.solarwatt.de) and return it to SOLARWATT AG. system. Further information is available in the SOLARWATT product information "Packaging" at www.solarwatt.de. INSTALLATION During installation, please take into account the locally valid solar module. Have the structural suitability of the building construction regulations, accident prevention regulations, for the installation of a solar power system checked by a the relevant, generally accepted rules of technology and specialist. The frame must not be mechanically or chemically safety regulations for working on roofs and buildings, as well processed. as electrical installations. SOLARWATT solar modules must be fixed to suitable substruc- During installation, avoid creating shades with the module tures, which are designed for the relevant mechanical wind clips or installation system to improve the energy yield.
  • Page 4 In regions with particularly high snowfall, the pressure load calculated in accordance with the standard based on local snow load information may be significantly exceeded due to snow overhang or build-up on the solar modules, which could result in above-average stress on the bottom frame edge. SOLARWATT therefore tests its modules above and beyond the standard IEC 61215 Ed.2 and in accordance with additional standards, taking into account additional loads in The SOLARWATT BLUE ROOF SOLUTION solar modules can be fastened in a number of ways: SCREW fIxTURES Fastening on the fastening holes with screws. Only use the holes provided in the frame (diameter: 9 mm). Fastening on the fastening holes The maximum pressure load taking into account the shape coefficients in accordance with DIN EN 1991-1 (DIN 1055) for the installation conditions is 2,400 N/m².   WARNING   NOTE   NOTE The solar modules are not designed...
  • Page 5 The maximum pressure load taking into The maximum pressure load taking into account the shape coefficients in accordance account the shape coefficients in accordance 100 mm with DIN EN 1991-1 (DIN 1055) for the instal- with DIN EN 1991-1 (DIN 1055) for the instal- lation conditions is 2,400 N/m². lation conditions is 2,400 N/m². 100 mm areas approved for fastening Horizontal installation Fastening on short sides In addition, this fastening mode requires a central, 200 mm round or linear support on the lower frame side (cen- tral support). The maximum pressure load taking into account the shape coefficients in accordance with DIN EN 1991-1 (DIN 1055) for the installation condi- 200 mm tions is 2,400 N/m². Fastening on long sides The maximum pressure load taking into account the shape coefficients in accordance with DIN EN 1991-1 (DIN 1055) for the installation conditions is 3,500 N/m².   NOTE SOLARWATT solar modules are not regulated construction products in the sense of DIBt (German Institute for Building Technology). It is not permitted to use SOLARWATT solar modules as overhead glazing. For roof installation, the solar modules may only be installed over a fire-resistant roof covering ("hard roof"). STATUS: 06/2012 | INSTALLATION INSTRUCTIONS Rev. 5 | Subject to change | © 2012 SOLARWATT AG...
  • Page 6 INSERTION SySTEM Fixed in place by inserting in a supporting frame Vertical installation The maximum pressure load taking into account the shape coefficients in accordance with DIN EN 1991-1 (DIN 1055) for the installation conditions is 2,400 N/m².   WARNING Solar modules generate electrical energy on the front side during incidence of light. A system with multiple solar modules can generate life-threatening voltages and electri- cal currents. Do not touch the electrical connections or cable ends while the solar module is exposed to light. STATUS: 06/2012 | INSTALLATION INSTRUCTIONS Rev. 5 | Subject to change | © 2012 SOLARWATT AG...

  • Page 7: Electrical Connection And Grounding

    ELECTRICAL CONNECTION AND GROUNDING SOLARWATT solar modules are equipped at the factory with solar modules installed parallel is three (without string fuse). high-quality solar cables and reverse-polarity protected, Please comply with the value specified in the data sheet for shock-proof plug connectors. No others may be used. When reverse-current feed and only use standardized photovoltaic connecting the modules, ensure that the plugs engage with cables (recommendation: at least 4 mm² cable cross-section). an audible click. The solar modules correspond to application class A and can To ensure that the products are safe and comply with the therefore be operated in systems with dangerous DC voltages in accordance with IEC 61730) and servic- technical data, only genuine tools from the relevant manu- (larger than 120 V facturer may be used when self-assembling solar cables. The es. Solar modules in this application class can be used in sys- solar cables must be compatible with the module plug system tems with unrestricted access, the relevant regulations must of the relevant manufacturer. be complied with. SOLARWATT solar modules qualified within this application class in accordance with IEC 61730 fulfill the The recommended maximum number of solar modules in- requirements of protection rating II with correct electrical stalled in series is 25. The recommended maximum number of installation. Connection lines Junction box with bypass diodes Cell connector Solar cells String connector Module schematic, front view   WARNING   NOTE The plug contacts must not be con- It is advisable to install lightening protection in exposed locations. The solar modules nected or disconnected under load.

  • Page 8: Maintenance And Servicing

    MAINTENANCE AND SERVICING A photovoltaic system needs practically no maintenance, conventional cleaning agent may also be used in the recom- as the solar modules are cleaned by the rain at the recom- mended dose. Do not use aggressive cleaning agents or met- mended minimum angle of 15°. To avoid reductions in yield, al objects, as they can be particularly damaging to the hard- we do, however, recommend carrying out a regular visual ened glass surface. The electric cables should (where acces- check on the module surfaces. Particularly heavy soiling sible) be checked regularly for damage, corrosion, and firm (e.g., leaves) can cause shades which reduce performance hold. Pay particular attention to BGV A3, DIN VDE 0105-100. and should therefore be removed. Clean the glass surface with water and a soft sponge only. In exceptional cases, a DISPOSAL Dispose of defective or old solar modules properly; they should never be disposed of with domestic waste. For this reason, we offer our customers return and recycling of our solar modules. Contact us by e-mail at info@solarwatt.de and specify the number and type of modules to be returned. We will then coordinate all further details for returning your modules. NOTES ON COMPLAINTS If you still have cause for complaint despite the high quality of our products, please contact your dealer directly or: SOLARWATT AG | Maria-Reiche-Str. 2a | 01109 Dresden | Germany Tel. + 49 351 8895-0 | Fax + 49 351 8895-111 | info@solarwatt.de Certified in accordance with ISO 9001 and ISO 14001 STATUS: 06/2012 | INSTALLATION INSTRUCTIONS Rev. 5 | Subject to change | © 2012 SOLARWATT AG...

This manual is also suitable for:

Blue 60m
