1. Contents

AX-TV is a video decoder used to display live video from all kind of AXIS IP cameras, ONVIF cameras
(please consult the supported camera's model on the Appendix2 table) as well as VX and NVX video
recorders from Visual Tools.
Connect the AX-TV to a TV or a monitor with the HDMI cable and you will have your cameras on screen
connected via WIFI or LAN.
The AX-TV can be controlled from its remote control, a web browser, the Supervisor X software or any
other software integrated with the AX-TV (there is an integration API available)
Package contents
Open the packaging and check that the following items are included;
•
AX-TV Unit
•
HDMI cable
•
Network cable
•
Remote control and batteries
•
Power supply

2. Installation and set up

Installation
Connect the unit to the power supply, the HDMI video cable to the monitor/TV and the network cable if
the connection is going to be via LAN.
The unit has to be installed in a visible place to be able to command it with the remote control. If you are
planning to control the AX-TV by other means you can hide it after the first configuration.
Don't place the unit in a closed place, it is necessary to leave some space for the ventilation.
Start-up
Select on your monitor/TV the HDMI input corresponding to the AX-TV to be able to see the configuration
menus on screen.
The first configuration of the unit has to be made with the remote control. You can connect a USB
keyboard to ease the input of text.
If you have a LAN connection and your router has DHCP the unit will get connected to the network
automatically, without need to edit the network configuration.
If the connection is via Wi-Fi the first thing you have to do is enter the network configuration menu to
select your Wi-Fi network and configure its password.
