Installation Guide | Pumping Smart Card
The reset input can be configured for normally open or normally closed operation. Use parameter 7-9 Reset/ Enable Logic to
select the configuration.
FLOW PROTECTION AND MONITORING
When used with a switch sensor, C23, C24 provide flow protection only. When used with a pulse sensor, C23, C24 provide flow
protection and monitoring.
10 | Danfoss A/S © 2018.10
N O T I C E
N O T I C E
Installation
AN279052730268en-000102 / 175R1183
