- Page 1 VISUAL-TV User manual HDMI Wireless video decoder...
- Page 3 INDEX INSTALLATION AND SET UP ........................2 SETTINGS ..............................3 APPENDIX: TECHNICAL SPECIFICATIONS ..................5 User manual - 1...
-
Page 4: Installation And Setup
1 Installation and set up Visual-Tv is a video decoder to visualize CCTV cameras connected to Visual Tools recording units. With this unit you could see the cameras of a VX range unit on a TV by using the remote control. - Page 5 2 Settings When the unit starts the screen shows the Visual Tools logo, press the [Menu] button to show all available options. Note: Use the arrow buttons [< >] to scroll through options, the [OK] button to select an option and the [Exit] button to come back.
- Page 6 System settings In this section you can change the language and apply the Factory settings, this option returns the Visual-Tv unit to its factory settings. Cameras Use the numeric buttons [from 1 to 16] to select a single camera, using [Zoom-in] you could change to quad view: 1, 4, 9 and 16 depending on the VX unit cameras.
-
Page 7: Appendix: Technical Specifications
3 Appendix: Technical specifications MODEL: Visual-Tv Wireless video decoder RESOLUTION: 1280 x 720 COMUNICATION: Ethernet RJ45 10/100M adapter. Built in 802.11 b/g/n WiFi inside. VIDEO OUTPUT: 1 HDMI 1.3 output REMOTE CONTROL Remote control with mouse function DISPLAY: Cameras one by one or quads 2x2, 3x3 and 4x4 POWER: Power supply 110-240, 1A Æ... - Page 8 HDMI Wireless video decoder User manual DOCTVUM00EN_120512v115...
