3.9. Import / Export configuration

This option eases the camera configuration export and import between AX-TV units, and lets you load the
previous configuration after a factory setting.
You can export the configuration to a microSD card or a USB memory. In case you have connected both
types of devices, the USB has the priority.
Select Export configuration to start the process. An axtv.xml file is exported to the external memory
device root. In case there is a file with the same name it will be replaced.
To import a configuration, select the Import configuration option, the AX-TV will search a file with the
same name into the root of the connected device.

3.10. System settings

There are three options in this section:
3.10.1. Language settings
You can choose one of the following languages: English, French, Italian, Portuguese or Spanish.
3.10.2.Set date and Time
3.10.3.Factory settings
This option returns the AX-TV unit to its factory default settings, except for the network configuration,
display position, date and time.
If you want to load a complete image of the factory software, see the appropriate chapter below
3.10.4.Display settings
Here you can adjust the size and position of the image on your TV screen by using the arrow buttons [< ^
>]. Use this option only if necessary.
User Manual - 13
