Tekmar Invita Quick Setup Manual page 9

Setup menu
• Press the button to enter the settings menu
Toggle between home and away to save energy
Set °F or °C, background and language, and
Setup WiFi and register to mobile and web app
WiFi connection status
Settings menu
Access levels and software version
Sensor setup and offsets
Equipment selection and accessory relay setup
Back to Settings menu
Relay menu
The Relay menu determines how the thermostat operates the
mechanical equipment.
• Press the button to enter the settings menu
• Press the SETUP button
• Press the RELAYS button
1. Select conventional or heat pump systems.
2. Select the number of heating and cooling stages.
3. Select if operating a radiant floor.
4, 6, 8, 10: Select the temperature differentials between
stages.
5, 7, 9, 11: Select the time delays between stages.
RELAYS
1
Heating Type: Conventional
2
Equipment: 1 Heat/1 Cool
3
Radiant Floor Heating: No
4
Heat 2 Differential: 2.0 °F
5
Heat 2 Time Delay: 1 min
6
Heat 3 Differential: 2.5 °F
view energy use
Back to home screen
WIFI: Connected
RELAYS 2
7
Heat 3 Time Delay: 1 min
8
Heat 4 Differential: 3.0 °F
9
Heat 4 Time Delay: 1 min
10
Cool 2 Differential: 2.0 °F
11
Cool 2 Time Delay: 1 min
12
Y Min Run Time: 2:00 min
MENU SELECTION
Program schedule
AWAY SCHEDULE
Time is automatically set when connected
DISPLAY TIME
to the Internet. Time can be manually set.
Advanced level settings
WIFI SETUP
On/Auto/Follow schedule
FAN
SETUP MENU
Set min and max temperatures
TOOLBOX TEMP
Setup temperature and humidity high and low
SENSORS ALERTS
alert notifications
Set the humidifier and dehumidifier settings
HUMIDITY
RELAYS
(requires a humidifier or dehumidifier to be installed)
Set the ventilator run time
VENT
(requires an HRV or ERV to be installed)
12, 13: Select the air conditioner or heat pump compressor
min off and min run times.
14: Select if operating a dual fuel system.
15, 16: Select accessory relay options: Humidifier, Dehumidi-
fier, HRV/ERV
17: Select the heat pump reversing valve position
18, 19: Select the system fan options.
20, 23: Select humidifier and dehumidifier options.
21, 22: Select window frost protection options. This prevents
moisture and frost on windows in the winter.
24: Select the time to switch between heating to cooling and
vice versa
RELAYS 3
13
Y Min Off Time: 5:00 min
14
Dual Fuel: Off
15
Accessory Relay 1: Off
16
Accessory Relay 2: Off
17
HP Reversing Valve: O
18
Fan Relay: G only
9 of 12
RELAYS 4
19
Fan with HRV/ERV: Off
20
Humidifier Type: Steam
21
Window Protection: Off
22
Window Quality: 2-pane average
23
Dehumidifier Type: DX Coil
24
Heat-Cool Time Interlock: 10 min
