- Page 1 AX-TV User manual HDMI Wireless video decoder...
-
Page 3: Table Of Contents
INDEX INSTALLATION AND SET UP ........................2 SETTINGS ..............................3 2.1 C ..........................3 ONFIGURATION MENU UNIT PERFORMANCE ..........................6 APPENDIX 1: CHANGING AXIS CAMERAS SETTINGS ................. 7 APPENDIX 2 : TECHNICAL SPECIFICATIONS ....................8 User manual - 1... -
Page 4: Installation And Set Up
With this unit you could see in your TV all the IP Axis cameras you have installed. Connect the unit to the TV trough the HDMI output and to the IP cameras by a network connection, LAN or WIFI. For the installation of an Ax-Tv unit check the package contents and follow the steps. Package contents Open the packaging and check that includes the following items: ... -
Page 5: Settings
2 Settings When the unit starts the screen shows the Visual Tools logo, press the [Menu ] button to show all available options. Note: Use the arrow buttons [< ^ >] to scroll through options, the [OK] button to select an option and the [Exit ] button to come back. - Page 6 Network settings You need to configure the network parameters to connect to the cameras. Choose the connection you prefer, Ethernet or WIFI, and make sure that the corresponding checkbox is selected or the communications will not be active. WIFI configuration Menu >>...
- Page 7 System settings In this section you can change the language and apply the Factory settings, this option returns the Ax-Tv unit to its factory settings. Display settings Into the display position you can adjust on your TV screen through the arrow buttons [<...
-
Page 8: Unit Performance
Updates The unit has a USB connection for updates, the process is as follows: 1.- The AX-TV unit need to be connected to the TV to follow the process, there is no need to be connected to the network. 2.- You need a USB memory FAT or NTFS formatted, plug it to your computer and copy the update zip file. -
Page 9: Appendix 1: Changing Axis Cameras Settings
You can create up to four profiles that correspond to the four different views that provide the Ax-Tv. The profiles name is AX-TVx where x correspond to the view type that the Ax-Tv provides (1, 2, 9 o 16 cameras). -
Page 10: Appendix 2: Technical Specifications
Appendix 2: Technical specifications MODEL: Ax-Tv Wireless video decoder RESOLUTION: 1280 x 720 COMUNICATION: Ethernet RJ45 10/100M adapter.Built in 802.11 b/g/n WiFi inside. VIDEO OUTPUT: 1 HDMI 1.3 output REMOTE CONTROL Infrared remote control DISPLAY: Cameras one by one or quads 2x2, 3x3 and 4x4 Default refresh rate 10 - 12 ips for one camera, 5 –... - Page 11 User manual - 9...
- Page 12 HDMI Wireless video decoder User manual DOCAXTVUM00EN_121212v015...
