3 Setting up the Smart Card

3.1 Set-up Procedure

Context:
SHOCK HAZARD
Attaching or removing accessories while the soft starter is connected to mains voltage may cause personal injury.
Before attaching or removing accessories, isolate the soft starter from mains voltage.
-
Procedure
1. Insert the smart card into the soft starter.
2. Connect sensors to the inputs:
A Depth protection: B13, B14 or C13, C14
B Pressure protection: B23, B24 or C33, C34, C43, C44.
C Flow protection: B33, B34 or C23, C24.
D Motor temperature protection: R1, R2, R3.
E Pressure or depth-based control: B23, B24.
3. Configure the soft starter's auto-reset as required (parameter 6-1 Auto-Reset Count and parameter 6-2 Auto-Reset Delay).
4. Configure flow protection operation if required.
5. Configure pressure protection operation if required.
6. Configure pressure or depth-based control if required.
Protection features still operate even if control is set to Off.
7. Configure depth protection if required.
8. Configure temperature protection if required.
9. Select the command source (parameter 1-1 Command Source).
• For protection and monitoring, use Digital input, Remote LCP, or Clock.
• For control, use Smart card or Smart card+Clock.
