3. Settings

The first configuration of the unit has to be made with the remote control and optionally a USB keyboard
to ease the text input. Once the AX-TV is set-up for the first time it is possible to edit or complete the
cameras configuration remotely from a web browser.

3.1. Edition with the remote control and the virtual keyboard

Use the arrow buttons [< ^ >] to scroll through options, the [OK] button to select an option and the [Exit
] button to go back.
To show the virtual keyboard, select a text box and press [OK]. The virtual keyboard will be shown on
screen. Select the character key with the arrow buttons and press [OK] to choose. Select the Next key
on the virtual keyboard to enter the text and move to the next text box. Press [Exit ] to exit the virtual
keyboard. The numbers can be typed directly with the number buttons of the remote control.
To modify a text, it is convenient to place first the cursor where you want to insert characters, or at the
end of the text to delete it, and then press [OK] to open the virtual keyboard.
You can use a mouse and a USB keyboard connected to the AX-TV to enter the configuration data
faster. Bear in mind that only QWERTY keyboards are supported.

3.2. Settings menu

Press the [Menu ] on the remote-control button to show the main
menu options. Enter the Settings option.
In the Settings menu there are the following options:
