Summary of Contents for Gold Medal 4211C
- Page 1 Instruction Manual Carmel Apple-Dip Warmer Model No. 4211C, 4211CX 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA Part No. 33051...
-
Page 2: Safety Precautions
Carmel Apple-Dip Warmer Model No. 4211C, 4211CX SAFETY PRECAUTIONS gmpopcorn.com Page 2... -
Page 3: Installation Instructions
Carmel Apple-Dip Warmer Model No. 4211C, 4211CX INSTALLATION INSTRUCTIONS After unpacking, check thoroughly for any damage which may have occurred in transit. Claims Inspection of Shipment should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control. -
Page 4: Electrical Requirements
Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Company’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. -
Page 5: About The Machine And Available Supplies
This machine is designed to use with either a standard #10 can (this is the can the caramel dip is About the Machine and Available Supplies sold in), or a stainless steel insert bowl. The insert bowl is sold separately from Gold Medal Products Co. as item #2194. -
Page 6: Controls And Their Functions
Carmel Apple-Dip Warmer Model No. 4211C, 4211CX OPERATING INSTRUCTIONS Controls and Their Functions Pushing this switch to the “ON” position (upright position with the lighted rocker switch ON/OFF SWITCH illuminated) will turn on the machine. The left and right side Temperature Control Knobs are used to set the desired warming TEMPERATURE CONTROL KNOB temperature for the caramel apple dip. -
Page 7: Operating Procedure
Carmel Apple-Dip Warmer Model No. 4211C, 4211CX Operating Procedure CAUTION Do NOT operate this unit without water! 1. Place the 2 can holders w/springs (shown on page 3) into the two reservoirs of the machine. 2. Place opened cans of caramel apple dip into the can holders. -
Page 8: Care And Cleaning
1. Unplug the machine and clean it after use. 2. Do not leave water in the pans overnight. 3. Clean the stainless steel covers with stainless steel cleaner. Gold Medal Products Company’s Watchdog Stainless Steel Polish (P/N 2088) is recommended. -
Page 9: Maintenance Instructions
Carmel Apple-Dip Warmer Model No. 4211C, 4211CX MAINTENANCE INSTRUCTIONS DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury or death. Read the installation, Operating, and Maintenance Instructions thoroughly before installing or servicing this equipment. DANGER Do Not immerse the equipment in water. Unplug your machine before servicing. - Page 10 Carmel Apple-Dip Warmer Model No. 4211C, 4211CX ORDERING SPARE PARTS 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. 2. When ordering, please include part number, part name, and quantity needed. 3. Please include your model number, serial number, and date of manufacture (located on the machine nameplate) with your order.
-
Page 11: Cabinet Exterior - Front View
Carmel Apple-Dip Warmer Model No. 4211C, 4211CX Cabinet Exterior – Front View Part Number Item Part Description Qty. KNOB, HEAT CONTROL 87049 87049 4211C 4211CX ROCKER SWITCH 42532 42532 STRAIN RELIEF 49740 49740 POWER SUPPLY CORD 22038 22038 HANDLE 67069 67069 gmpopcorn.com... -
Page 12: Cabinet Interior And Bottom Cover View
Carmel Apple-Dip Warmer Model No. 4211C, 4211CX Cabinet Interior and Bottom Cover View 1, 2 3, 4 Bottom Cover (Shown at a Reduced View) Part Number Item Part Description Qty. TINNERMAN FASTENER 47299 47299 4211C 4211CX 8-32 X 1/2 SLT HWH T/S (Screws) -
Page 13: Unit Accessories
Carmel Apple-Dip Warmer Model No. 4211C, 4211CX Unit Accessories Part Number Item Part Description Qty. CAN HOLDER W/SPRING 38540 38540 4211C 4211CX 3/4 OZ DIPPER 38129 38129 BOWL PLATFORM 38120 38120 LID W/KNOB 33056 33056 KNOB LID LIFT 47120 47120... -
Page 14: Wiring Diagram
Carmel Apple-Dip Warmer Model No. 4211C, 4211CX WIRING DIAGRAM Model No. 4211C gmpopcorn.com Page 14... - Page 15 Carmel Apple-Dip Warmer Model No. 4211C, 4211CX Model No. 4211CX gmpopcorn.com Page 15...
-
Page 16: Warranty
No claim under this warranty shall be honored in the event that components in the unit at the time of the claim were not supplied or approved by Gold Medal Products Company. This warranty is effective only when electrical items have been properly attached to city utility lines only at proper voltages.
