- Page 1 Model 4100XL Digital Checkweigher Scale INSTRUCTION MANUAL DORAN SCALES, INC. 1315 PARAMOUNT PKWY. 1-800-262-6844 FAX: (630) 879-0073 http://www.doranscales.com MANUAL REVISION: 0.3 MAN0197 12/3/2001 Made in USA...
-
Page 2: Table Of Contents
Table of Contents Table of Contents..................1 Introduction ....................3 Quick Start User's Guide ................4 Fig. 1: Model 4100XL Front Panel Layout ..............4 Power Up: ........................4 Basic Weighing Operation:................... 4 Controls and Display Operation: .................. 5 Zero:..........................5 Units: (Optional) ......................5 Print: (Optional) ...................... - Page 3 Data Communications ................19 Introduction to data communications:................. 19 Printer Modes: ......................20 Transmit on demand (tod): ..................20 Continuous print (CP):..................... 20 Auto Print 1 (AP1): ....................20 Auto Print 2 (AP2): ....................20 Data output format:..................... 21 "F0" Format: ......................21 Fig.
-
Page 4: Introduction
With ease of use and setup in mind, the scale is simple to set up and ready to use. The Model 4100XL offers many features. A few of these features are listed below: NTEP certification for Class III installations to 5,000d. -
Page 5: Quick Start User's Guide
Quick Start User's Guide Fig. 1: Model 4100XL Front Panel Layout Power Up: Connect the Model 4100XL to a compatible power source. Basic Weighing Operation: 1) Remove all items from the scale platter. 2) Press ZERO to zero the scale. The weight display should now read zero. -
Page 6: Controls And Display Operation
Be sure the AC power is not excessively noisy - this can occur if large inductive loads, such as solenoids or motors, are on the same power line. The Model 4100XL has a filtered power supply to reduce the effects of normal line noise, but they cannot limit severe fluctuations. -
Page 7: Quick Setup Guide
Quick Setup Guide Load Cell and Power Connections: Load cell connections are made through a terminal block located at the bottom center of the main PC. Board (Fig. 2). See “Specifications and Interconnect Data” for wiring. The power cord connects to a connector adjacent to the transformer. These connections are accessible by removing the rear cover. - Page 8 connector found on the main board. Like the load cell cable and power cord, the option cables are passed through watertight fittings mounted on the bottom of the indicator. CTS /RXD REMOTE SWITCH DIGITAL GND. Fig. 3: Remote Push Button Connections Capacity: Capacity selection is performed by pressing and release Calibration button (S1) to enter the calibrate mode.
- Page 9 10% of capacity are more likely to have significant errors at full capacity than are scales calibrated at 25% or 50%. Doran Scales recommends that all scales be calibrated at full capacity whenever possible. 10% calibration should not be used when calibrating scales for legal for trade applications.
- Page 10 4) Record the "no load" counts. 5) Place "Full Load" on the platform and record the "Full Load" counts. Subtract the "No Load" counts from the "Full Load" counts to calculate span. Refer to Table 1 and verify that the span falls within the limits specified for the amount of dead load present.
-
Page 11: Detailed Parameter Setup
Detailed Parameter Setup The Model 4100XL has 19 setup and calibration parameters, which can be accessed through the scale's Calibration Setup Menu. Entering and Exiting the Calibration Setup Menu: To enter the Calibration Setup Menu. Remove the two screws mounting access cover. -
Page 12: Changing A Parameter
UNITS to go to the next menu item. Quick Review of Setup Parameters: Setup parameters for the Model 4100XL may be quickly reviewed without opening the scale. Remove power and press and hold the ZERO button while you apply power. -
Page 13: Setup Menus Explained
Setup Menus Explained (In order of occurrence) Calibration Setup Menu O.U. m.A. d.o. For. t.o.d. C.P. A.P.1 A.P.2 0.25 UnitS r.P.b. XXXXX 14.4 lb oz... -
Page 14: Capacity Setup Menu
Quarter capacity calibration. 1/10th of capacity calibration. * NOTE: For maximum accuracy, Doran Scales recommends that all scales be calibrated at full capacity. When location or installation make it difficult to bring full capacity weights to the scale, calibration with as... -
Page 15: Over And Under Setup Menu
Over and Under Setup Menu O.U. Over and Under tolerances Select Menu Allows the selection of Checkweighing band in scale divisions. Checkweighing is off +1 division +2 division +3 division +5 division +7 division +10 division +15 division +20 division +30 division Digital Filter Setup Menu Averaging mode... -
Page 16: Automatic Zero Tracking Setup Menu
Automatic Zero Tracking Setup Menu Automatic Zero Tracking Range Small weights within the specified number of divisions are automatically zeroed. Zero tracking is off. No automatic zeroing. Zero tracking to within 0.5 division. Zero tracking to within 1.0 division. Zero tracking to within 3.0 divisions. Motion Aperture Setup Menu m.A. -
Page 17: Latching Print Request Setup Menu
Enhanced Output includes Checkweigh status. Basic Dual Print Format. Includes Kilogram weight. Basic Dual Print Format. Includes Kilogram weight and Checkweigh status. Basic Output for Doran Model SSP printer. Enhanced Output for Doran Model SSP printer. Baud Rate Setup Menu Baud Rate Setup Determines baud rate for serial data. -
Page 18: Serial Data Handshaking Setup Menu
Serial Data Handshaking Setup Menu Serial Data Output Handshaking Selects the type of serial data handshaking used. (See the Data Communication section for details) No handshaking is used. Data is sent when ready, receiving device (printer) must be fast enough to keep up with the data. -
Page 19: Remote Push-Button Configuration Menu
Remote Push-button Configuration Menu r.P.b. Remote Push Button Configures the remote switch to perform one of the three front panel functions. The remote switch is disabled. The remote switch functions as a PRINT button. The remote switch functions as a UNITS button. The remote switch functions as a ZERO button. -
Page 20: Data Communications
Data Communications Introduction to data communications: In the Model 4100XL data is sent to a printer or computer by using "asynchronous serial data communications." Data is broken up and sent one piece at a time to the printer or computer. In spite of this apparent simplicity, a basic understanding of serial data communications is needed when setting up the scale. -
Page 21: Printer Modes
"Ctrl-Q" is received. To use this mode, the RTX line of the scale is tied to the TXD line of the receiving unit. Printer Modes: The Model 4100XL offers four different print control modes. These modes dictate when printer data is sent. Transmit on demand (tod): In this mode, scale data is transmitted whenever the print button is pressed, the remote print button is pressed, or a print request is received from the serial port. -
Page 22: Data Output Format
Data output format: In order for the serial data sent from the scale to be useful, the data must be organized so that it is easy to read. To accomplish this, the scale arranges the displayed data with additional text to indicate the active units and to indicate the presence of motion during the reading. -
Page 23: D0" Format
STX: ASCII character 02h (normally a non printing character) Space Carriage return & line feed: ASCII characters 13 & 10 STX± 27 lb 12.2 oz CR+LF Displayed weight data with units. (lb-oz only) Fig. 2 Format "F0" lb-oz form In the case of lb-oz data, the pounds value is placed after the polarity sign. A space followed by "lb"... -
Page 24: Fig 4. Sample Ss0 Format Printer Output
"SS0" format: The data string produced by the SSP format allows the scale to communicate with the Doran Model SSP Label Printer. This printer allows the creation of custom labels containing weight information, bar codes and graphics. Refer to Fig. 4 for details. -
Page 25: Specifications And Interconnect Data
Specifications and Interconnect Data Specifications: Model 4100XL Resolution: 10,000d in precision mode Sensitivity: 0.5 µV min. Load Cell Capacity: 0.5 mV/V to 3.5mV/V Power Supply: 115/230 VAC 50/60 Hz Display: 6 digit LED. 0.56" high Displayed units: lb, kg, oz, g and lb oz... - Page 26 PIN # TITLE CTS for Hardware Handshaking RTX for Software Handshaking Remote Switch High Remote Switch Ground RS232 Signal Ground Table 11: P3 Options Connections PIN # TITLE Neutral Ground Table 12: J4 Power Connections PIN # TITLE Zero Switch Ground Zero Switch High Units Switch Print Switch...
- Page 27 WHITE GREEN SHRINK SHIELD BLACK SHRINK Fig. 6: Connector J3, Serial cable assembly Serial Cable Assembly DB25 Female connector w/ hardware handshaking Function Wire Color White Signal GND Black Jumper 4 to 5 Jumper 6 to 8 to 20 DB9 Female Connector w/ Hardware Handshaking White Signal GND...
- Page 28 Serial Cable Assembly DB25 Female connector w/ Software Handshaking Function Wire Color White Signal GND Black Jumper 4 to 5 Jumper 6 to 8 to 20 DB9 Female Connector w/ Software Handshaking White Signal GND Black Jumper 1 to 4 to 6 Jumper 7 to 8 Table 15: Serial Cable assembly with Software Handshaking...
- Page 29 Fig. 7: Installation of EMI / RFI / ESD protection devices. NOTE: Fig. 7 illustrates a 4100XL connected with a 6 wire load cell. When installing a 4-wire cell, Sense + should be jumpered to Excitation + and Sense - should be...
-
Page 30: Troubleshooting
Troubleshooting General problem resolution: Problem: What to Do or Check: Weight reading will not Make sure that there is nothing caught in the platform repeat or scale does not under or around the load cell or spider interfering with return to zero when weight its movement. -
Page 31: Resetting The Scale Parameters
If you are still experiencing a problem with your scale, or if the problem you are having is not covered in the above list, please contact your Doran Scales authorized dealer. Resetting the scale parameters: If at some point the Model 4100XL, user wishes to return the setup parameters to factory default, follow these steps. -
Page 32: Scale Messages
Scale Messages: Message Meaning "donE" The scale has successfully completed the Function complete. requested action. "Abort" The requested action has been canceled prior to Aborted Function. completion. "SAVEd" The scale has successfully store and verified Parameter value saved. parameter value in nonvolatile memory. Error messages: Error Message What to Do or Check:... - Page 33 LIMITED WARRANTY STATEMENT DORAN SCALES, INC. warrants its products to be free from defects in material and workmanship for a period of two (2) years from date of shipment. Any product found to be defective within this time period may be returned to DORAN’s factory, freight prepaid, with prior return...
