1/2.8" Compact High Sensitivity Network Camera
WAT-2400S
Thank you for purchasing the "1/2.8" Compact High Sensitivity Camera WAT-2400S / WAT-933 " (reffered to as the "product"
or "camera" in this manual). This operation manual covers safety, functions, installation and the correct operating procedure
for the camera. First, we ask you to read this operation manual thoroughly, then install and operate the product as advised.
For future reference, we also advise safekeeping of this manual. Not understanding the contents of the operation manual may
cause damage to the camera, personal belongings and/or result in injury. Watec is not responsible for any inconvenience or
the attendant damages to the video and monitoring recording equipment caused by misuse, miss-operation or improper wiring
of our equipment. If you do not understand the installation, operation or safety instructions expressed in this manual, please
contact the distributor or dealer from where the camera was purchased.
To Use This Product Safely
Watec cameras are designed to be used safely. If not used safely, it may lead to a physical accident caused by fire and
electric shock. Therefore, please keep and read the "Cautions for safety" (P.2) for protection against accidents.
Guide to the Safety Symbols
"Danger" indicates a compulsorily prohibition to prevent accidents.
"Warning" may lead to a serious accident such as death or injury caused by fire or electric shock.
"Caution" may incur injury and cause damage to peripheral objects in the immediate surroundings.
"Notice" indicates instructions which must be completed.
Power Supply
Power for the camera can either supplied by the PoE (Power over Ethernet) or DC power supply.
・PoE (Power over Ethernet)
Use the PoE hub or NVR supporting IEEE802.3af for the PoE power supply.
・DC power supply
Use a stabilized power adaptor designed for DC+12-36V with a current capacity of more than 500mA.
Wiring of the connector must be exact (see "Description of Parts" (P.4) "⑨4P Cable" ).
Utilize the option SWI12-12-N-P5 (Power supply adaptor), CB-06 and/or CB-07 (Cable with connectors).
Do not use the PoE and DC power supply at the same time!
Failure to observe the precautions above may result in damage to the camera, power adaptor and fire.
/
WAT-933
(Color)
Operation Manual
(B&W)
¦ 1 / 6 ¦
